Non-Catalog Model
Frequency Mixer
ZFVY-1
Level 27 (LO Power +27 dBm)
Important Note
This is a non-catalog model and can be manufactured on specific request.
Pricing and delivery information can be supplied upon request.
Please click ”Back”, and then click “Contact Us” for Applications support.
CASE STYLE: K18
ELECTRICAL SPECIFICATIONS 50Ω @+25°C
Parameter
LO/RF Frequency
IF Frequency
Conversion Loss
L-R Isolation
1-250 MHz
0.5-500 MHz
0.5-50 MHz
50-250 MHz
250-500 MHz
L-I Isolation
0.5-50 MHz
50-250 MHz
250-500 MHz
1 dB COMP.: +24 dBm typ.
Min.
0.5
0.02
Typ.
Max.
500
500
Units
MHz
MHz
dB
dB
dB
dB
dB
dB
dB
dB
5.79
40
35
25
28
35
25
47
46
35
35
46
35
7.5
8.5
MAXIMUM RATINGS
Operating Temperature
Storage Temperature
-55°C to 100°C
-55°C to 100°C
Electrical Schematic
PIN CONNECTIONS
LO
RF
IF
1
2
3
Mini-Circuits
ISO 9001 ISO 14001
CERTIFIED
RF/IF MICROWAVE COMPONENTS
®
minicircuits.com
REV. OR
M113754
ZFVY-1
080408
EW
ALL N
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661 For detailed performance specs & shopping online see Mini-Circuits web site
The Design Engineers Search Engine
Provides ACTUAL Data Instantly From MINI-CIRCUITS At:
www.minicircuits.com
