SAW Components
Low-Loss Filter
Data Sheet
B1610
1220,00 MHz
SMD ceramic package
QCC8D
Features
s
Low loss RF filter for dual conversion
s
Usable passband 8 MHz
s
No matching network required for operation
at 200
Ω
s
Balanced to balanced operation
s
Low group delay ripple
s
Package for
Surface Mounted
Technology (SMT)
Terminals
s
Ni, gold-plated
Dimensions in mm, approx. weight 0,037 g
Pin configuration
1
2
5
6
3,7
4,8
Input
Input
Output
Output
To be grounded
Case – ground
Type
B1610
Ordering code
B39122–B1610–U810
Marking and Package
according to
C61157-A7-A72
Packing
according to
F61074-V8168-Z000
Electrostatic Sensitive Device
(ESD)
Maximum ratings
Operable temperature range
Storage temperature range
DC voltage
Source power
T
T
stg
V
DC
P
S
–40/+85
–40/+85
0
0
˚C
˚C
V
dBm
source and load impedance 200
Ω
2
Jul 03, 2003
SAW Components
Low-Loss Filter
Data Sheet
Characteristics
Operating temperature range:
Terminating source impedance:
Terminating load impedance:
B1610
1220,00 MHz
T
= –40 ˚C ... +85 ˚C
Z
S
= 200
Ω
Z
L
= 200
Ω
min.
typ.
1220,00
max.
—
MHz
Nominal frequency
f
N
—
α
max
Maximum insertion attenuation
1216,00 ... 1224,00 MHz
∆α
Amplitude ripple in passband
(p-p)
1216,00 ... 1224,00 MHz
Attenuation
500,00 ... f
N
–91,00 MHz
f
N
–91,00 ... f
N
–85,00 MHz
f
N
–76,00 ... f
N
–68,00 MHz
f
N
–88,00
f
N
–72,00
f
N
–44,00
f
N
–36,00
MHz
MHz
MHz
MHz
α
—
3,6
4,2
dB
—
0,6
1,2
dB
58,0
58,0
56,0
58,0
56,0
46,0
42,0
56,0
62,0
62,0
60,0
62,0
60,0
54,0
44,0
62,0
—
—
—
—
—
—
—
—
dB
dB
dB
dB
dB
dB
dB
dB
f
N
+70,00 ... 2000,00 MHz
∆τ
Group delay ripple
(p-p)
1216,00 ... 1224,00 MHz
—
15
—
ns
3
Jul 03, 2003
SAW Components
Low-Loss Filter
Data Sheet
Transfer function
B1610
1220,00 MHz
Transfer function
(passband)
4
Jul 03, 2003
SAW Components
Low-Loss Filter
Data Sheet
Transfer function
(wideband)
B1610
1220,00 MHz
5
Jul 03, 2003
