J507
Current Regulator Diode
Linear Systems replaces discontinued Siliconix J507
The Linear Systems J507 is a ± 20% range current regulator
The J507 is a ±20% range current regulator designed
for demanding applications in test equipment and
instrumentation. The J507 utilizes JFET techniques to
produce a single two-leaded device which is extremely
simple to operate.
•
•
•
•
•
•
•
•
Two-Lead Plastic Package
Guaranteed ±20% Tolerance
Operation up to 50V
Excellent Temperature Stability
Simple Series Circuitry, No Separate Voltage
Source
Tight Guaranteed Circuit Performance
Excellent Performance in Low-Voltage/Battery
Circuits and High-Voltage Spike Protection
High Circuit Stability vs. Temperature.
FEATURES
REPLACEMENT SECOND SOURCE FOR SILICONIX J507
WIDE CURRENT RANGE
1.80mA ± 20%
BIASING NOT REQUIRED
V
GS
= 0V
1
ABSOLUTE MAXIMUM RATINGS
@ 25°C (unless otherwise noted)
Maximum Temperatures
Storage Temperature
Operating Junction Temperature
Maximum Power Dissipation
Continuous Power Dissipation @ 125°C
Maximum Currents
Forward Current
Reverse Current
Maximum Voltages
Peak Operating Voltage
‐55°C to +150°C
‐55°C to +135°C
360mW
20mA
50mA
P
OV
= 50V
J507 Applications:
•
•
•
Constant-Current Supply
Current-Limiting
Timing Circuits
ELECTRICAL CHARACTERISTICS @ 25°C (unless otherwise noted)
SYMBOL
CHARACTERISTICS
MIN.
TYP.
MAX.
UNITS
2
P
OV
Peak Operating Voltage
50
‐‐
‐‐
V
V
R
Reverse Voltage
‐‐
0.8
‐‐
V
C
F
Forward Capacitance
‐‐
2.2
‐‐
pF
SPECIFIC ELECTRICAL CHARACTERISTICS @ 25°C (unless otherwise noted)
FORWARD CURRENT
3
DYNAMIC IMPEDANCE
4
PART
I
F
Z
d
V
F
= 25V
NOM
1.80
V
F
= 25V
Click To Buy
MIN
1.44
MAX
2.16
MIN
0.20
TYP
1
KNEE
IMPEDANCE
Z
K
V
F
= 6V
TYP
0.19
CONDITIONS
I
F
= 1.1 I
F(MAX)
I
R
= 1mA
V
F
= 25V, f = 1MHz
5
LIMITING VOLTAGE
V
L
J507
I
F
= 0.8 I
F(MIN)
TYP
MAX
2.8
1.3
Notes:
1. Absolute Maximum ratings are limiting values above which serviceability may be impaired
2. Pulsed, t = 2ms. Maximum V
F
where
I
F
< 1.1 I
F(MAX)
3. Pulsed, t = 2ms. Continuous currents may vary.
4. Pulsed, t = 2ms. Continuous impedances may vary.
5. Min V
F
required to ensure
I
F
= 0.8 I
F(MIN)
Available Packages:
J507 in TO-92
J507 available as bare die
Please contact Micross for full package and die dimensions:
Email:
chipcomponents@micross.com
Web:
www.micross.com/distribution.aspx
Information furnished by Linear Integrated Systems and Micross Components is believed to be accurate and reliable. However, no responsibility is assumed for its use; nor for any infringement of patents or
other rights of third parties which may result from its use. No license is granted by implication or otherwise under any patent or patent rights of Linear Integrated Systems.
