HCF4510M013TR: Description4000/14000/40000 SERIES, SYN POSITIVE EDGE TRIGGERED 4-BIT BIDIRECTIONAL DECADE COUNTER, PDSO16, MICRO, PLASTIC, SOP-16; Categorylogic logic; File Size136KB，12 Pages; ManufacturerSTMicroelectronics; Websitehttp://www.st.com/; Environmental Compliance

Download Datasheet Parametric View All

HCF4510M013TR Overview

4000/14000/40000 SERIES, SYN POSITIVE EDGE TRIGGERED 4-BIT BIDIRECTIONAL DECADE COUNTER, PDSO16, MICRO, PLASTIC, SOP-16

HCF4510M013TR Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	STMicroelectronics
Parts packaging code	SOIC
package instruction	MICRO, PLASTIC, SOP-16
Contacts	16
Reach Compliance Code	compliant
Is Samacsys	N
Counting direction	BIDIRECTIONAL
series	4000/14000/40000
JESD-30 code	R-PDSO-G16
JESD-609 code	e4
length	9.9 mm
Load capacitance (CL)	50 pF
Load/preset input	YES
Logic integrated circuit type	DECADE COUNTER
Maximum Frequency@Nom-Sup	2000000 Hz
Operating mode	SYNCHRONOUS
Number of digits	4
Number of functions	1
Number of terminals	16
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Encapsulate equivalent code	SOP16,.25
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
method of packing	TAPE AND REEL
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
power supply	5/15 V
propagation delay (tpd)	400 ns
Certification status	Not Qualified
Maximum seat height	1.75 mm
Maximum supply voltage (Vsup)	15 V
Minimum supply voltage (Vsup)	3 V
Nominal supply voltage (Vsup)	5 V
surface mount	YES
technology	CMOS
Temperature level	INDUSTRIAL
Terminal surface	Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Trigger type	POSITIVE EDGE
width	3.9 mm
minfmax	5.5 MHz
Base Number Matches	1

Preview

Download Datasheet

View All

HCF4510B

HCF4516B

PRESETTABLE UP/DOWN COUNTERS

MEDIUM SPEED OPERATION f

= 8MHz

TYP. AT 10V

SYNCHRONOUS INTERNAL CARRY

PROPAGATION

RESET AND PRESET CAPABILITY

QUIESCENT CURRENT SPECIFIED TO 15V

5V, 10V, AND 15V PARAMETRIC RATINGS

INPUT CURRENT OF 100nAAT 15V AND 25°C

100% TESTED FOR QUIESCENT CURRENT

MEETS ALL REQUIREMENTS OF JEDEC

TENTATIVE STANDARD No. 13A, ”STANDARD

SPECIFICATIONS FOR DESCRIPTION OF ”B”

SERIES CMOS DEVICES”

DIP

ORDER CODES

PACKAGE

DIP

SOP

TUBE

HCF45XXBEY

HCF45XXBM1

SOP

T& R

HCF45XXM013TR

DESCRIPTION

The HCF4510B and HCF4516B are monolithic

integrated circuits available in 16-lead dual in-line

plastic and plastic micro package. The

HCF4510B Presettable BCD Up/Down Counter

and the HCF4516B Presettable Binary Up/Down

Counter consist of four synchronously clocked

D-type flip-flops (with a gating structure to provide

T-type flip-flop capability) connected as counters.

These counters can be cleared by a high level on

the RESET line, and can be preset to any binary

number present on the jam inputs by a high level

on the PRESET ENABLE line. The HCF4510B

will count out of non-BCD counter states in a

maximum of two clock pulses in the up mode,

PIN CONNECTION

and a maximum of four clock pulses in the down

mode. If the CARRY-IN input is held low, the

counter advances up or down on each

positive-going clock transition. Synchronous

cascading is accomplished by connecting all

clock inputs in parallel and connecting the

CARRY-OUT of a less significant stage to the

CARRY-IN of a more significant stage. The

HCF4510B and HCF4516B can be loaded in the

ripple mode by connecting the CARRY-OUT to

the clock of the next stage. If the UP/DOWN input

changes during a terminal count, the

CARRY-OUT must be gated with the clock, and

the UP/DOWN input must change while the clock

is high. This method provides a clean clock signal

to the subsequent counting stage.

March 2000

1/12
