Power Inductors - Shielded
ctparts.com
CTMP2A Series
From .47 µH to 100 µH
Part
Number
CTMP2A_-R47
CTMP2A_-R68
Not shown at actual size.
CTMP2A_-1R0
CTMP2A_-1R5
CTMP2A_-2R2
CTMP2A_-3R3
CTMP2A_-4R7
CTMP2A_-6R8
CTMP2A_-8R2
CTMP2A_-100
CTMP2A_-150
CTMP2A_-220
CTMP2A_-330
CTMP2A_-470
CTMP2A_-680
CTMP2A_-820
CTMP2A_-101
SPECIFICATIONS
Parts are available in ±20% tolerance only.
CTMP2AF
Please specify “F” for RoHS compliant
L Test
Freq.
(kHz)
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
DCR
@20°C
Ω
(Ω Max.)
0.024
0.027
0.067
0.073
0.086
0.098
0.117
0.136
0.167
0.179
0.217
0.311
0.476
0.727
1.108
1.463
2.015
Isat
Peak
(Adc)
5.8
4.83
3.63
3.22
2.64
2.23
1.81
1.53
1.54
1.42
1.16
0.97
0.79
0.66
0.54
0.50
0.45
Inductance
(µH)
.47
.68
1.0
1.5
2.2
3.3
4.7
6.8
8.2
10
15
22
33
47
68
82
100
OCL
(µH±20%)
0.47
0.68
1.21
1.54
2.30
3.21
4.86
6.85
8.54
10.02
15.18
21.40
32.74
46.48
68.53
81.15
99.65
Compliant
Available
RoHS
CHARACTERISTICS
Description:
SMD Low Profile Power Inductors
Applications:
Wireless and hand-held equipment applications
such as PC cards, cellular telephones, pagers, GPS, and disk
drives.
Operating Temperature:
-40°C to +85°C
Storage Temperature:
-40°C to +125°C
Testing:
Inductance & Q is tested on an HP4284A at specified
frequency.
OCL Test Parameters:
100KHz, 0.25 Vrms, 0.0 Adc
Packaging:
Bulk pack
Marking:
Marked with inductance code
Miscellaneous:
RoHS Compliant available.
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
PHYSICAL DIMENSIONS
Size
mm
inches
A
Max.
5.88
0.231
B
Max.
7.50
0.295
C
Max.
1.8
0.071
D
Max.
5.2
0.205
E
1.6
0.063
PAD LAYOUT
08.29.06
Technologies
Manufacturer of Inductors, Chokes, Coils, Beads, Transformers & Toroids
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2006 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
