CMD4850P-10 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > LED optoelectronic/LED> photoelectric> CMD4850P-10

CMD4850P-10: DescriptionTrigger Output SSR, 1-Channel, 4000V Isolation, PLASTIC PACKAGE-4; CategoryLED optoelectronic/LED photoelectric; File Size575KB，5 Pages; ManufacturerCrydom; Websitehttp://www.crydom.com/en/index.shtml

Download Datasheet Parametric View All

CMD4850P-10 Overview

Trigger Output SSR, 1-Channel, 4000V Isolation, PLASTIC PACKAGE-4

CMD4850P-10 Parametric

Parameter Name	Attribute value
Maker	Crydom
package instruction	PLASTIC PACKAGE-4
Reach Compliance Code	unknown
Is Samacsys	N
Other features	VDE APPROVED
Maximum forward current	0.03 A
Maximum insulation voltage	4000 V
Number of components	1
Maximum on-state current	50 A
Maximum operating temperature	80 °C
Minimum operating temperature	-40 °C
Optoelectronic device types	TRIGGER OUTPUT SSR
Base Number Matches	1

Preview

Download Datasheet

View All

CMD / CMA48 Series

• Ratings from 25A to 125A @ 48-530 VAC

• SCR output for heavy industrial loads

• AC or DC control

• LED input status indicator

• Zero-crossing (resistive loads) or random-fire (inductive loads) output

• IP20 touch-safe housing

• Standard box-clamp connections

PRODUCT SELECTION

Control Voltage

4-32 VDC

90-140 VAC

18-36 VAC

25A

CMD4825

CMA4825

CMA4825E

50A

CMD4850

CMA4850

CMA4850E

75A

CMD4875

CMA4875

CMA2475E

90A

CMD4890

CMA4890

CMA4890E

110A

CMD48110

CMA48110

CMA48110E

125A

CMD48125

CMA48125

CMA48125E

AVAILABLE OPTIONS

OUTPUT SPECIFICATIONS (1)

Description

Operating Voltage (47-63Hz) [Vrms]

Transient Overvoltage [Vpk]

Maximum Off-State Leakage Current @ Rated Voltage [mArms]

Minimum Off-State dv/dt @ Maximum Rated Voltage [V/µsec] (2)

Maximum Load Current (3) [Arms]

Minimum Load Current [Arms]

Maximum 1 Cycle Surge Current (50/60) [Apk]

Maximum On-State Voltage Drop @ Rated Current [Vpk]

Thermal Resistance Junction to Case (Rjc) [°C/W]

Maximum I² t for Fusing 50/60Hz (1/2 cycle) [A² sec]

Minimum Power Factor (with Maximum Load)

25A

48-530

1200

500

0.15

239/250

1.6

1.02

285/259

0.5

50A

48-530

1200

500

0.15

597/625

1.6

0.63

1779/1621

0.5

75A

48-530

1200

500

0.25

954/1000

1.6

0.31

4555/4150

0.5

90A

48-530

1200

500

0.25

1145/1200

1.6

0.28

6560/5976

0.5

110A

48-530

1200

500

110

0.25

1432/1500

1.6

0.25

10249/9338

0.5

125A

48-530

1200

500

125

0.025

1670/1750

1.6

0.22

13950/12709

0.5
