This product complies with the RoHS Directive (EU 2002/95/EC).
DSC8505
Silicon NPN epitaxial planar type
For low frequency output amplification
DSC7505 in MT-2 through hole type package
Features
Contributes to miniaturization of sets, reduction of component count.
Eco-friendly Halogen-free package
Package
Code
MT-2-A2-B
Name
Pin
1. Emitter
2. Collector
3. Base
Symbol
V
CBO
V
CEO
V
EBO
I
C
I
CP
P
C
T
j
T
stg
Rating
40
20
7
3
5
1
150
–55 to +150
Unit
V
V
V
A
A
W
°C
°C
Packaging
Radial type : 2000 pcs / carton
Absolute Maximum Ratings
T
a
= 25°C
Parameter
Collector-base voltage (Emitter open)
Collector-emitter voltage (Base open)
Emitter-base voltage (Collector open)
Collector current
Peak collector current
Collector power dissipation
Junction temperature
Storage temperature
Marking Symbol: 5G
Note) Printed circuit board: Copper foil area of 1 cm
2
or more, and the board thickness
of 1.7 mm for the collector portion
Electrical Characteristics
T
a
= 25°C±3°C
Parameter
Collector-emitter voltage (Base open)
Emitter-base voltage (Collector open)
Collector-base cutoff current (Emitter open)
Forward current transfer ratio
*1
Collector-emitter saturation voltage
*1
Transition frequency
*1
Collector output capacitance
(Common base, input open circuited)
Symbol
V
CEO
V
EBO
I
CBO
h
FE1 *2
h
FE2
V
CE(sat)
f
T
C
ob
Conditions
I
C
= 1 mA, I
B
= 0
I
E
= 10
mA,
I
C
= 0
V
CB
= 10 V, I
E
= 0
V
CE
= 2 V, I
C
= 0.5 A
V
CE
= 2 V, I
C
= 2 A
I
C
= 3 A, I
B
= 0.1 A
V
CE
= 6 V, I
C
= 50 mA
V
CB
= 20 V, I
E
= 0, f = 1 MHz
200
50
230
150
1.0
Min
20
7
0.1
600
Typ
Max
Unit
V
V
mA
V
MHz
pF
Note) 1. Measuring methods are based on JAPANESE INDUSTRIAL STANDARD JIS C 7030 measuring methods for transistors.
2. *1: Pulse measurement
*2: Rank classification
Code
Rank
h
FE1
Marking Symbol
Q
Q
230 to 380
5GQ
R
R
340 to 600
5GR
Product of no-rank is not classified and have no marking symbol for rank.
Publication date: November 2011
Ver. AED
1
