MC68EC020RP25 datasheet, PDF - EEWORLD Datasheet

MC68EC020RP25: Description32-BIT, 25MHz, MICROPROCESSOR, PPGA100, PLASTIC, PGA-100; CategoryThe embedded processor and controller Microcontrollers and processors; File Size9MB，313 Pages; ManufacturerNXP; Websitehttps://www.nxp.com

Download Datasheet Parametric View All

MC68EC020RP25 Overview

32-BIT, 25MHz, MICROPROCESSOR, PPGA100, PLASTIC, PGA-100

Parameter Name	Attribute value
Parts packaging code	PGA
package instruction	PGA,
Contacts	100
Reach Compliance Code	unknown
ECCN code	EAR99
Is Samacsys	N
Address bus width	24
bit size	32
boundary scan	NO
maximum clock frequency	25 MHz
External data bus width	32
Format	FIXED POINT
Integrated cache	YES
JESD-30 code	S-PPGA-P100
length	34.545 mm
low power mode	NO
Number of terminals	100
Maximum operating temperature	70 °C
Minimum operating temperature
Package body material	PLASTIC/EPOXY
encapsulated code	PGA
Package shape	SQUARE
Package form	GRID ARRAY
Certification status	Not Qualified
Maximum seat height	4.7 mm
speed	25 MHz
Maximum supply voltage	5.25 V
Minimum supply voltage	4.75 V
Nominal supply voltage	5 V
surface mount	NO
technology	HCMOS
Temperature level	COMMERCIAL
Terminal form	PIN/PEG
Terminal pitch	2.54 mm
Terminal location	PERPENDICULAR
width	34.545 mm
uPs/uCs/peripheral integrated circuit type	MICROPROCESSOR
Base Number Matches	1

Freescale Semiconductor, Inc.

Freescale Semiconductor, Inc...

For More Information On This Product,

Go to: www.freescale.com
