PZT2369-T datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> The transistor> PZT2369-T

PZT2369-T: DescriptionTRANSISTOR 500 mA, 15 V, NPN, Si, SMALL SIGNAL TRANSISTOR, BIP General Purpose Small Signal; CategoryDiscrete semiconductor The transistor; File Size76KB，2 Pages; ManufacturerNXP; Websitehttps://www.nxp.com

Download Datasheet Parametric Compare View All

PZT2369-T Overview

TRANSISTOR 500 mA, 15 V, NPN, Si, SMALL SIGNAL TRANSISTOR, BIP General Purpose Small Signal

PZT2369-T Parametric

Parameter Name	Attribute value
Maker	NXP
package instruction	SMALL OUTLINE, R-PDSO-G4
Reach Compliance Code	unknown
ECCN code	EAR99
Is Samacsys	N
Maximum collector current (IC)	0.5 A
Collector-emitter maximum voltage	15 V
Configuration	SINGLE
Minimum DC current gain (hFE)	40
JESD-30 code	R-PDSO-G4
Number of components	1
Number of terminals	4
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Polarity/channel type	NPN
Certification status	Not Qualified
surface mount	YES
Terminal form	GULL WING
Terminal location	DUAL
transistor applications	SWITCHING
Transistor component materials	SILICON
Nominal transition frequency (fT)	500 MHz
Maximum off time (toff)	18 ns
Base Number Matches	1

Preview

Download Datasheet

View All

PZT2369-T Related Products

	PZT2369-T	BSW65/PH	BSX49	BSY63	BSY18	BSY34	PZT2369	BSX49/PH
Description	TRANSISTOR 500 mA, 15 V, NPN, Si, SMALL SIGNAL TRANSISTOR, BIP General Purpose Small Signal	TRANSISTOR 1000 mA, 80 V, NPN, Si, SMALL SIGNAL TRANSISTOR, TO-39, BIP General Purpose Small Signal	TRANSISTOR 600 mA, 40 V, NPN, Si, SMALL SIGNAL TRANSISTOR, TO-18, BIP General Purpose Small Signal	TRANSISTOR 200 mA, 15 V, NPN, Si, SMALL SIGNAL TRANSISTOR, TO-39, BIP General Purpose Small Signal	TRANSISTOR 200 mA, 12 V, NPN, Si, SMALL SIGNAL TRANSISTOR, TO-39, BIP General Purpose Small Signal	TRANSISTOR 0.6 A, 40 V, NPN, Si, POWER TRANSISTOR, TO-39, BIP General Purpose Power	TRANSISTOR 500 mA, 15 V, NPN, Si, SMALL SIGNAL TRANSISTOR, BIP General Purpose Small Signal	TRANSISTOR 0.6 A, 40 V, NPN, Si, POWER TRANSISTOR, TO-18, BIP General Purpose Power
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown	unknown	unknown	unknown
ECCN code	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99
Maximum collector current (IC)	0.5 A	1 A	0.6 A	0.2 A	0.2 A	0.6 A	0.5 A	0.6 A
Collector-emitter maximum voltage	15 V	80 V	40 V	15 V	12 V	40 V	15 V	40 V
Configuration	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE
Minimum DC current gain (hFE)	40	30	25	30	40	25	40	25
JESD-30 code	R-PDSO-G4	O-MBCY-W3	O-MBCY-W3	O-MBCY-W3	O-MBCY-W3	O-MBCY-W3	R-PDSO-G4	O-MBCY-W3
Number of components	1	1	1	1	1	1	1	1
Number of terminals	4	3	3	3	3	3	4	3
Package body material	PLASTIC/EPOXY	METAL	METAL	METAL	METAL	METAL	PLASTIC/EPOXY	METAL
Package shape	RECTANGULAR	ROUND	ROUND	ROUND	ROUND	ROUND	RECTANGULAR	ROUND
Package form	SMALL OUTLINE	CYLINDRICAL	CYLINDRICAL	CYLINDRICAL	CYLINDRICAL	CYLINDRICAL	SMALL OUTLINE	CYLINDRICAL
Polarity/channel type	NPN	NPN	NPN	NPN	NPN	NPN	NPN	NPN
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
surface mount	YES	NO	NO	NO	NO	NO	YES	NO
Terminal form	GULL WING	WIRE	WIRE	WIRE	WIRE	WIRE	GULL WING	WIRE
Terminal location	DUAL	BOTTOM	BOTTOM	BOTTOM	BOTTOM	BOTTOM	DUAL	BOTTOM
transistor applications	SWITCHING	SWITCHING	SWITCHING	SWITCHING	SWITCHING	SWITCHING	SWITCHING	SWITCHING
Transistor component materials	SILICON	SILICON	SILICON	SILICON	SILICON	SILICON	SILICON	SILICON
Nominal transition frequency (fT)	500 MHz	80 MHz	400 MHz	300 MHz	280 MHz	250 MHz	500 MHz	250 MHz
Maker	NXP	-	-	NXP	NXP	NXP	NXP	NXP
package instruction	SMALL OUTLINE, R-PDSO-G4	CYLINDRICAL, O-MBCY-W3	CYLINDRICAL, O-MBCY-W3	CYLINDRICAL, O-MBCY-W3	CYLINDRICAL, O-MBCY-W3	-	SMALL OUTLINE, R-PDSO-G4	-
JEDEC-95 code	-	TO-39	TO-18	TO-39	TO-39	TO-39	-	TO-18
