(1/4)
SMD Inductors(Coils)
For High Frequency(Multilayer)
MLG Series MLG0603S
FEATURES
• Nominal inductance values are supported from 0.3 to 100nH.
• Provides high Q characteristics.
• Advanced monolithic structure is formed using a multilayering
and sintering process with ceramic and conductive materials for
high-frequency.
• The products contain no lead and also support lead-free
soldering.
• It is a product conforming to RoHS directive.
APPLICATIONS
For high-frequency applications including mobile phones, high
frequency modules (PA, VCO, FEM etc.), Bluetooth, W-LAN, UWB
and tuners.
SHAPES AND DIMENSIONS
0.6±0.03
Conformity to RoHS Directive
PRODUCT IDENTIFICATION
MLG 0603 S 2N2 S T
(1)
(2) (3) (4) (5) (6)
(1) Series name
(2) Dimensions
0603
0.6× 0.3mm (L× W)
(3) Material code
(4) Inductance value
2N2
12N
R10
2.2nH
12nH
100nH
(5) Inductance tolerance
B
C
S
H
J
±0.1nH
±0.2nH
±0.3nH
±3%
±5%
0.3±0.03
(6) Packaging style
0.15±0.05
T
Taping (reel)
0.3±0.03
SPECIFICATIONS
Operating temperature range
Storage temperature range
Weight: 0.2mg
–55 to +125°C
–55 to +125°C [Unit of products]
RECOMMENDED PC BOARD PATTERN
0.25 to 0.35
PACKAGING STYLE AND QUANTITIES
Packaging style
Taping
Quantity
15000 pieces/reel
0.2 to 0.3 0.25 to 0.35 0.2 to 0.3
Dimensions in mm
RECOMMENDED SOLDERING CONDITION
REFLOW SOLDERING
10s max.
250 to 260˚C
230˚C
Natural
cooling
HANDLING AND PRECAUTIONS
• Before soldering, be sure to preheat components.
The preheating temperature should be set so that the
temperature difference between the solder temperature and
product temperature does not exceed 150°C.
• After mounting components onto the printed circuit board, do not
apply stress through board bending or mishandling.
• When hand soldering, apply the soldering iron to the printed
circuit board only. Temperature of the iron tip should not exceed
350°C. Soldering time should not exceed 3 seconds.
180˚C
150˚C
Preheating
60 to 120s
Time(s)
Soldering
30 to 60s
• Conformity to RoHS Directive: This means that, in conformity with EU Directive 2002/95/EC, lead, cadmium, mercury, hexavalent chromium, and specific
bromine-based flame retardants, PBB and PBDE, have not been used, except for exempted applications.
• Please contact our Sales office when your application are considered the following:
The device’s failure or malfunction may directly endanger human life (e.g. application for automobile/aircraft/medical/nuclear power devices, etc.)
• All specifications are subject to change without notice.
006-01 / 20070702 / e521_mlg0603.fm
(2/4)
ELECTRICAL CHARACTERISTICS
Inductance
(nH)
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1.0
1.1
1.2
1.3
1.5
1.6
1.8
2.0
2.2
2.4
2.7
3.0
3.3
3.6
3.9
4.3
4.7
5.1
5.6
6.2
6.8
7.5
8.2
9.1
10
12
15
18
22
27
33
39
47
56
68
82
100
∗
Inductance
tolerance
±0.1, ±0.2nH
±0.1, ±0.2nH
±0.1, ±0.2nH
±0.1, ±0.2nH
±0.1, ±0.2nH
±0.1, ±0.2nH
±0.1, ±0.2nH
±0.1, ±0.2, 0.3nH
±0.1, ±0.2, 0.3nH
±0.1, ±0.2, 0.3nH
±0.1, ±0.2, 0.3nH
±0.1, ±0.2, 0.3nH
±0.1, ±0.2, 0.3nH
±0.1, ±0.2, 0.3nH
±0.1, ±0.2, 0.3nH
±0.1, ±0.2, 0.3nH
±0.1, ±0.2, 0.3nH
±0.1, ±0.2, 0.3nH
±0.1, ±0.2, 0.3nH
±0.1, ±0.2, 0.3nH
±0.1, ±0.2, 0.3nH
±0.1, ±0.2, 0.3nH
±3%, ±0.3nH
±3%, ±0.3nH
±3%, ±0.3nH
±3%, ±0.3nH
±3%, ±0.3nH
±3, ±5%
±3, ±5%
±3, ±5%
±3, ±5%
±3, ±5%
±3, ±5%
±3, ±5%
±3, ±5%
±3, ±5%
±3, ±5%
±3, ±5%
±3, ±5%
±3, ±5%
±3, ±5%
±3, ±5%
±3, ±5%
±3, ±5%
Q
min.
—
—
—
—
—
—
—
4
4
4
4
4
4
4
4
4
4
4
4
4
4
5
5
5
5
5
5
5
5
5
5
5
6
6
6
6
6
6
6
6
5
5
5
5
Test frequency
L, Q (MHz)
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
Self-resonant
frequency
(GHz)
min.
typ.
10.0
20up
10.0
20up
10.0
20up
10.0
20up
10.0
16.3
10.0
16.1
10.0
13.8
10.0
14.4
10.0
13.6
10.0
12.3
9.0
11.4
9.0
10.4
9.0
11.5
8.5
10.0
8.2
9.8
8.0
8.9
8.0
9.2
6.5
8.1
6.2
7.8
5.8
7.0
5.5
6.9
5.0
6.6
5.0
6.4
4.5
5.4
4.5
5.5
4.2
5.3
4.2
5.1
3.6
4.4
4.2
5.3
3.8
4.5
3.4
4.9
3.2
4.1
2.8
3.6
2.5
3.3
2.2
2.8
2.0
2.5
1.8
2.2
1.6
2.0
1.4
1.6
1.3
1.5
1.2
1.4
1.05
1.2
0.90
1.1
0.77
0.9
DC resistance
(Ω)
max.
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.15
0.15
0.15
0.15
0.2
0.2
0.25
0.25
0.25
0.25
0.3
0.35
0.35
0.4
0.4
0.45
0.45
0.5
0.55
0.6
0.7
0.7
0.8
0.8
0.9
1.1
1.2
1.2
1.5
1.8
2.0
2.2
3.2
3.5
4.0
4.5
typ.
0.02
0.02
0.02
0.02
0.02
0.03
0.03
0.04
0.04
0.06
0.07
0.07
0.09
0.12
0.14
0.14
0.15
0.17
0.20
0.23
0.22
0.27
0.27
0.28
0.23
0.31
0.32
0.32
0.43
0.45
0.51
0.53
0.63
0.69
0.78
0.88
1.00
1.20
1.40
1.48
2.11
2.40
2.80
3.13
Rated current
(mA)max.
600
600
600
600
600
600
600
600
550
550
550
550
500
500
400
400
300
300
300
300
300
300
300
300
250
250
250
250
200
200
200
200
180
180
150
150
100
100
50
50
50
50
50
50
Part No.
MLG0603S0N3
MLG0603S0N4
MLG0603S0N5
MLG0603S0N6
MLG0603S0N7
MLG0603S0N8
MLG0603S0N9
MLG0603S1N0
MLG0603S1N1
MLG0603S1N2
MLG0603S1N3
MLG0603S1N5
MLG0603S1N6
MLG0603S1N8
MLG0603S2N0
MLG0603S2N2
MLG0603S2N4
MLG0603S2N7
MLG0603S3N0
MLG0603S3N3
MLG0603S3N6
MLG0603S3N9
MLG0603S4N3
MLG0603S4N7
MLG0603S5N1
MLG0603S5N6
MLG0603S6N2
MLG0603S6N8
MLG0603S7N5
MLG0603S8N2
MLG0603S9N1
MLG0603S10N
MLG0603S12N
MLG0603S15N
MLG0603S18N
MLG0603S22N
MLG0603S27N
MLG0603S33N
MLG0603S39N
MLG0603S47N
MLG0603S56N
MLG0603S68N
MLG0603S82N
MLG0603SR10
∗
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
: Please specify inductance tolerance, B (±0.1nH), C (±0.2nH), S (±0.3nH), H (±3%) or J (±5%).
• Test equipment
Inductance Q : HP4291A+16197A, or equivalent
SRF: HP8720C, or equivalent
Rdc: YOKOGAWA TYPE7561, or equivalent
• Rated current : Value obtained when current flows and temperature has risen to under 20°C.
• All specifications are subject to change without notice.
