Coaxial
Frequency Mixer
Level 7 (LO Power +7 dBm)
Maximum Ratings
Operating Temperature
Storage Temperature
RF Power
IF Current
-55°C to 100°C
-55°C to 100°C
50mW
40mA
ZP-3+
ZP-3
0.15 to 400 MHz
Features
• low conversion loss, 4.7 dB typ.
• IF response to DC
• excellent L-R isolation, 46 dB typ., L-I, 47 dB typ.
• rugged shielded case
BNC version shown
CASE STYLE: GG60
Connectors
BNC
SMA
Model
ZP-3+
ZP-3-S(+)
Price
Qty.
$39.95 ea. (1-9)
$44.95 ea. (1-9)
Permanent damage may occur if any of these limits are exceeded.
Applications
• VHF/UHF
• cellular
• instrumentation
Coaxial Connections
LO
RF
IF
L
R
X
+ RoHS compliant in accordance
with EU Directive (2002/95/EC)
The +Suffix identifies RoHS Compliance. See our web site
for RoHS Compliance methodologies and qualifications.
Outline Drawing
Electrical Specifications
FREQUENCY
(MHz)
LO/RF
f
L
-f
U
0.15-400
DC-400
IF
—
X
4.7
CONVERSION LOSS
(dB)
Mid-Band
m
σ
0.10
Total
Range
Max. Max.
7.0
8.0
L
LO-RF ISOLATION
(dB)
M
Typ. Min.
46
30
50
35
U
Typ. Min.
25
60
L
LO-IF ISOLATION
(dB)
M
Typ. Min.
47
25
40
35
U
Typ. Min.
20
Typ. Min.
60
Typ. Min.
1 dB COMP.: +1 dBm typ.
For phase detection, DC output has positive
polarity with in-phase LO and RF signals.
L = low range [f
L
to 10 f
L
]
m= mid band [2f
L
to f
U
/2]
M = mid range [10 f
L
to f
U
/2]
U = upper range [f
U
/2 to f
U
]
Typical Performance Data
Frequency
(MHz)
Conversion
Loss
(dB)
LO
30.15
30.23
30.30
30.50
31.00
32.80
36.40
40.00
58.00
94.00
130.00
168.00
187.00
225.00
263.00
282.00
301.00
320.00
340.00
370.00
LO
+7dBm
5.37
5.27
5.21
5.16
5.08
4.91
4.91
4.73
4.71
4.75
4.83
4.85
4.88
4.92
4.97
5.10
5.17
5.15
5.38
5.41
VSWR
RF Port
(:1)
LO
+7dBm
1.57
1.41
1.33
1.25
1.21
1.21
1.21
1.21
1.21
1.17
1.14
1.13
1.10
1.08
1.10
1.12
1.14
1.17
1.10
1.05
Frequency
(MHz)
Isolation
L-R
(dB)
LO
+7dBm
68.68
65.36
63.22
61.75
57.56
56.48
54.90
52.63
54.13
49.62
48.10
48.03
53.65
55.10
54.03
52.86
51.53
47.44
45.39
44.42
Isolation
L-I
(dB)
LO
+7dBm
61.84
56.87
54.20
52.09
47.59
45.97
44.70
42.36
42.02
38.81
38.56
37.82
37.79
38.07
37.59
36.62
35.44
33.11
32.24
32.17
VSWR
LO Port
(:1)
LO
+7dBm
2.59
2.60
2.59
2.58
2.54
2.50
2.50
2.57
2.55
2.62
2.66
2.68
2.67
2.76
2.82
2.76
2.69
2.86
3.05
3.06
RF
0.15
0.23
0.30
0.50
1.00
2.80
6.40
10.00
28.00
64.00
100.00
138.00
157.00
195.00
233.00
252.00
271.00
290.00
370.00
400.00
LO
10.00
20.00
30.00
40.00
76.00
94.00
112.00
149.00
168.00
206.00
225.00
244.00
282.00
301.00
320.00
340.00
360.00
390.00
410.00
430.00
Outline Dimensions (
inch
)
mm
A
B
C
2.31 1.20
.60
58.67 30.48 15.24
D
E
.125 2.062
3.18 52.37
F
G
H
wt
.30
.53
.63 grams
7.62 13.46 16.00
75.0
Electrical Schematic
ISO 9001 ISO 14001 AS 9100
CERTIFIED
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
The Design Engineers Search Engine
IF/RF MICROWAVE COMPONENTS
Mini-Circuits
®
For detailed performance specs
& shopping online see web site
®
Provides ACTUAL Data Instantly at
minicircuits.com
Notes: 1.
Performance and quality attributes and conditions not expressly stated in this specification sheet are intended to be excluded and do not form a part of this specification sheet.
2.
Electrical specifications
and performance data contained herein are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.
3.
The parts covered by this specification sheet are subject to
Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled to the rights and benefits contained therein. For a full statement of the Standard
Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp.
REV. B
M108294
ZP-3
DJ/TD/CP
070412
Page 1 of 2
Performance Charts
7.5
CONVERSION LOSS (dB)
at IF Freq of 30 MHz
ZP-3+
ZP-3
ZP-3
L-R ISOLATION
80
70
60
50
40
LO=+4 dBm
30
LO=+7 dBm
200
FREQUENCY (MHz)
ZP-3
RF VSWR
2.5
LO=+4 dBm
2.0
VSWR
LO=+7 dBm
LO=+10 dBm
LO=+10 dBm
300
400
ZP-3
CONVERSION LOSS
7.0
6.5
6.0
5.5
5.0
4.5
0.1
ISOLATION (dB)
LO=+4 dBm
LO=+7 dBm
LO=+10 dBm
1
10
FREQUENCY (MHz)
ZP-3
L-I ISOLATION
100
1000
0
100
70
60
50
40
30
20
0
LO=+4 dBm
100
ISOLATION (dB)
1.5
LO=+7 dBm
LO=+10 dBm
300
400
1.0
0.1
1
10
FREQUENCY (MHz)
100
1000
200
FREQUENCY (MHz)
ZP-3
LO VSWR
ZP-3
IF VSWR
4.0
3.5
VSWR
2.5
at LO Freq of 400 MHz
LO=+4 dBm
LO=+7 dBm
LO=+10 dBm
2.5
2.0
1.5
1.0
0
LO=+4 dBm
100
LO=+7 dBm
LO=+10 dBm
300
400
VSWR
200
FREQUENCY (MHz)
3.0
2.0
1.5
1.0
0.1
1
10
FREQUENCY (MHz)
100
1000
ISO 9001 ISO 14001 AS 9100
CERTIFIED
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
The Design Engineers Search Engine
IF/RF MICROWAVE COMPONENTS
Mini-Circuits
®
For detailed performance specs
& shopping online see web site
®
Provides ACTUAL Data Instantly at
minicircuits.com
Notes: 1.
Performance and quality attributes and conditions not expressly stated in this specification sheet are intended to be excluded and do not form a part of this specification sheet.
2.
Electrical specifications
and performance data contained herein are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.
3.
The parts covered by this specification sheet are subject to
Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled to the rights and benefits contained therein. For a full statement of the Standard
Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp.
Page 2 of 2
