NP84N055CHE

Description
Power Field-Effect Transistor, 84A I(D), 55V, 0.0073ohm, 1-Element, N-Channel, Silicon, Metal-oxide Semiconductor FET, TO-220AB, MP-25, 3 PIN
CategoryDiscrete semiconductor    The transistor
File Size80KB,8 Pages
ManufacturerNEC Electronics
Download Datasheet Parametric View All

NP84N055CHE Overview

Power Field-Effect Transistor, 84A I(D), 55V, 0.0073ohm, 1-Element, N-Channel, Silicon, Metal-oxide Semiconductor FET, TO-220AB, MP-25, 3 PIN

NP84N055CHE Parametric

Parameter NameAttribute value
Is it Rohs certified?incompatible
MakerNEC Electronics
Parts packaging codeTO-220AB
package instructionFLANGE MOUNT, R-PSFM-T3
Contacts3
Reach Compliance Codecompliant
ECCN codeEAR99
Is SamacsysN
Avalanche Energy Efficiency Rating (Eas)441 mJ
Shell connectionDRAIN
ConfigurationSINGLE WITH BUILT-IN DIODE
Minimum drain-source breakdown voltage55 V
Maximum drain current (ID)84 A
Maximum drain-source on-resistance0.0073 Ω
FET technologyMETAL-OXIDE SEMICONDUCTOR
JEDEC-95 codeTO-220AB
JESD-30 codeR-PSFM-T3
JESD-609 codee0
Number of components1
Number of terminals3
Operating modeENHANCEMENT MODE
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formFLANGE MOUNT
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Polarity/channel typeN-CHANNEL
Maximum pulsed drain current (IDM)336 A
Certification statusNot Qualified
surface mountNO
Terminal surfaceTIN LEAD
Terminal formTHROUGH-HOLE
Terminal locationSINGLE
Maximum time at peak reflow temperatureNOT SPECIFIED
transistor applicationsSWITCHING
Transistor component materialsSILICON
Base Number Matches1
DATA SHEET
MOS FIELD EFFECT TRANSISTOR
NP84N055CHE,NP84N055DHE,NP84N055EHE,NP84N055KHE
SWITCHING
N-CHANNEL POWER MOS FET
DESCRIPTION
These products are N-channel MOS Field Effect
Transistor designed for high current switching
applications.
ORDERING INFORMATION
PART NUMBER
NP84N055CHE
NP84N055DHE
NP84N055EHE
PACKAGE
TO-220AB
TO-262
TO-263 (MP-25ZJ)
TO-263 (MP-25ZK)
FEATURES
Channel temperature 175 degree rated
Super low on-state resistance
R
DS(on)
= 7.3 mΩ MAX. (V
GS
= 10 V, I
D
= 42 A)
Low C
iss
: C
iss
= 4540 pF TYP.
Built-in gate protection diode
5
NP84N055KHE
(TO-220AB)
ABSOLUTE MAXIMUM RATINGS (T
A
= 25°C)
Drain to Source Voltage (
V
GS
= 0 V
)
Gate to Source Voltage (
V
DS
= 0 V
)
Drain Current (DC) (T
C
= 25°C)
Drain Current (pulse)
Note2
Note1
V
DSS
V
GSS
I
D(DC)
I
D(pulse)
P
T
P
T
T
ch
T
stg
55
±20
±84
±336
1.8
200
175
−55
to +175
84 / 56 / 21
70 / 313 / 441
V
V
A
A
W
W
°C
°C
A
mJ
(TO-263)
(TO-262)
Total Power Dissipation (T
A
= 25°C)
Total Power Dissipation (T
C
= 25°C)
Channel Temperature
Storage Temperature
Single Avalanche Current
Single Avalanche Energy
Note3
Note3
I
AS
E
AS
Notes 1.
Calculated constant current according to MAX. allowable channel
temperature.
2.
PW
10
µ
s, Duty cycle
1%
3.
Starting T
ch
= 25°C, V
DD
= 28 V, R
G
= 25
, V
GS
= 20
0 V (See Figure 4.)
THERMAL RESISTANCE
Channel to Case Thermal Resistance
Channel to Ambient Thermal Resistance
R
th(ch-C)
R
th(ch-A)
0.75
83.3
°C/W
°C/W
The information in this document is subject to change without notice. Before using this document, please
confirm that this is the latest version.
Not all products and/or types are available in every country. Please check with an NEC Electronics
sales representative for availability and additional information.
Document No.
D14099EJ5V0DS00 (5th edition)
Date Published December 2002 NS CP(K)
Printed in Japan
The mark
5
shows major revised points.
2002
