Connectorized
Amplifier
Features
• Wide Bandwidth, 20 MHz to 6 GHz
• Low Noise Figure, 3.3 dB Typ.
• Protected by US Patent 6,790,049
ZX60-6013E+
ZX60-6013E
50Ω, 20 MHz to 6 GHz
Applications
•
•
•
•
•
•
CASE STYLE: GC957
Connectors
SMA
SMA
Model
ZX60-6013E-S+
ZX60-6013E-S
Price
$49.95 ea.
$49.95 ea.
Qty.
(1-9)
(1-9)
Buffer Amplifier
Cellular
PCS
Lab
Instrumentation
Test Equipment
+ RoHS compliant in accordance
with EU Directive (2002/95/EC)
The + suffix identifies RoHS Compliance.
See
our web site
for RoHS Compliance methodologies and qualifications.
Electrical Specifications at T
AMB
= 25
o
C
MODEL
NO.
FREQ.
DC
(GHz) VOLTAGE
@ Pin V+
(V)
f
L
- f
U
ZX60-6013E(+) 0.02-6
12.0
0.1
GAIN over frequency in GHz
Typ (dB)
MAXIMUM DYNAMIC
VSWR
ACTIVE
DC
POWER
RANGE
(:1)
DIRECTIVITY OPERATING
(dBm)
Typ.
(dB)
CURRENT @
Output
Isolation-Gain
Pin V+
(1 dB
(mA)
NF
IP3
6.0 Min.at
In
Out
Comp.) (dB) (dBm)
2 GHz
3-f
U
f
L
-3 3-f
U
Typ. Max.
Typ.
Typ. Typ. f
L
-3
Typ.
GHz GHz GHz GHz
f
U
f
L
13.0
13.4
5.8
3.3
28.7
1.4
1.6
1.2
1.2
3-9
39
50
1.0
2.0
3.0
4.0
5.0
16.2 15.9 15.2 14.3 13.4 12.7 12.1
Maximum Ratings
Operating Temperature
Storage Temperature
DC Voltage
Input Power(no Damage)
Power
-45
o
C to 85
o
C
-55
o
C to 100
o
C
12.5V
15dBm
650mW
Outline Drawing
Outline Dimensions (
inch
)
mm
A
B
C
D
.74 .75 .46 1.18
18.8 19.1 11.6 30.0
E
.04
1.0
F
G H
.17 .45 .59
4.3 11.4 14.9
J
.33
8.3
K
.21
5.3
L
.22
5.6
M
N
P
.18 1.00 0.37
4.6 25.4 9.4
Q
.18
4.6
R
wt.
.09 grams
2.3
23.0
Distribution Centers
NORTH AMERICA 800-654-7949 • 417-335-5935 • Fax 417-335-5945 • EUROPE 44-1252-832600 • Fax 44-1252-837010
Mini-Circuits
®
INTERNET
http://www.minicircuits.com
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
Mini-Circuits
ISO 9001 & ISO 14001
Certified
REV.B
M98898
EDR-6286
ZX60-6013E
RAV/URJ
061121
page 1 of 2
Typical Performance Data & Curves at
25 C
FREQUENCY
(MHz)
20
50
100
500
1000
1500
2000
2500
3000
3220
3500
3670
3850
4000
4200
4500
5000
5500
5750
6000
GAIN
(dB)
16.09
16.28
16.31
16.20
15.94
15.60
15.22
14.76
14.24
14.11
13.85
13.72
13.52
13.37
13.15
13.05
12.62
12.33
12.18
12.06
DIRECTIVITY
(dB)
3.60
3.33
3.24
3.40
3.73
4.12
4.54
5.59
6.08
6.22
6.78
6.91
7.28
7.13
7.35
7.95
8.79
8.81
9.27
9.18
VSWR
IN
(:1)
1.24
1.21
1.20
1.22
1.27
1.38
1.48
1.57
1.59
1.57
1.54
1.55
1.53
1.51
1.69
1.68
1.60
1.51
1.45
1.39
VSWR
OUT
(:1)
1.03
1.08
1.10
1.11
1.12
1.14
1.18
1.21
1.22
1.25
1.22
1.22
1.23
1.22
1.15
1.13
1.05
1.07
1.12
1.19
POWER OUT @1dB
COMPRESSION
(dBm)
13.24
13.28
13.35
13.61
13.50
13.22
12.87
12.45
11.90
11.60
11.16
10.86
10.51
10.21
9.78
9.10
7.93
6.81
6.30
5.81
o
ZX60-6013E+
ZX60-6013E
IP3
(dBm)
29.97
29.96
29.95
29.73
29.20
28.42
27.42
26.23
24.91
24.28
23.48
22.97
22.43
21.98
21.37
20.45
18.92
17.44
16.72
16.04
NF
(dB)
3.33
3.27
3.20
3.26
3.16
3.27
3.35
3.20
3.11
3.32
3.42
3.36
3.25
3.21
3.10
3.04
3.16
3.19
3.22
3.21
ZX60-6013E
GAIN
17
ZX60-6013E
DIRECTIVITY
10
DIRECTIVITY (dB)
9
8
7
6
5
4
3
2
ZX60-6013E
VSWR
2.0
1.8
VSWR
1.6
1.4
1.2
1.0
0
1000
2000
3000
4000
FREQUENCY (MHz)
5000
6000
IN
OUT
16
GAIN (dB)
15
14
13
12
11
0
1000
2000
3000
4000
FREQUENCY (MHz)
5000
6000
0
1000
2000
3000
4000
FREQUENCY (MHz)
5000
6000
ZX60-6013E
OUTPUT POWER AT 1dB COMPRESSION
16
OUTPUT POWER (dBm)
ZX60-6013E
NOISE FIGURE
3.5
NOISE FIGURE (dB)
3.4
3.3
3.2
3.1
3.0
ZX60-6013E
IP3
31
29
27
IP3 (dBm)
25
23
21
19
17
15
14
12
10
8
6
4
0
1000
2000
3000
4000
FREQUENCY (MHz)
5000
6000
0
1000
2000
3000
4000
FREQUENCY (MHz)
5000
6000
0
1000
2000
3000
4000
FREQUENCY (MHz)
5000
6000
Distribution Centers
NORTH AMERICA 800-654-7949 • 417-335-5935 • Fax 417-335-5945 • EUROPE 44-1252-832600 • Fax 44-1252-837010
Mini-Circuits
®
INTERNET
http://www.minicircuits.com
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
page 2 of 2
Mini-Circuits
ISO 9001 & ISO 14001
Certified
