HNN-01 Overview

DC-DC Regulated Power Supply Module, 1 Output, Hybrid

HNN-01 Parametric

Parameter Name	Attribute value
Maker	Taiyo Yuden
package instruction	,
Reach Compliance Code	unknown
ECCN code	EAR99
Is Samacsys	N
Analog Integrated Circuits - Other Types	DC-DC REGULATED POWER SUPPLY MODULE
Efficiency (main output)	70%
Maximum input voltage	5.5 V
Minimum input voltage	4.5 V
Nominal input voltage	5 V
JESD-30 code	R-XSMA-T6
Maximum grid adjustment rate	5%
Maximum load regulation	5%
Number of functions	1
Output times	1
Number of terminals	6
Maximum operating temperature	60 °C
Minimum operating temperature
Nominal output voltage	-24 V
Package body material	UNSPECIFIED
Package shape	RECTANGULAR
Package form	MICROELECTRONIC ASSEMBLY
Certification status	Not Qualified
surface mount	NO
technology	HYBRID
Temperature level	COMMERCIAL
Terminal form	THROUGH-HOLE
Terminal location	SINGLE
Fine-tuning/adjustable output	NO
Base Number Matches	1

Preview

Download Datasheet

View All

Xentek

Model

HN Series

+5 V Input

Fixed Output

Ultra-Compact

General Notes

Short Protection

High Efficiency

DC — DC Converters

On/Off Remote

DC/DC Converter Shuts Down After an

Output Based Short Circuit. Converter Starts

Up after Power (V

IN

) is Turned On and Off.

DC/DC Converter is Controlled by Remote

Physical Specifications

Dimensions:

Operating Temp:

Relative Humidity:

Storage:

13.5 mm x 35.0 mm x 4.3 mm

(0.531" x 1.38" x 0.169")

0 to 60 °C

20% to 90%, non-condensing

-20 to 180 °C/5-95% RH

Options

Active Hi

W/O Remote On-Off

Active Low

Electrical Characteristics*

Ordering

Code

(Vdc)

HNN-01

HNN-02

HNN-03

HNH-01

HNH-02

HNH-03

HNL-01

HNL-02

HNL-03

-24

-23

-22

-24

-23

-22

-24

-23

-22

4.5 - 5.5

0.0 - 20

±5%

Min. 70%

200

Active

|

4.5 - 5.5

0.0 - 20

±5%

Min. 70%

200

Active

{

4.5 - 5.5

0.0 - 20

±5%

Min. 70%

200

No

(Vdc)

Output Voltage

Input Voltage

Output

Current

(mA)

Min. Total

Regulation

y

Efficiency

z

Max. Output

Ripple Noise

(mVp-p)

x

On/Off

Remote

*Above Specifications Occur @ 25 ºC

Input-Side Capacitor = 47 µF/35 V. Output-Side Capacitor = LXF35VB27 (Nippon Cemicon Co. Ltd..) unless otherwise noted

x

y

z

{

|

Tester to Syncroscope (100 MHz)

Occurs at: Vin = 10 -25 V; Iout = 0.0 - 20 mA; Ta = 0.0 - 60 ºC

Occurs at: Iout = 0.0 - 30 mA

Occurs at: ‘H’ Level = On; ‘L’ Level = Off; H = 2.5 -5.5 V & L = 0.5 V Max.

Occurs at: ‘H’ Level = Off; ‘L’ Level = On; H = (Vin - 0.5 V) - OPEN & L = 0.0 - (Vin - 2.5 V)
