ZFSC-3-1+ datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Wireless rf/communication> Radio frequency and microwave> ZFSC-3-1+

ZFSC-3-1+: DescriptionCombiner, 1MHz Min, 500MHz Max, 1.2dB Insertion Loss-Max, ROHS COMPLIANT, CASE J17; CategoryWireless rf/communication Radio frequency and microwave; File Size139KB，1 Pages; ManufacturerMini-Circuits; Websitehttps://www.minicircuits.com; Environmental Compliance

Download Datasheet Parametric Compare View All

ZFSC-3-1+ Overview

Combiner, 1MHz Min, 500MHz Max, 1.2dB Insertion Loss-Max, ROHS COMPLIANT, CASE J17

ZFSC-3-1+ Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Mini-Circuits
package instruction	ROHS COMPLIANT, CASE J17
Reach Compliance Code	not_compliant
ECCN code	EAR99
Other features	BNC, ISOLATION-MIN (DB):18
Characteristic impedance	50 Ω
structure	COAXIAL
Maximum input power (CW)	30 dBm
Maximum insertion loss	1.2 dB
Maximum operating frequency	500 MHz
Minimum operating frequency	1 MHz
Maximum operating temperature	100 °C
Minimum operating temperature	-55 °C
RF/Microwave Device Types	COMBINER
Maximum voltage standing wave ratio	1.26

Preview

Download Datasheet

View All

Coaxial

Power Splitter/Combiner

3 Way-0°

Operating Temperature

Storage Temperature

Power Input (as a splitter)

Internal Dissipation

ZFSC-3-1

50Ω

-55°C to 100°C

1W max.

0.375W max.

1 to 500 MHz

Features

• wideband, 1 to 500 MHz

• low insertion loss, 0.5 dB typ.

• high isolation, 30 dB typ.

• rugged, shielded case

BNC version shown

Maximum Ratings

CASE STYLE: J17

Connectors Model

BNC

ZFSC-3-1

SMA

ZFSC-3-1-S

N-TYPE

ZFSC-3-1-N

BRACKET (OPTION "B")

Price

$51.95

$56.95

$2.50

Qty.

(1-9)

(1+)

Coaxial Connections

SUMPORT

PORT 1

PORT 2

PORT 3

Applications

• VHF/UHF

• instrumentation

• communication system

Splitter Electrical Speciﬁcations

FREQ.

RANGE

(MHz)

-f

1-500

ISOLATION

(dB)

INSERTION LOSS (dB)

ABOVE 4.8 dB

PHASE

UNBALANCE

(Degrees)

Max.

AMPLITUDE

UNBALANCE

(dB)

Max.

0.2

Max.

0.3

Max.

0.4

Outline Drawing

Typ. Min Typ. Min Typ. Min

Typ. Max. Typ. Max. Typ. Max.

0.4

0.75

0.5

0.9

0.8

1.2

L = low range [f

to 10 f

]

M = mid range [10 f

to f

/2]

U= upper range [f

/2 to f

]

Typical Performance Data

Freq.

(MHz)

Insertion Loss

(dB)

S-1

1.00

4.20

7.00

10.00

67.00

124.00

181.00

220.00

250.00

310.00

390.00

450.00

470.00

490.00

500.00

5.02

5.01

5.02

5.09

5.16

5.25

5.24

5.28

5.33

5.46

5.57

5.55

5.60

Amp.

Unbal.

(dB)

1-2

0.00

0.01

0.00

0.01

0.02

0.03

0.06

0.08

0.14

0.20

0.22

0.27

0.29

35.42

35.93

36.31

36.50

33.88

30.45

28.12

26.92

26.28

25.41

25.38

25.97

26.08

26.00

25.91

Isolation

(dB)

1-3

35.35

35.81

36.18

36.38

34.07

30.83

28.54

27.33

26.69

25.80

25.74

26.51

26.78

26.98

27.09

Phase VSWR VSWR VSWR VSWR

Unbal.

(deg.)

2-3

35.32

36.47

36.81

36.98

33.28

29.38

26.82

25.52

24.76

23.71

23.33

23.79

24.04

24.29

24.49

0.03

0.07

0.10

0.56

1.09

1.49

1.71

1.91

2.16

2.50

2.80

3.14

3.41

3.49

1.11

1.06

1.05

1.07

1.13

1.18

1.21

1.23

1.26

1.24

1.23

1.22

ZFSC-3-1

ISOLATION

S-2

5.02

5.09

5.15

5.22

5.23

5.25

5.33

5.37

5.35

5.28

5.31

S-3

5.02

5.01

5.03

5.10

5.16

5.25

5.26

5.30

5.42

5.50

5.49

5.43

5.47

1.15

1.07

1.06

1.07

1.08

1.09

1.10

1.12

1.13

1.14

1.15

1.07

1.06

1.08

1.09

1.10

1.11

1.12

1.13

1.12

1.15

1.07

1.06

1.07

1.08

1.10

1.11

1.12

1.15

1.17

1.19

Outline Dimensions (

inch

)

1.25

.75

.63

31.75 31.75 19.05 16.00

.38 1.000

9.65 25.40

.125 1.000

3.18 25.40

.07 grams

1.78

75.0

INSERTION LOSS (dB)

.125 1.688

2.18

.75

3.18 42.88 55.37 19.05

ZFSC-3-1

INSERTION LOSS

6.0

S-1(dB)

S-2(dB)

S-3(dB)

1-2 (dB)

1-3 (dB)

2-3 (dB)

ISOLATION (dB)

100

200

300

400

500

For option B with N-Type connectors, dimension "C" increases

to 0.94 inches.

5.8

5.6

5.4

5.2

5.0

FREQUENCY (MHz)

100

200

300

400

500

FREQUENCY (MHz)

ZFSC-3-1

VSWR

1.5

1.4

VSWR

1.3

1.2

1.1

1.0

100

200

300

400

500

FREQUENCY (MHz)

#S-VSWR

#1-VSWR

electrical schematic

Distribution Centers

NORTH AMERICA 800-654-7949 • 417-335-5935 • Fax 417-335-5945 • EUROPE 44-1252-832600 • Fax 44-1252-837010

Mini-Circuits

INTERNET

http://www.minicircuits.com

P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661

REV. OR

M94793

ZFSC-3-1

HY/TD/CP

060905

Mini-Circuits

ISO 9001 & ISO 14001

Certified
