BK/ABC-V-2-1/2

Description
Electric Fuse, Fast Blow, 2.5A, 250VAC, 125VDC, 100A (IR), Through Hole,
CategoryCircuit protection    Circuit protection
File Size85KB,2 Pages
ManufacturerEaton
Download Datasheet Parametric Compare View All

BK/ABC-V-2-1/2 Overview

Electric Fuse, Fast Blow, 2.5A, 250VAC, 125VDC, 100A (IR), Through Hole,

BK/ABC-V-2-1/2 Parametric

Parameter NameAttribute value
Is it lead-free?Contains lead
Is it Rohs certified?incompatible
MakerEaton
Reach Compliance Codecompliant
ECCN codeEAR99
Is SamacsysN
Other featuresINTERRUPTING CURRENT-MAX(DC): 10000 A; RESPONSE TIME: 120 SEC MAX AT 200% RATED CURRENT, SOURCE ERROR IN INTERRUPT RATING
Fusing characteristicsFAST
body height31.75 mm
Body length or diameter6.35 mm
Circuit protection typeELECTRIC FUSE
Installation featuresTHROUGH HOLE
method of packingBULK
physical size6.35mm x 31.75mm
Rated breaking capacity100 A
Rated current2.5 A
Rated voltage (AC)250 V
Rated voltage (DC)125 V
GuidelineCE
surface mountNO
Terminal shapePIN WIRE
Base Number Matches1
1/4" x 1-1/4" Fuses
ABC Series, Fast Acting, Ceramic Tube
Description
• Fast-acting, ceramic tube
• Optional leaded version available
• 1/4 x 1-1/4 (6.3mm x 32mm) physical size
• Ceramic tube, nickel-plated brass endcap construction
• UL Listed product meets standard 248-14
ELECTRICAL CHARACTERISTICS
% of Amp Rating
Opening Time
110%
4 Hours Minimum
135%
60 Minutes maximum
200%
120 Seconds Maximum
Approvals
• UL Listed Guide & File numbers (ABC 1/4 - 15A):
JDYX & E19180.
• UL Recognition Guide & File numbers (ABC 20 - 30A):
JDYX2 & E19180.
• CSA Certification Record No: 053787 C 000 &
Class No: 1422 01 & 1422 30.
Environmental Data
• Shock: 1/4A and 1/2A – MIL-STD-202,
Method 213, Test Condition I;
1A thru 30A – MIL-STD-202, Method 207,
(HI Shock)
• Vibration: 1/4A thru 30A – MIL-STD-202,
Method 204, Test Condition C (Except 5g, 500HZ)
Ordering
• Specify product code, option code and packaging code
Dimensions
(
mm
in
)
Drawing Not to Scale
SPECIFICATIONS
Product
Code
ABC-1/4
ABC-1/2
ABC-3/4
ABC-1
ABC-1-1/2
ABC-2
ABC-2-1/2
ABC-3
ABC-4
ABC-5
ABC-6
ABC-7
ABC-8
ABC-10
ABC-12
ABC-15
ABC-20
ABC-25
ABC-30
Voltage
Rating
AC
DC
250V
125V
250V
125V
250V
125V
250V
125V
250V
125V
250V
125V
250V
125V
250V
125V
250V
125V
250V
125V
250V
125V
250V
125V
250V
125V
250V
125V
250V
125V
250V
125V
250V
125V
125V
125V
125V
125V
AC Interrupting
Rating
250V
125V
35A
10000A
35A
10000A
35A
10000A
35A
10000A
100A
10000A
100A
10000A
100A
10000A
100A
10000A
200A
10000A
200A
10000A
200A
10000A
200A
10000A
200A
10000A
200A
10000A
750A
10000A
750A
10000A
400A
1000A
-
1000A
-
1000A
DC Interrupting
Rating
125V
75V
10000A
-
10000A
-
10000A
-
10000A
-
10000A
-
10000A
-
10000A
-
10000A
-
10000A
-
10000A
-
10000A
-
10000A
-
10000A
-
10000A
-
10000A
-
10000A
-
10000A
-
400A
1000A
400A
1000A
Typical DC Cold
Resistance**
(ohms)
3.000
0.788
0.303
0.197
0.1175
0.0755
0.05875
0.0435
0.02975
0.0286
0.02315
0.0183
0.0146
0.01205
0.0068
0.005425
0.00366
0.00263
0.002225
Typical
Melting I
2
t†
AC
0.02
0.19
0.8
1.4
2.9
4.2
8.53
19.5
29.1
16.4
31.6
73.2
111.9
215.6
129.6
200.2
550.8
839.3
1,429
Typical
Voltage
Drop‡
3.25
0.51
0.42
0.35
0.35
0.25
0.26
0.25
0.25
0.23
0.24
0.20
0.17
0.15
0.11
0.12
0.13
0.12
0.14
** DC Cold Resistance (Measured at
≤10%
of rated current)
† Typical Melting I
2
t (A
2
Sec) (I
2
t was measured at listed interrupting rating and rated voltage. Measured at 70% to 80% power factor on AC)
‡ Typical Voltage Drop (Voltage drop was measured at 25°C±3°C ambient temperature at rated current)
