3. LEDs (Left / Right) : “G” = Green ; “Y” = Yellow ; “—” = None. For different LED color requirements, please contact
E&E Magnetic Products Limited.
4. Schematic H30G, H30Y H33D, K30Y, K33D are suitable for Auto MDI/MDIX applications.
,
5. Panel tabs are optional.
6. Operating temperature: -40
°
C to +85
°
C.
2/F Block A, 94 Tokwawan Road, Kowloon, Hong Kong
1
Tel: (852) 2765 3888
Fax: (852) 2954 3304
MJ004(06)
Revised in 06/07
E & E Magnetic Products Limited
10/100 Base-T Applications
Single Port, Through Hole, Tab Up
Zigzag Output Pins Pattern
M
ECHANICAL
D
IMENSIONS
MJ11U-01A
0.450
11.43 0.350
0.100 8.89
2.54 0.050
Chip side
C
0.050 1.27
1.27 0.100
2.54
7 5 3 1
8 6 4 2
R
U
R
US
(E&E P/N)
(DATE)
0.035
0.89
0.062
2X DIA:
1.57
DIA: 0.126
2X
3.20
DIA: 0.042
4X
1.07
8X DIA:
11
12
9
10
0.250
6.35 0.180
0.100 4.57
2.54 0.120
3.05
NOTE 5
Cable side
LED (LEFT)
0.640
MAX.
16.26
0.534
13.56
0.620
15.75
Recommended hole pattern
viewed from component side
0.855
MAX.
21.72
LED (RIGHT)
0.555
MAX.
14.10
REFERENCE OR
GAUGE PLANE
J8
J1
0.425
10.80
0.125
3.18
MJ11U-01B
0.450
11.43 0.350
0.100 8.89
2.54 0.050
Chip side
C
0.050 1.27
1.27 0.100
2.54
7 5 3 1
8 6 4 2
R
U
R
US
(E&E P/N)
(DATE)
0.035
0.89
0.062
2X DIA:
1.57
DIA: 0.126
2X
3.20
8X DIA:
0.250
6.35 0.120
3.05
NOTE 5
Cable side
0.620
15.75
Recommended hole pattern
viewed from component side
0.855
MAX.
21.72
0.640
MAX.
16.26
0.555
MAX.
14.10
REFERENCE OR
GAUGE PLANE
J8
J1
0.425
10.80
0.125
3.18
All dimensions are specified in inch with higher precedence in inch.
mm
0.010 .
Unless otherwise specified, all tolerances are
0.25
2/F Block A, 94 Tokwawan Road, Kowloon, Hong Kong
2
Tel: (852) 2765 3888
Fax: (852) 2954 3304
MJ004(06)
Revised in 06/07
E & E Magnetic Products Limited
10/100 Base-T Applications
Single Port, Through Hole, Tab Up
Zigzag Output Pins Pattern
S
CHEMATICS
H301
Shield
Primary
1
2
3
4
5
6
7
8
1CT:1
Secondary
J1
J2
Tx-Side
1CT:1CT
J3
J4
J5
J6
J7
J8
RJ-45
Chip Side
1000pF/2000V
Rx-Side
75Ω
75Ω
75Ω
75Ω
RJ-45
Cable Side
H30G
Shield
1000pF/2000V
75Ω
75Ω
75Ω
75Ω
Primary
1
2
3
4
5
6
7
8
1CT:1CT
Secondary
J1
J2
J3
J4
J5
J6
J7
J8
Tx-Side
1CT:1CT
Rx-Side
RJ-45
Chip Side
RJ-45
Cable Side
H30H
Shield
1000pF/2000V
75Ω
75Ω
75Ω
75Ω
Primary
1
2
3
4
5
6
7
8
1CT:1
Secondary
J1
J2
J3
J4
J5
J6
J7
J8
Tx-Side
1CT:1CT
Rx-Side
RJ-45
Chip Side
RJ-45
Cable Side
2/F Block A, 94 Tokwawan Road, Kowloon, Hong Kong
3
Tel: (852) 2765 3888
Fax: (852) 2954 3304
MJ004(06)
Revised in 06/07
E & E Magnetic Products Limited
10/100 Base-T Applications
Single Port, Through Hole, Tab Up
Zigzag Output Pins Pattern
S
CHEMATICS
H30Y / K30Y
Shield
Primary
1
2
3
4
5
6
7
8
Secondary
1CT:1CT
Tx-Side
1CT:1CT
J1
J2
J3
J4
J5
J6
J7
J8
RJ-45
Chip Side
1000pF/2000V
Rx-Side
75Ω
75Ω
75Ω
75Ω
RJ-45
Cable Side
H33D / K33D
Shield
Primary
1
2
3
4
5
6
7
8
Secondary
1CT:1CT
Tx-Side
1CT:1CT
J1
J2
J3
J4
J5
J6
J7
J8
RJ-45
Chip Side
Rx-Side
75Ω
1000pF/2000V
75Ω
75Ω
75Ω
RJ-45
Cable Side
H701
Shield
Primary
1
2
3
4
5
6
7
8
1CT:1.41
Secondary
J1
J2
J3
J4
J5
J6
J7
J8
Tx-Side
1CT:1CT
RJ-45
Chip Side
1000pF/2000V
Rx-Side
75Ω
75Ω
75Ω
75Ω
RJ-45
Cable Side
2/F Block A, 94 Tokwawan Road, Kowloon, Hong Kong
4
Tel: (852) 2765 3888
Fax: (852) 2954 3304
MJ004(06)
Revised in 06/07
E & E Magnetic Products Limited
10/100 Base-T Applications
Single Port, Through Hole, Tab Up
Zigzag Output Pins Pattern
LED (LEFT)
LED (RIGHT)
COLOR
POLARITY
PIN 9
PIN 10
LED
S
C
OLOR
A
ND
P
OLARITY
MJ11U-01A
COLOR
POLARITY
PIN 11
PIN 12
LED (RIGHT)
9
10
GREEN
YELLOW
LED (LEFT)
11
12
LED S
PECIFICATION
@25°C, F
ORWARD
C
URRENT
= 20mA
Standard Color
Green
Yellow
Typical Wavelength (nm)
565
590
Forward Voltage (volt)
Typical
2.2
2.1
Maximum
2.5
2.5
M
ATERIALS
Housing
Contact Pins
PCB Pins
7
Consist of thermoset & thermoplastic materials, all of them are UL 94-V0 rated.
Phosphor bronze, plated with nickel under-plating and hard gold over contact area.
Copper wire which meets solderability requirements per MIL-STD-202, method 208.
Notes:
7. All parts shown in this datasheet have gold plating thickness of 10 micro-inch (min.) over contact area.
Advance options including 30 micro-inch (min.) and 50 micro-inch (min.) are also available.
FOR MORE INFORMATION, PLEASE CONTACT
HEADQUARTER
2/F Block A, Merit Industrial Centre,
94 Tokwawan Road, Kowloon,
Hong Kong
Tel: (852) 2765 3888
Fax: (852) 2954 3304
Email: eempl@eleceltek.com
Website: http://www.eleceltek.com
