A19-1/SMA19-1
10 TO 1000 MHz
CASCADABLE AMPLIFIER
· HIGH OUTPUT POWER: +22.5 dBm (TYP.)
· HIGH THIRD ORDER I.P.: +35 dBm (TYP.)
· MEDIUM NOISE FIGURE: 6.0 dB (TYP.)
Typical Performance @ 25°C
Specifications (Rev. Date: 11/00)*
Characteristics
Frequency
Small Signal Gain (min.)
Gain Flatness (max.)
Reverse Isolation
Noise Figure (max.)
Power Output @ 1 dB comp. (min.)
IP3
IP2
Second Order Harmonic IP
VSWR Input / Output (max.)
DC Current @ 15 Volts (max.)
Typical
0° to 50°C
°
°
Guaranteed
-54° to +85°C
°
°
0.0-1.1 GHz
11.5 dB
±0.2 dB
16 dB
5.5 dB
22.5 dBm
+35 dBm
+51 dBm
+58 dBm
1.5:1 / 1.5:1
90 mA
0.0-1.0 GHz
10.5 dB
±0.6 dB
6.5 dB
20.5 dBm
0.0-1.0 GHz
10.0 dB
±0.8 dB
7.0 dB
20.0 dBm
1.7:1 / 1.7:1
94 mA
2.0:1 / 2.0:1
99 mA
* Measured in a 50-ohm system at +15 Vdc Nominal. Subject to change without notice.
Absolute Maximum Ratings
Storage Temperature
Max. Case Temperature
Max. DC Voltage
Max. Continuous RF Input Power
Max. Short Term RF Input Power (1 minute max.)
Max. Peak Power (3
µsec
max.)
“S” Series Burn-in Temperature (Case)
-62° to +125°C
125°C
+17 Volts
+13 dBm
100 mW
0.5 W
125°C
Thermal Data: V
cc
= 15 Vdc
Thermal Resistance
θ
jc
Transistor Power Dissipation P
d
Junction Temperature Rise Above Case T
jc
100°C/W
0.907 W
91°C
Outline Drawings
Package
Figure
Model
TO-8
BG
A19-1
Surface Mount
AA
SMA19-1
SMA Connectorized
CE
CA19-1
Specifications subject to change without notice.
•
North America: 1-800-366-2266
Visit www.macom.com for complete contact and product information.
