F-214
FTM–125–02–L–DV
FTMH–116–02–L–DV–P
FTMH–111–02–F–DV–ES–A
(1,00 mm) .0394"
SMT MICRO TERMINAL STRIPS
SPECIFICATIONS
For complete specifications and
recommended PCB layouts
see www.samtec.com?FTMH
or www.samtec.com?FTM
Insulator Material:
Black Liquid Crystal
Polymer
Terminal Material:
Phosphor Bronze
Current Rating (FTMH/CLM):
2.8 A per pin
(1 pin powered per row)
Operating Temp Range:
-55°C to +125°C
Plating:
Sn or Au over
50µ" (1,27 µm) Ni
RoHS Compliant:
Yes
Mates with:
CLM, MLE
Optional
Pick & Place
pads
Processing:
Lead-Free Solderable:
Yes
-DV Lead Coplanarity:
(0,10 mm) .004" max
-DH Lead Coplanarity:
(0,10 mm) .004" max (05-25)
(0,15 mm) .006" max (26-50)
Surface
Mount
Low profile
(1,79 mm)
.071"
RECOGNITIONS
For complete scope of
recognitions see
www.samtec.com/quality
TYPE
STRIP
1
NO. PINS
PER ROW
LEAD
STYLE
PLATING
OPTION
FTMH
= SMT Micro
= 05 thru 50
FTMH
FTM
–02
= (1,91 mm) .075" Post
(Mates with MLE)
–F
= Gold flash on post,
Matte Tin on tail
ALSO AVAILABLE
(MOQ Required)
• End shrouds with
board locks
• Molded end shrouds for
05 through 08 positions
• Other platings
Contact Samtec.
FTM
= Micro Low Profile
No. of positions
x (1,00) .03937
= 02 thru 50 (unshrouded)
= 05 thru 46 (shrouded)
–03
= (1,65 mm) .065" Post
(Mates with CLM)
–L
= 10µ" (0,25 µm)
Gold on post, Matte Tin on tail
(1,91)
.075
DIA
02
100
FTMH
OPTION
B
(1,57)
.062
(4,06)
.160
(5,49)
.216
(3,17)
.125
01
– ES
– EC
FTMH
No. of positions
x (1,00) .03937 +
B
99
(4,32)
.170
(3,84)
.151
(3,10)
.122
– EP
(1,22)
.048
FTMH
LEAD
STYLE
– 02
– 03
–ES OPTION
–EC OPTION
– EP OPTION
A
(1,91)
.075
(1,65)
.065
(0,30) .012 SQ TYP
(1,00)
.03937
A
(5,00)
.197
(0,69)
.027
(2,59)
.102
(0,64) .025
DIA
(3,18)
.125
X
(5,08)
.200
(3,18)
.125
A
(1,49)
.059
Shrouded option removed for clarity
(1,80)
.071
(5,21)
.205
–P OPTION
Note:
Some lengths,
styles and options are
non-standard, non-returnable.
–DV OPTION
–DH OPTION
–A OPTION
WWW.SAMTEC.COM
FTMH–128–03–L–DV–EP
FTMH–122–02–F–DV–EC
FTMH–135–02–F–DH
FTMH–120–02–L–DV
FTM–125–02–L–DV
FTMH, FTM SERIES
Low Profile
(1,27 mm) .050"
Surface
mount
Flex Shroud
options available
Shrouded and
alignment pin
options available
ROW
OPTION
FLEX SHROUD OPTIONS
OTHER
OPTIONS
–DV
= Dual Vertical
(FTMH-DV only with
9 pins/row minimum)
(FTM only)
–A
= Alignment Pin
(3 positions minimum)
Metal or plastic at Samtec discretion
(FTMH–DV only)
–DH
= Dual Horizontal
(FTMH only)
–ES
= End Shroud
–S
= End Shroud
(05 positions minimum).
Molded or press fit shroud at
Samtec’s discretion
(See assembly print at
www.samtec.com?FTM
for dimensions)
–EC
50
02
= End Shroud with Locking Clip
(Manual placement required)
–K
= (2,50 mm) .098" DIA Polyimide
Film Pick & Place Pad
(FTMH–DH only)
–EP
(5,21)
.205
01
49
(3,18)
= End Shroud with Guide Post
.125
(Use only when mating with CLM)
–SA
= End Shroud with Alignment Pins
(05 through 46 positions)
–P
= Plastic Pick & Place Pad
(–DV only)
(6 positions minimum)
FTM
No. of positions x
(1,00) .03937 +
C
02
46
FTM
OPTION
–S
– SA
(3,23) (4,44)
.127 .175
C
(7,00)
.276
(4,00)
.157
FTM
LEAD
STYLE
– 02
– 03
–TR
= Tape & Reel
D
(1,91)
.075
(1,65)
.065
01
45
(0,97)
.038
(0,30) .012 SQ TYP
D
No of positions
x (1,00) .03937
(2,54)
.100
x
(5,08)
.200
(3,56)
.140
(3,18)
.125
(1,27)
.050
(1,40) (3,56)
.055 .140
(1,00)
.039
DIA
–DV OPTION
–S OPTION
(1,50) .059
–P OPTION
Shrouded options removed for clarity
–SA OPTION
WWW.SAMTEC.COM
