LM741EN: DescriptionBasic information of LM741EN amplifier: LM741EN is an OPERATIONAL AMPLIFIER. The commonly used packaging method is DIP, LM741EN amplifier core information: The minimum operating temperature of the LM741EN is and the maximum operating temperature is 70 °C. Its maximum average bias current is 0.21 µA How to simply check the efficiency of an amplifier? Looking at its slew rate, the LM741EN has a nominal slew rate of 0.7 V/us. When the op amp is used in a closed loop, at a certain closed-loop gain (usually 1 or 2, 10, etc.), the frequency when the LM741EN gain becomes 0.707 times the low-frequency gain is 1500 kHz. The nominal supply voltage of the LM741EN is 15 V, and its corresponding nominal negative supply voltage is -15 V. The input offset voltage of the LM741EN is 4000 µV (input offset voltage: the compensation voltage added between the two input terminals to make the output terminal of the operational amplifier 0V (or close to 0V).) Related dimensions of LM741EN: The width of LM741EN is: 7.62 mm and the length is 9.8171 mm. LM741EN has 8 terminals. Its terminal position type is: DUAL. Terminal pitch is 2.54 mm. Total pins: 8 LM741EN amplifier additional information: Its temperature grade is: COMMERCIAL. The corresponding JESD-30 code is: R-PDIP-T8. The package code of LM741EN is: DIP. The materials used in the LM741EN package are mostly PLASTIC/EPOXY. The package shape is RECTANGULAR. The LM741EN package pin format is: IN-LINE. Its terminal form is: THROUGH-HOLE. The maximum seat height is 5.08 mm.; CategoryAnalog mixed-signal IC Amplifier circuit; File Size896KB，9 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/; Alternative parts：LM741EN

Download Datasheet Parametric Compare View All

LM741EN Overview

Basic information of LM741EN amplifier:

LM741EN is an OPERATIONAL AMPLIFIER. The commonly used packaging method is DIP,

LM741EN amplifier core information:

The minimum operating temperature of the LM741EN is and the maximum operating temperature is 70 °C. Its maximum average bias current is 0.21 µA

How to simply check the efficiency of an amplifier? Looking at its slew rate, the LM741EN has a nominal slew rate of 0.7 V/us. When the op amp is used in a closed loop, at a certain closed-loop gain (usually 1 or 2, 10, etc.), the frequency when the LM741EN gain becomes 0.707 times the low-frequency gain is 1500 kHz.

The nominal supply voltage of the LM741EN is 15 V, and its corresponding nominal negative supply voltage is -15 V. The input offset voltage of the LM741EN is 4000 µV (input offset voltage: the compensation voltage added between the two input terminals to make the output terminal of the operational amplifier 0V (or close to 0V).)

Related dimensions of LM741EN:

The width of LM741EN is: 7.62 mm and the length is 9.8171 mm. LM741EN has 8 terminals. Its terminal position type is: DUAL. Terminal pitch is 2.54 mm. Total pins: 8

LM741EN amplifier additional information:

Its temperature grade is: COMMERCIAL. The corresponding JESD-30 code is: R-PDIP-T8. The package code of LM741EN is: DIP. The materials used in the LM741EN package are mostly PLASTIC/EPOXY. The package shape is RECTANGULAR.

The LM741EN package pin format is: IN-LINE. Its terminal form is: THROUGH-HOLE. The maximum seat height is 5.08 mm.

LM741EN Parametric

Parameter Name	Attribute value
Maker	Rochester Electronics
Parts packaging code	DIP
package instruction	DIP,
Contacts	8
Reach Compliance Code	unknown
ECCN code	EAR99
Is Samacsys	N
Amplifier type	OPERATIONAL AMPLIFIER
Maximum average bias current (IIB)	0.21 µA
Nominal Common Mode Rejection Ratio	95 dB
Maximum input offset voltage	4000 µV
JESD-30 code	R-PDIP-T8
length	9.8171 mm
Negative supply voltage upper limit	-22 V
Nominal Negative Supply Voltage (Vsup)	-15 V
Number of functions	1
Number of terminals	8
Maximum operating temperature	70 °C
Minimum operating temperature
Package body material	PLASTIC/EPOXY
encapsulated code	DIP
Package shape	RECTANGULAR
Package form	IN-LINE
Certification status	Not Qualified
Maximum seat height	5.08 mm
Nominal slew rate	0.7 V/us
Supply voltage upper limit	22 V
Nominal supply voltage (Vsup)	15 V
surface mount	NO
technology	BIPOLAR
Temperature level	COMMERCIAL
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
Nominal Uniform Gain Bandwidth	1500 kHz
width	7.62 mm
Base Number Matches	1
