CLC5665IM: DescriptionBasic information of CLC5665IM amplifier: CLC5665IM is an OPERATIONAL AMPLIFIER. Commonly used packaging methods are PLASTIC, SOIC-8 CLC5665IM amplifier core information: The minimum operating temperature of CLC5665IM is -40 °C and the maximum operating temperature is 85 °C. Its peak reflow temperature is NOT SPECIFIED Its maximum average bias current is 20 µA How to simply check the efficiency of an amplifier? Looking at its slew rate, the nominal slew rate of CLC5665IM is 1800 V/us. When the op amp is used in closed loop, at a certain closed-loop gain (usually 1 or 2, 10, etc.), the frequency when the CLC5665IM gain becomes 0.707 times the low-frequency gain is 90000 kHz. The nominal supply voltage of CLC5665IM is 15 V, and its corresponding nominal negative supply voltage is -15 V. The input offset voltage of CLC5665IM is 10000 µV (input offset voltage: the compensation voltage added between the two input terminals to make the output terminal of the operational amplifier 0V (or close to 0V).) Related dimensions of CLC5665IM: The width of CLC5665IM is: 3.9 mm and the length is 4.9 mm. CLC5665IM has 8 terminals. Its terminal position type is: DUAL. Terminal pitch is 1.27 mm. Total pins: 8 CLC5665IM amplifier additional information: Its temperature grade is: INDUSTRIAL. And its humidity sensitivity level is: NOT SPECIFIED. CLC5665IM is not Rohs certified. It contains lead. The corresponding JESD-30 code is: R-PDSO-G8. The corresponding JESD-609 code is: e0. The packaging code of CLC5665IM is: SOP. CLC5665IM packaging materials are mostly PLASTIC/EPOXY. The package shape is RECTANGULAR. The CLC5665IM package pin format is: SMALL OUTLINE. Its terminal forms are: GULL WING. The maximum seat height is 1.75 mm.; CategoryAnalog mixed-signal IC Amplifier circuit; File Size914KB，14 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/; Alternative parts：CLC5665IM

Download Datasheet Parametric Compare View All

CLC5665IM Overview

Basic information of CLC5665IM amplifier:

CLC5665IM is an OPERATIONAL AMPLIFIER. Commonly used packaging methods are PLASTIC, SOIC-8

CLC5665IM amplifier core information:

The minimum operating temperature of CLC5665IM is -40 °C and the maximum operating temperature is 85 °C. Its peak reflow temperature is NOT SPECIFIED Its maximum average bias current is 20 µA

How to simply check the efficiency of an amplifier? Looking at its slew rate, the nominal slew rate of CLC5665IM is 1800 V/us. When the op amp is used in closed loop, at a certain closed-loop gain (usually 1 or 2, 10, etc.), the frequency when the CLC5665IM gain becomes 0.707 times the low-frequency gain is 90000 kHz.

The nominal supply voltage of CLC5665IM is 15 V, and its corresponding nominal negative supply voltage is -15 V. The input offset voltage of CLC5665IM is 10000 µV (input offset voltage: the compensation voltage added between the two input terminals to make the output terminal of the operational amplifier 0V (or close to 0V).)

Related dimensions of CLC5665IM:

The width of CLC5665IM is: 3.9 mm and the length is 4.9 mm. CLC5665IM has 8 terminals. Its terminal position type is: DUAL. Terminal pitch is 1.27 mm. Total pins: 8

CLC5665IM amplifier additional information:

Its temperature grade is: INDUSTRIAL. And its humidity sensitivity level is: NOT SPECIFIED. CLC5665IM is not Rohs certified. It contains lead. The corresponding JESD-30 code is: R-PDSO-G8.

The corresponding JESD-609 code is: e0. The packaging code of CLC5665IM is: SOP. CLC5665IM packaging materials are mostly PLASTIC/EPOXY. The package shape is RECTANGULAR. The CLC5665IM package pin format is: SMALL OUTLINE.

Its terminal forms are: GULL WING. The maximum seat height is 1.75 mm.

CLC5665IM Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Parts packaging code	SOIC
package instruction	PLASTIC, SOIC-8
Contacts	8
Reach Compliance Code	unknown
Is Samacsys	N
Amplifier type	OPERATIONAL AMPLIFIER
Maximum average bias current (IIB)	20 µA
Nominal Common Mode Rejection Ratio	60 dB
Maximum input offset voltage	10000 µV
JESD-30 code	R-PDSO-G8
JESD-609 code	e0
length	4.9 mm
Humidity sensitivity level	NOT SPECIFIED
Negative supply voltage upper limit	-16 V
Nominal Negative Supply Voltage (Vsup)	-15 V
Number of functions	1
Number of terminals	8
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	COMMERCIAL
Maximum seat height	1.75 mm
Nominal slew rate	1800 V/us
Supply voltage upper limit	16 V
Nominal supply voltage (Vsup)	15 V
surface mount	YES
Temperature level	INDUSTRIAL
Terminal surface	TIN LEAD
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Nominal Uniform Gain Bandwidth	90000 kHz
width	3.9 mm
Base Number Matches	1

Preview

Download Datasheet

View All

D ts e t

aa h e

R c e t r lc r nc

o h se Ee to is

Ma u a t r dCo o e t

n fc u e

mp n n s

R c e tr b a d d c mp n ns ae

o h se rn e

o oet r

ma ua trd u ig ete dewaes

n fcue sn i r i/ fr

p rh s d f m te oiia s p l r

uc a e r

o h r n l u pi s

o R c e tr waes rce td f m

r o h se

fr e rae r

te oiia I. Al rce t n ae

r nl P

l e rai s r

d n wi tea p o a o teOC

o e t h p rv l f h

P r aetse u igoiia fcoy

at r e td sn r n la tr

ts p o rmso R c e tr e eo e

e t rga

r o h se d v lp d

ts s lt n t g aa te p o u t

e t oui s o u rne

rd c

me t o e c e teOC d t s e t

es r x e d h

M aa h e.

Qu l yOv riw

e ve

• IO- 0 1

S 90

•A 92 cr ct n

S 1 0 et ai

• Qu l e Ma ua trr Ls (

ai d

n fcues it QML MI- R -

) LP F

385

•C a sQ Mitr

lay

•C a sVS a eL v l

p c ee

• Qu l e S p l r Ls o D sr uos( L )

ai d u pi s it f it b tr QS D

•R c e trsacic l u pir oD A a d

o h se i

r ia s p l t L n

me t aln u t a dD A sa d r s

es lid sr n L tn ad .

R c e tr lcrnc , L i c mmi e t

o h se Ee t is L C s o

tdo

s p ligp o u t ta s t f c so r x e t-

u pyn rd cs h t ai y u tme e p ca

t n fr u lya daee u loto eoiial

i s o q ai n r q a t h s r n l

s p l db id sr ma ua trr.

u pi

e yn ut

y n fcues

T eoiia ma ua trr d ts e t c o a yn ti d c me t e e t tep r r n e

h r n l n fcue’ aa h e a c mp n ig hs o u n r cs h ef ma c

a ds e ic t n o teR c e tr n fcue v rino ti d vc . o h se Ee t n

n p c ai s f h o h se ma ua trd eso f hs e ie R c e tr lcr -

isg aa te tep r r n eo i s mio d co p o u t t teoiia OE s e ic -

c u rne s h ef ma c ft e c n u tr rd cs o h r n l M p c a

t n .T pc lv le aefr eee c p r o e o l. eti mii m o ma i m rt g

i s ‘y ia’ au s r o rfrn e up s s ny C r n nmu

r xmu ai s

ma b b s do p o u t h rceiain d sg , i lt n o s mpetsig

y e a e n rd c c aa tr t , e in smuai , r a l e t .

z o

0 3 ohs E cr i , L . lRg s eevd 7 1 0 3

e e oc

T l r m r, l s v iw wrcl . m

o e n oe p ae it w . e c o

o ec

CLC5665IM Related Products

	CLC5665IM	CLC5665IMX	CLC5665IN
Description	OP-AMP, 10000uV OFFSET-MAX, 90MHz BAND WIDTH, PDSO8, PLASTIC, SOIC-8	OP-AMP, 10000uV OFFSET-MAX, 90MHz BAND WIDTH, PDSO8, PLASTIC, SOIC-8	OP-AMP, 10000uV OFFSET-MAX, 90MHz BAND WIDTH, PDIP8, PLASTIC, MDIP-8
Is it lead-free?	Contains lead	Contains lead	Contains lead
Is it Rohs certified?	incompatible	incompatible	incompatible
Parts packaging code	SOIC	SOIC	DIP
package instruction	PLASTIC, SOIC-8	PLASTIC, SOIC-8	PLASTIC, MDIP-8
Contacts	8	8	8
Reach Compliance Code	unknown	unknown	unknown
Is Samacsys	N	N	N
Amplifier type	OPERATIONAL AMPLIFIER	OPERATIONAL AMPLIFIER	OPERATIONAL AMPLIFIER
Maximum average bias current (IIB)	20 µA	20 µA	20 µA
Nominal Common Mode Rejection Ratio	60 dB	60 dB	60 dB
Maximum input offset voltage	10000 µV	10000 µV	10000 µV
JESD-30 code	R-PDSO-G8	R-PDSO-G8	R-PDIP-T8
JESD-609 code	e0	e0	e0
length	4.9 mm	4.9 mm	9.8171 mm
Humidity sensitivity level	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
Negative supply voltage upper limit	-16 V	-16 V	-16 V
Nominal Negative Supply Voltage (Vsup)	-15 V	-15 V	-15 V
Number of functions	1	1	1
Number of terminals	8	8	8
Maximum operating temperature	85 °C	85 °C	85 °C
Minimum operating temperature	-40 °C	-40 °C	-40 °C
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	SOP	SOP	DIP
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	SMALL OUTLINE	SMALL OUTLINE	IN-LINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
Certification status	COMMERCIAL	COMMERCIAL	COMMERCIAL
Maximum seat height	1.75 mm	1.75 mm	5.08 mm
Nominal slew rate	1800 V/us	1800 V/us	1800 V/us
Supply voltage upper limit	16 V	16 V	16 V
Nominal supply voltage (Vsup)	15 V	15 V	15 V
surface mount	YES	YES	NO
Temperature level	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL
Terminal surface	TIN LEAD	TIN LEAD	TIN LEAD
Terminal form	GULL WING	GULL WING	THROUGH-HOLE
Terminal pitch	1.27 mm	1.27 mm	2.54 mm
Terminal location	DUAL	DUAL	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
Nominal Uniform Gain Bandwidth	90000 kHz	90000 kHz	90000 kHz
width	3.9 mm	3.9 mm	7.62 mm
Base Number Matches	1	1	1
