SPECIFICATIONS
MECHANICAL
Output Waveform
HC12 (25PPR)
TYPE
Supply Voltage
Current
Output
Voltage
1
12 VDC
±10%
5
5 VDC
±10%
D
5 VDC
±10%
2
24 VDC
±10%
60mA max 80mA max 150mA max 30mA max
H
L
≥
4.0V
Vcc -0.5V
≥
2.0V
1. Max Shaft Load: radial: 2 kgf
axial: 2 kgf
2. Torque: 160 - 320 gf•cm (Pulse Wheel)
50 - 150 gf•cm (Switches)
3. Life: 10
6
cycles (Pulse Wheel)
50,000 cycles (Switches)
Sig A
Sig B
Detent Stop
≤
0.4V
(Selector switches) 25V max, 0.4VA max
100PPR
1000Hz
73.0
31.0
ENVIRONMENTAL
1.
2.
3.
4.
5.
Operating Temp: -10° to +60° C
Storage Temp: -40° to +70° C
Humidity:
≤85%
RH, no condensation
Vibration: 10~55 Hz, 1.5 mm, 2 hrs
Shock: 50G, 11ms, 3 axes, 3 reps
Contact Rating
Resolution
Freq. Response
HC11 (100PPR)
Sig A
26.0
Sig B
Detent Stop
X
OFF
Y
Z
4
X1 X10 X100
Ordering Information
HC1
Resolution:
1 = 100PPR
2 = 25PPR
Input:
1 = 12V
5 = 5V
D = 5V (Differential)
2 = 24V
Axis Selector Switch
A = OFF X Y Z 4
B = OFF X Y Z 4 5
C = OFF X Y Z 4 5 6
D = OFF X Y Z 4 5 6 7
E = OFF X Y Z 4 5 6 7 8
F = OFF X Y
G = OFF X Y Z
H=
J =
K=
L =
M=
N=
P=
Coil Cord:
0 = None
1 = 2M Cord
2 = 3M Cord
3 = 5M Cord
4 = 4M Cord
Knob:
C = Blank
XY
D = Custom Logo
XY Z
XY Z 4
XY Z 4 5
XY Z 4 5 6
XY Z 4 5 6 7
XY Z 4 5 6 7 8
Connectors:
0 = None
1 = One end
2 = Both ends
3 = Custom
0
30
20
124.0
80
70
10
90
C U I Stack, Inc.
9615 SW Allen Blvd. #103
Beaverton, OR 97005
Tel: 503/643-4899 FAX: 503/643-6129
DRAWN BY
UPDATED
CHECKED
RELEASED
©
C U I Stack, Inc.,
1997
60
50
40
PART NO.
REV.
HC1XXXXXX
A
Talking
