AD2S82AKPZ datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> converter> AD2S82AKPZ

AD2S82AKPZ: DescriptionSYNCHRO OR RESOLVER TO DIGITAL CONVERTER, PQCC44, PLASTIC, LCC-44; CategoryAnalog mixed-signal IC converter; File Size2MB，17 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

AD2S82AKPZ Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	AD2S82AKPZ	-	-	View	Buy Now

AD2S82AKPZ Overview

SYNCHRO OR RESOLVER TO DIGITAL CONVERTER, PQCC44, PLASTIC, LCC-44

AD2S82AKPZ Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Rochester Electronics
Parts packaging code	LCC
package instruction	QCCJ,
Contacts	44
Reach Compliance Code	unknown
Is Samacsys	N
Maximum analog input voltage	2 V
Maximum angular accuracy	4 arc min
Converter type	SYNCHRO OR RESOLVER TO DIGITAL CONVERTER
JESD-30 code	S-PQCC-J44
JESD-609 code	e3
length	16.5862 mm
Humidity sensitivity level	3
Maximum negative supply voltage	-13.2 V
Minimum negative supply voltage	-10.8 V
Nominal negative supply voltage	-12 V
Number of digits	16
Number of functions	1
Number of terminals	44
Maximum operating temperature	70 °C
Minimum operating temperature
Package body material	PLASTIC/EPOXY
encapsulated code	QCCJ
Package shape	SQUARE
Package form	CHIP CARRIER
Peak Reflow Temperature (Celsius)	260
Certification status	COMMERCIAL
Maximum seat height	4.57 mm
Signal/output frequency	20000 Hz
Maximum supply voltage	13.2 V
Minimum supply voltage	10.8 V
Nominal supply voltage	12 V
surface mount	YES
technology	BICMOS
Temperature level	COMMERCIAL
Terminal surface	MATTE TIN
Terminal form	J BEND
Terminal pitch	1.27 mm
Terminal location	QUAD
Maximum time at peak reflow temperature	40
Maximum tracking rate	16.25 rps
width	16.5862 mm
Base Number Matches	1

Preview

Download Datasheet

View All

D ts e t

aa h e

R c e t r lc r nc

o h se Ee to is

Ma u a t r dCo o e t

n fc u e

mp n n s

R c e tr b a d d c mp n ns ae

o h se rn e

o oet r

ma ua trd u ig ete dewaes

n fcue sn i r i/ fr

p rh s d f m te oiia s p l r

uc a e r

o h r n l u pi s

o R c e tr waes rce td f m

r o h se

fr e rae r

te oiia I. Al rce t n ae

r nl P

l e rai s r

d n wi tea p o a o teOC

o e t h p rv l f h

P r aetse u igoiia fcoy

at r e td sn r n la tr

ts p o rmso R c e tr e eo e

e t rga

r o h se d v lp d

ts s lt n t g aa te p o u t

e t oui s o u rne

rd c

me t o e c e teOC d t s e t

es r x e d h

M aa h e.

Qu l yOv riw

e ve

• IO- 0 1

S 90

•A 92 cr ct n

S 1 0 et ai

• Qu l e Ma ua trr Ls (

ai d

n fcues it QML MI- R -

) LP F

385

•C a sQ Mitr

lay

•C a sVS a eL v l

p c ee

• Qu l e S p l r Ls o D sr uos( L )

ai d u pi s it f it b tr QS D

•R c e trsacic l u pir oD A a d

o h se i

r ia s p l t L n

me t aln u t a dD A sa d r s

es lid sr n L tn ad .

R c e tr lcrnc , L i c mmi e t

o h se Ee t is L C s o

tdo

s p ligp o u t ta s t f c so r x e t-

u pyn rd cs h t ai y u tme e p ca

t n fr u lya daee u loto eoiial

i s o q ai n r q a t h s r n l

s p l db id sr ma ua trr.

u pi

e yn ut

y n fcues

T eoiia ma ua trr d ts e t c o a yn ti d c me t e e t tep r r n e

h r n l n fcue’ aa h e a c mp n ig hs o u n r cs h ef ma c

a ds e ic t n o teR c e tr n fcue v rino ti d vc . o h se Ee t n

n p c ai s f h o h se ma ua trd eso f hs e ie R c e tr lcr -

isg aa te tep r r n eo i s mio d co p o u t t teoiia OE s e ic -

c u rne s h ef ma c ft e c n u tr rd cs o h r n l M p c a

t n .T pc lv le aefr eee c p r o e o l. eti mii m o ma i m rt g

i s ‘y ia’ au s r o rfrn e up s s ny C r n nmu

r xmu ai s

ma b b s do p o u t h rceiain d sg , i lt n o s mpetsig

y e a e n rd c c aa tr t , e in smuai , r a l e t .

z o

0 3 ohs E cr i , L . lRg s eevd 7 1 0 3

e e oc

T l r m r, l s v iw wrcl . m

o e n oe p ae it w . e c o

o ec

AD2S82AKPZ Related Products

	AD2S82AKPZ	AD2S81AJD	AD2S82AHPZ	AD2S82ALPZ	AD2S82AHP	AD2S82ALP	AD2S82AHPZ-REEL
Description	SYNCHRO OR RESOLVER TO DIGITAL CONVERTER, PQCC44, PLASTIC, LCC-44	SYNCHRO OR RESOLVER TO DIGITAL CONVERTER, CDIP28, CERAMIC, DIP-28	SYNCHRO OR RESOLVER TO DIGITAL CONVERTER, PQCC44, PLASTIC, LCC-44	SYNCHRO OR RESOLVER TO DIGITAL CONVERTER, PQCC44, PLASTIC, LCC-44	SYNCHRO OR RESOLVER TO DIGITAL CONVERTER, PQCC44, PLASTIC, LCC-44	SYNCHRO OR RESOLVER TO DIGITAL CONVERTER, PQCC44, PLASTIC, LCC-44	SYNCHRO OR RESOLVER TO DIGITAL CONVERTER, PQCC44, PLASTIC, LCC-44
Is it lead-free?	Lead free	Contains lead	Lead free	Lead free	Contains lead	Contains lead	Lead free
Is it Rohs certified?	conform to	incompatible	conform to	conform to	incompatible	incompatible	conform to
Maker	Rochester Electronics	Rochester Electronics	Rochester Electronics	Rochester Electronics	Rochester Electronics	Rochester Electronics	Rochester Electronics
Parts packaging code	LCC	DIP	LCC	LCC	LCC	LCC	LCC
package instruction	QCCJ,	DIP,	QCCJ,	QCCJ,	QCCJ,	QCCJ,	QCCJ,
Contacts	44	28	44	44	44	44	44
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown	unknown	unknown
Is Samacsys	N	N	N	N	N	N	N
Maximum analog input voltage	2 V	2 V	2 V	2 V	2 V	2 V	2 V
Maximum angular accuracy	4 arc min	30 arc min	22 arc min	2 arc min	22 arc min	2 arc min	22 arc min
Converter type	SYNCHRO OR RESOLVER TO DIGITAL CONVERTER	SYNCHRO OR RESOLVER TO DIGITAL CONVERTER	SYNCHRO OR RESOLVER TO DIGITAL CONVERTER	SYNCHRO OR RESOLVER TO DIGITAL CONVERTER	SYNCHRO OR RESOLVER TO DIGITAL CONVERTER	SYNCHRO OR RESOLVER TO DIGITAL CONVERTER	SYNCHRO OR RESOLVER TO DIGITAL CONVERTER
JESD-30 code	S-PQCC-J44	R-CDIP-T28	S-PQCC-J44	S-PQCC-J44	S-PQCC-J44	S-PQCC-J44	S-PQCC-J44
JESD-609 code	e3	e0	e3	e3	e0	e0	e3
length	16.5862 mm	37.85 mm	16.5862 mm	16.5862 mm	16.5862 mm	16.5862 mm	16.5862 mm
Humidity sensitivity level	3	NOT SPECIFIED	3	3	5	5	3
Maximum negative supply voltage	-13.2 V	-13.2 V	-13.2 V	-13.2 V	-13.2 V	-13.2 V	-13.2 V
Minimum negative supply voltage	-10.8 V	-10.8 V	-10.8 V	-10.8 V	-10.8 V	-10.8 V	-10.8 V
Nominal negative supply voltage	-12 V	-12 V	-12 V	-12 V	-12 V	-12 V	-12 V
Number of digits	16	12	16	16	16	16	16
Number of functions	1	1	1	1	1	1	1
Number of terminals	44	28	44	44	44	44	44
Maximum operating temperature	70 °C	70 °C	70 °C	70 °C	70 °C	70 °C	70 °C
Package body material	PLASTIC/EPOXY	CERAMIC, METAL-SEALED COFIRED	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	QCCJ	DIP	QCCJ	QCCJ	QCCJ	QCCJ	QCCJ
Package shape	SQUARE	RECTANGULAR	SQUARE	SQUARE	SQUARE	SQUARE	SQUARE
Package form	CHIP CARRIER	IN-LINE	CHIP CARRIER	CHIP CARRIER	CHIP CARRIER	CHIP CARRIER	CHIP CARRIER
Peak Reflow Temperature (Celsius)	260	NOT SPECIFIED	260	260	225	225	260
Certification status	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL
Maximum seat height	4.57 mm	5.27 mm	4.57 mm	4.57 mm	4.57 mm	4.57 mm	4.57 mm
Signal/output frequency	20000 Hz	20000 Hz	20000 Hz	20000 Hz	20000 Hz	20000 Hz	20000 Hz
Maximum supply voltage	13.2 V	13.2 V	13.2 V	13.2 V	13.2 V	13.2 V	13.2 V
Minimum supply voltage	10.8 V	10.8 V	10.8 V	10.8 V	10.8 V	10.8 V	10.8 V
Nominal supply voltage	12 V	12 V	12 V	12 V	12 V	12 V	12 V
surface mount	YES	NO	YES	YES	YES	YES	YES
technology	BICMOS	BICMOS	BICMOS	BICMOS	BICMOS	BICMOS	BICMOS
Temperature level	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL
Terminal surface	MATTE TIN	TIN LEAD	MATTE TIN	MATTE TIN	TIN LEAD	TIN LEAD	MATTE TIN
Terminal form	J BEND	THROUGH-HOLE	J BEND	J BEND	J BEND	J BEND	J BEND
Terminal pitch	1.27 mm	2.54 mm	1.27 mm	1.27 mm	1.27 mm	1.27 mm	1.27 mm
Terminal location	QUAD	DUAL	QUAD	QUAD	QUAD	QUAD	QUAD
Maximum time at peak reflow temperature	40	NOT SPECIFIED	40	40	30	30	40
Maximum tracking rate	16.25 rps	260 rps	16.25 rps	16.25 rps	16.25 rps	16.25 rps	16.25 rps
width	16.5862 mm	15.24 mm	16.5862 mm	16.5862 mm	16.5862 mm	16.5862 mm	16.5862 mm
Base Number Matches	1	1	1	1	1	1	1
