Coaxial
Power Splitter/Combiner
2 Way-0° Resistive 50Ω
Maximum Ratings
Operating Temperature
Storage Temperature
Power Input (as a splitter)
Internal Dissipation
-55°C to 100°C
-55°C to 100°C
0.75W max.
0.375W max.
ZFRSC-42+
ZFRSC-42
DC to 4200 MHz
CASE STYLE: K18
Connectors
Model
SMA
ZFRSC-42
BRACKET (OPTION “B”)
Price
$59.95
$2.50
Qty.
(1-9)
(1+)
Features
•
•
•
•
very wideband, DC to 4200 MHz
low insertion loss, 0.1 dB typ.
excellent amplitude unbalance, 0.02dB typ.
rugged shielded case
Applications
Coaxial Connections
SUM PORT
PORT 1
PORT 2
3
1
2
FREQ.
RANGE
(MHz)
f
L
-f
U
L
Typ.
6.2
• laboratory
• test set-ups
+ RoHS compliant in accordance
with EU Directive (2002/95/EC)
See our web site for RoHS Compliance methodologies and
qualifications.
Splitter Electrical Specifications
ISOLATION
(dB)
M
Typ.
6.5
U
Typ.
7.0
INSERTION LOSS (dB)
ABOVE 6 dB
L
Typ. Max.
0.1
0.2
M
U
Typ. Max. Typ. Max.
0.1
0.5
0.4
1.4
PHASE
UNBALANCE
(Degrees)
L
Max.
1
M
Max.
3
U
Max.
5
AMPLITUDE
UNBALANCE
(dB)
L
Max.
0.1
M
Max.
0.2
U
Max.
0.5
Outline Drawing
DC-4200
L = low range [f
L
to 10 f
L
]
M = mid range [10 f
L
to f
U
/2]
U = upper range [f
U
/2 to f
U
]
This is a resistive power divider to enable frequency coverage from dc to the highest rated frequency. Since resistive power
dividers do not provide a high degree of isolation (basically isolation equals the insertion loss between ports), an amplifier
such as Mini-Circuits’ ZFL series is recommended when high isolation is required. Matched power rating 0.75W, internal load
dissipation 0.375W.
Typical Performance Data
Amplitude
Unbalance
(dB)
0.03
0.01
0.02
0.00
0.01
0.01
0.02
0.03
0.02
0.01
0.02
0.01
0.04
0.08
0.03
Frequency
(MHz)
0.05
0.50
1.00
10.00
50.00
100.00
400.00
1000.00
1400.00
2000.00
2400.00
3000.00
3400.00
3800.00
4200.00
Insertion Loss
(dB)
(dB)
S-1
S-2
6.01
6.03
6.00
6.01
6.00
6.03
5.99
5.99
5.97
5.95
6.03
6.12
6.16
6.07
6.12
6.04
6.02
6.02
6.01
6.01
6.02
6.01
6.02
5.99
5.96
6.01
6.13
6.12
5.99
6.08
Isolation
(dB)
6.05
6.03
6.01
6.05
6.01
6.03
6.02
5.94
5.94
5.93
5.95
6.06
6.13
6.20
6.18
Phase
Unbalance
(deg.)
0.48
0.03
0.00
0.05
0.01
0.09
0.06
0.63
1.04
1.69
1.96
2.77
3.24
2.70
3.18
VSWR
S
1.00
1.00
1.00
1.00
1.00
1.00
1.01
1.02
1.01
1.03
1.03
1.03
1.02
1.02
1.04
VSWR
1
1.00
1.00
1.00
1.00
1.00
1.01
1.02
1.03
1.03
1.02
1.04
1.07
1.09
1.12
1.14
VSWR
2
1.00
1.00
1.00
1.00
1.00
1.01
1.02
1.03
1.03
1.03
1.04
1.07
1.08
1.10
1.12
Outline Dimensions (
inch
)
mm
A
1.25
31.75
J
--
--
B
1.25
31.75
K
--
--
C
.75
19.05
L
.125
3.18
D
.63
16.00
M
1.688
42.88
E
.38
9.65
N
2.18
55.37
F
1.00
25.40
P
.75
19.05
G
.125
3.18
H
1.000
25.40
INSERTION LOSS (dB)
ZFRSC-42
INSERTION LOSS
8.0
S-1(dB)
7.0
6.0
5.0
4.0
3.0
0
700
1400
2100
2800
3500
4200
FREQUENCY (MHz)
ZFRSC-42
VSWR
1.40
#S-VSWR
1.30
VSWR
1.20
1.10
1.00
0
700
1400
2100
2800
3500
4200
FREQUENCY (MHz)
#1-VSWR
#2-VSWR
5.0
0
700
S-2(dB)
ISOLATION (dB)
6.5
6.0
5.5
7.0
ZFRSC-42
ISOLATION
Q
wt
.07 grams
1.78
70.0
1400
2100
2800
3500
4200
FREQUENCY (MHz)
electrical schematic
Mini-Circuits
®
INTERNET
http://www.minicircuits.com
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
REV. A
M98898
ZFRSC-42
HY/TD/CP
050927
