PX1004-1
•
•
•
•
•
Low Insertion Loss
Excellent Selectivity
Hermetic 13.3 X 6.5 mm Surface-mount Case
Single-ended Input and Output
Complies with Directive 2002/95/EC (RoHS)
82.2 MHz
SAW Filter
Pb
Value
+10
30
-40 to +85
260°C for 30 s
Units
dBm
VDC
°C
Absolute Maximum Ratings
Rating
Maximum Incident Power in Passband
Maximum DC Voltage Between any 2 Terminals
Storage Temperature Range
Suitable for Lead-free Soldering - Maximum Soldering Profile
SM13365-12
Electrical Characteristics
Characteristic
Nominal Center Frequency
Passband
Insertion Loss at fc
3 dB Passband
Amplitude Ripple over fc ±15 kHz
Group Delay Variation over fc ±17 kHz
Third-Order Intermod. for -20 dBm tones at fc ±100 & 200 kHz
Rejection
fc ±100 kHz
fc -1500 kHz to fc -1600 kHz
Ultimate
Operating Temperature Range
Impedance Matching to 50
Ω
unbalanced
Case Style
Lid Symbolization (YY=year, WW=week) See note 4
T
A
1
-20
External L-C
SM13365-12 13.3 X 6.5 mm Nominal Footprint
RFM PX1004-1 YYWW
1, 2, 3
11
65
65
+70
°C
16
dB
GDV
Sym
f
C
IL
BW
3
1, 2
Notes
1
±25
Min
Typ
82.20
3.0
±42
1.0
6.0
-95
Max
5.5
Units
MHz
dB
kHz
dB
P-P
µs
P-P
dBm
Electrical Connections
Connection
Port 1Hot
Port 1 Gnd Return
Port 2 Hot
Port 2 Gnd Return
Case Ground
Terminals
2
3
8
9
All Others
Notes:
1.
Unless noted otherwise, all specifications apply over the operating temperature
range with filter soldered to the specified demonstration board with impedance
matching to 50
Ω
and measured with 50
Ω
network analyzer.
Unless noted otherwise, all frequency specifications are referenced to the nom-
inal center frequency, fc.
Rejection is measured as attenuation below the minimum IL point in the pass-
band. Rejection in final user application is dependent on PCB layout and exter-
nal impedance matching design. See Application Note No. 42 for details.
"LRIP" or "L" after the part number indicates "low rate initial production" and
"ENG" or "E" indicates "engineering prototypes."
The design, manufacturing process, and specifications of this filter are subject
to change.
6.
Either Port 1 or Port 2 may be used for either input or output in the design.
However, impedances and impedance matching may vary between Port 1 and
Port 2, so that the filter must always be installed in one direction per the circuit
design.
US and international patents may apply.
RFM, stylized RFM logo, and RF Monolithics, Inc. are registered trademarks of
RF Monolithics, Inc.
Electrostatic Sensitive Device. Observe precautions for handling.
2.
3.
7.
8.
9.
4.
5.
www.RFM.com E-mail: info@rfm.com
©2010 by RF Monolithics, Inc.
Page 1 of 5
PX1004-1 - 7/6/10
