MBA/SMA 0204, MBB/SMA 0207, MBE/SMA 0414 - Precision
Vishay Beyschlag
Precision Thin Film Leaded Resistors
FEATURES
•
•
•
•
•
•
•
•
Approved according to EN 140101-806
Advanced thin film technology
Low TCR: ± 15 ppm/K to ± 25 ppm/K
Precision tolerance of value:
± 0.1 % and ± 0.25 %
Superior overall stability: Class 0.05
Wide precision range: 10
Ω
to 1.5 MΩ
Lead (Pb)-free solder contacts
Pure tin plating provides compatibility with lead (Pb)-free
and lead containing soldering processes
Compliant to RoHS directive 2002/95/EC
DESCRIPTION
MBA/SMA 0204, MBB/SMA 0207 and MBE/SMA 0414
precision leaded thin film resistors combine the proven
reliability of the professional products with an advanced level
of precision and stability. Therefore they are perfectly suited
for applications in the fields of test and measuring equipment
along with industrial and medical electronics.
•
APPLICATIONS
•
Test and measuring equipment
•
Industrial electronics
•
Medical electronics
METRIC SIZE
DIN
CECC
0204
A
0207
B
0414
D
TECHNICAL SPECIFICATIONS
DESCRIPTION
CECC Size
Resistance Range
Resistance Tolerance
Temperature Coefficient
Operation Mode
Climatic Category (LCT/UCT/Days)
Rated Dissipation,
P
70
Operating Voltage,
U
max.
AC/DC
Film Temperature
Max. Resistance Change at
P
70
for
Resistance Range,
ΔR/R
max., After:
1000 h
8000 h
225 000 h
Permissible Voltage Against Ambient
(Insulation):
1 Minute;
U
ins
Continuous
Failure Rate: FIT
observed
300 V
75 V
500 V
75 V
≤
0.1 x 10
-9
/h
800 V
75 V
85
°C
Precision
10/85/56
0.07 W
200 V
125
°C
85
°C
Standard
55/125/56
0.25 W
MBA/SMA 0204
A
22
Ω
to 332 kΩ; 0
Ω
MBB/SMA 0207
B
10
Ω
to 1 MΩ
± 0.25 %; ± 0.1 %
± 25 ppm/K; ± 15 ppm/K
Precision
10/85/56
0.11 W
350 V
125
°C
85
°C
Standard
55/125/56
0.40 W
Precision
10/85/56
0.17 W
500 V
125
°C
Standard
55/125/56
0.65 W
MBE/SMA 0414
D
22
Ω
to 1.5 MΩ
100
Ω
to 100 kΩ
≤
0.05 %
≤
0.1 %
≤
0.3 %
≤
0.25 %
≤
0.5 %
≤
1.5 %
100
Ω
to 270 kΩ
≤
0.03 %
≤
0.1 %
≤
0.3 %
≤
0.15 %
≤
0.5 %
≤
1.5 %
100
Ω
to 470 kΩ
≤
0.05 %
≤
0.1 %
≤
0.3 %
≤
0.25 %
≤
0.5 %
≤
1.5 %
Notes
• MB_ series has been merged with the related SMA series to form one series “MB_/SMA__”
• These resistors do not feature a limited lifetime when operated within the permissible limits. However, resistance value drift increasing over
operating time may result in exceeding a limit acceptable to the specific application, thereby establishing a functional lifetime.
www.vishay.com
72
For technical questions, contact:
filmresistorsleaded@vishay.com
Document Number: 28767
Revision: 26-Jul-10
MBA/SMA 0204, MBB/SMA 0207, MBE/SMA 0414 - Precision
Precision Thin Film Leaded Resistors
Vishay Beyschlag
(1)
PART NUMBER AND PRODUCT DESCRIPTION - CECC APPROVED PRODUCTS
PART NUMBER: MBB0207VD1001BCT00
M
MODEL/SIZE
B
B
0
2
0
7
V
D
1
0
0
1
B
C
T
0
0
SPECIAL
VARIANT
V
= CECC 06
N
= RB Radial
5 mm for
MBB/SMA0207
S
= UB Radial
2.5 mm for
MBB/SMA0207
TCR/MATERIAL
E
= ± 15 ppm/K
D
= ± 25 ppm/K
VALUE
3 digit value
1 digit multiplier
MULTIPLIER
8
= *10
-2
2
= *10
2
9
= *10
-1
3
= *10
3
0
= *10
0
4
= *10
4
1
= *10
1
5
= *10
5
TOLERANCE
B
= ± 0.1 %
C
= ± 0.25 %
PACKAGING
(2)
CT
C1
RP
R2
N4
MBA0204
=
MBA/SMA 0204
MBB0207
=
MBB/SMA 0207
MBE0414
=
MBE/SMA 0414
00
= Standard
L0
= Welding joint
not lacquered for
MBB/SMA 0207
KL
= Lacquered
welding joint for
MBA/SMA 0204
PRODUCT DESCRIPTION: MBB/SMA 0207-25 0.1 % CECC 06 CT 1K0
MBB/SMA 0207
MODEL/SIZE
MBA/SMA 0204
MBB/SMA 0207
MBE/SMA 0414
-
25
TCR
±
15
ppm/K
±
25
ppm/K
0.1 %
TOLERANCE
±
0.1
%
±
0.25
%
CECC 06
VARIANT
CECC 06
CECC 06 L0
CECC 06 KL
CT
PACKAGING
(2)
CT
C1
RP
R2
N4
1K0
RESISTANCE
1K0
= 1 kΩ
51R1
= 51.1
Ω
TEMPERATURE COEFFICIENT AND RESISTANCE RANGE - CECC APPROVED PRODUCTS
DESCRIPTION
TCR
TOLERANCE
± 0.25 %
± 25 ppm/K
± 0.1 %
± 0.25 %
± 15 ppm/K
± 0.1 %
43
Ω
to 221 kΩ
10
Ω
to 1 MΩ
43
Ω
to 1 MΩ
43
Ω
to 332 kΩ
22
Ω
to 221 kΩ
10
Ω
to 1 MΩ
10
Ω
to 1 MΩ
43
Ω
to 1 MΩ
22
Ω
to 1 MΩ
MBA/SMA 0204
22
Ω
to 332 kΩ
RESISTANCE VALUE
(3)
MBB/SMA 0207
(4)
10
Ω
to 1 MΩ
MBE/SMA 0414
22
Ω
to 1.5 MΩ
(1)
Notes
(1)
Approval is according to EN 140101-806, version A
(2)
Please refer to table PACKAGING for complete information
(3)
Resistance values to be selected from E96 and E192 series, for other values please contact factory
(4)
MBB/SMA 0207: Ohmic range 10
≤
R < 22R for 0.25 % tolerance and 10
≤
R < 43R for 0.1 % tolerance can not be qualified according to CECC
so these can only be ordered with variant = 0
• Resistance ranges printed in bold are preferred TCR/tolerance combinations with optimized availability
• The PART NUMBER shown above is to facilitate the unified part numbering system for ordering products
• Radial version (RB, UB) can not be qualified according to CECC so these can only be ordered with variant N or S
Document Number: 28767
Revision: 26-Jul-10
For technical questions, contact:
filmresistorsleaded@vishay.com
www.vishay.com
73
MBA/SMA 0204, MBB/SMA 0207, MBE/SMA 0414 - Precision
Vishay Beyschlag
DESCRIPTION
Production is strictly controlled and follows an extensive
set of instructions established for reproducibility. A
homogeneous film of metal alloy is deposited on a high grade
ceramic body and conditioned to achieve the desired
temperature coefficient. Plated steel termination caps are
firmly pressed on the metallized rods. A special laser is used
to achieve the target value by smoothly cutting a helical
groove in the resistive layer without damaging the ceramics.
A further conditioning is applied in order to stabilise the
trimming result. Connecting wires of electrolytic copper
plated with 100 pure tin are welded to the termination caps.
The resistors are covered by protective coating designed for
electrical, mechanical and climatic protection.The
terminations receive a final pure tin on nickel plating. Four or
five color code rings designate the resistance value and
tolerance in accordance with
IEC 60062.
The result of the determined production is verified by an
extensive testing procedure performed on 100 of the
individual resistors. Only accepted products are stuck
directly on the adhesive tapes in accordance with
IEC 60286-1
or for the radial versions in accordance to
IEC 60286-2.
Precision Thin Film Leaded Resistors
•
2000/53/EC End of Vehicle Life Directive (ELV) and
Annex II (ELVII)
•
2002/95/EC Restriction of the
Substances Directive (RoHS)
use
of
Hazardous
•
2002/96/EC Waste Electrical and Electrical Equipment
Directive (WEEE)
APPROVALS
The resistors are approved within the IECQ-CECC Quality
Assessment System for Electronic Components to the detail
specification
EN 140101-806
which refers to
EN 60115-1
and
EN 140100
and the variety of environmental test
procedures of the
IEC 60068
series.
Conformity is attested by the use of the
CECC
logo ( ) as
the Mark of Conformity on the package label for the CECC
version.
Vishay BEYSCHLAG has achieved
“Approval of
Manufacturer”
in accordance with
IEC QC 001002-3,
clause 2.
The release certificate for
“Technology Approval
Schedule”
in accordance with
CECC 240001
based on
IEC QC 001002-3,
clause 6 is granted for the Vishay
BEYSCHLAG manufacturing process.
ASSEMBLY
The resistors are suitable for processing on automatic
insertion equipment and cutting and bending machines.
Excellent solderability is proven, even after extended
storage. They are suitable for automatic soldering using
wave or dipping.
The resistors are completely lead (Pb)-free, the pure tin
plating provides compatibility with lead (Pb)-free and
lead-containing soldering processes. The immunity of the
plating against tin whisker growth has been proven under
extensive testing.
The encapsulation is resistant to all cleaning solvents
commonly used in the electronics industry, including
alcohols, esters and aqueous solutions. The suitability of
conformal coatings, if applied, shall be qualified by
appropriate means to ensure the long-term stability of the
whole system.
All products comply with
GADSL
(1)
and the
CEFIC-EECA-EICTA
(2)
list of legal restrictions on
hazardous substances. This includes full compliance with
the following directives:
RELATED PRODUCTS
This product family of leaded thin film resistors for
professional applications is complemented by
Zero Ohm
Jumpers.
For a corelated range of precision TCR and tolerance
specifications see the datasheet:
•
“Professional Thin Film Leaded Resistors”, document no.
28766
For products approved to EN 140101-806, version E, with
established reliability and failure rate level E7 (Quality factor
π
Q
= 0.1), see the datasheet:
•
“Established Reliability Thin Film Leaded Resistors”,
document no. 28768
Notes
(2)
Global Automotive Declarable Substance List, see
www.gadsl.org
(3)
CEFIC (European Chemical Industry Council), EECA (European Electronic Component Manufacturers Association), EICTA (European
trade organisation representing the information and communications technology and consumer electronics), see
www.eicta.org/index.php?id=1053&id_article=340
For technical questions, contact:
filmresistorsleaded@vishay.com
Document Number: 28767
Revision: 26-Jul-10
www.vishay.com
76
