ZFSC-3-4-75: DescriptionCombiner, 1MHz Min, 1000MHz Max, 2dB Insertion Loss-Max, CASE J17; CategoryWireless rf/communication Radio frequency and microwave; File Size81KB，2 Pages; ManufacturerMini-Circuits; Websitehttps://www.minicircuits.com

Download Datasheet Parametric View All

ZFSC-3-4-75 Overview

Combiner, 1MHz Min, 1000MHz Max, 2dB Insertion Loss-Max, CASE J17

ZFSC-3-4-75 Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Mini-Circuits
package instruction	CASE J17
Reach Compliance Code	not_compliant
Other features	BNC, ISOLATION-MIN (DB):15
Characteristic impedance	75 Ω
structure	COAXIAL
Maximum input power (CW)	30 dBm
Maximum insertion loss	2 dB
JESD-609 code	e0
Maximum operating frequency	1000 MHz
Minimum operating frequency	1 MHz
Maximum operating temperature	100 °C
Minimum operating temperature	-55 °C
RF/Microwave Device Types	COMBINER
Terminal surface	Tin/Lead (Sn/Pb)
Maximum voltage standing wave ratio	1.58
