BK1/GDB-315MAV: DescriptionFAST BLOW ELECTRIC FUSE, 0.315A, 250VAC, 35A (IR), THROUGH HOLE; CategoryCircuit protection Circuit protection; File Size155KB，2 Pages; ManufacturerEaton

Download Datasheet Parametric View All

BK1/GDB-315MAV Overview

FAST BLOW ELECTRIC FUSE, 0.315A, 250VAC, 35A (IR), THROUGH HOLE

BK1/GDB-315MAV Parametric

Parameter Name	Attribute value
Maker	Eaton
Reach Compliance Code	unknown
ECCN code	EAR99
Is Samacsys	N
Fusing characteristics	FAST
body height	21.1 mm
Body length or diameter	5.54 mm
Circuit protection type	ELECTRIC FUSE
JESD-609 code	e3
Joule integral nominal
Manufacturer's serial number	GDB
Installation features	THROUGH HOLE
method of packing	BAG
physical size	5.54mm x 21.1mm
Rated breaking capacity	35 A
Rated current	0.315 A
Rated voltage (AC)	250 V
Guideline	BSI; CSA; IMQ; SEMKO; UL; VDE
surface mount	NO
Terminal surface	TIN
Terminal shape	PIN WIRE
Base Number Matches	1

Preview

Download Datasheet

View All

5mm x 20mm Fuses

GDB Series, Fast Acting, Glass Tube

Description

• Fast acting, low breaking capacity

• 5mm x 20mm physical size

• Glass tube, nickel-plated brass endcap construction

• Optional axial leads are .032" x 1.5" copper tinned

• Designed to IEC 60127-2 (32mA-6.3A)

ELECTRICAL CHARACTERISTICS

1.5 In 2.1 In

2.75 In

4 In

10 In

min

max

min

max

min

max

32mA-100mA 60 min 30 min 10 ms 500 ms 3 ms 100 ms 20 ms

125mA-6.3A 60 min 30 min 50 ms 2 sec 10 ms 300 ms 20 ms

Dimensions

Drawing Not to Scale

Ordering

• Specify product code, option code and packaging code

Agency Information

• UL Recognized Card: (32mA-6.3A) Guide JDYX2,

File E19180

• CSA Component Acceptance: File 53787

• Semko Approval 32mA-400mA and 800mA-6.3A

• VDE Approval 32mA-6.3A

• BSI Approval 160mA-6.3A

• IMQ Approval 160mA-6.3A

• Ratings above 6.3A have a 0.8mm diameter lead

• With TR2 packaging code, lead wire length is 19.05mm

SPECIFICATIONS

Product Code

GDB-32mA

GDB-40mA

GDB-50mA

GDB-63mA

GDB-80mA

GDB-100mA

GDB-125mA

GDB-160mA

GDB-200mA

GDB-250mA

GDB-315mA

GDB-400mA

GDB-500mA

GDB-630mA

GDB-800mA

GDB-1A

GDB-1.25A

GDB-1.6A

GDB-2A

GDB-2.5A

GDB-3.15A

GDB-4A

GDB-5A

GDB-6.3A

GDB-8A

GDB-10A

Voltage

Rating

250V

Interrupting Rating

at Rated Voltage (50Hz)

35A

Typical DC

Cold Resistance

(ohms)*

41.5

25.5

17.5

12.9

5.2

3.9

2.9

9.2

7.0

4.5

3.2

1.9

0.27

0.21

0.15

0.13

0.098

0.068

0.044

0.035

0.026

0.022

0.015

0.010

N/A

Typical

Melting I

t (A

Sec)

AC†

0.000047

0.00011

0.00020

0.00057

0.0012

0.003

0.005

0.008

0.016

0.28

0.58

0.18

0.35

0.67

0.60

0.84

1.6

4.2

6.1

N/A

Maximum

Voltage

Drop (mV)‡

3200

2500

2400

2000

1200

1100

1000

2000

1700

1400

1300

1100

220

190

200

190

150

130

120

N/A

* DC Cold Resistance (Measured at <10% of rated current)

† Typical Melting I

t (I

t was measured at listed interrupting rating and rated voltage)

‡ Maximum Voltage Drop (Voltage drop was measured at 20°C ambient temperature at rated current)
