M
AXI
-C
ON
-X
®
F
IELD
I
NSTALLABLE
C
ONNECTORS
Part Number to Order
XX X XX-XX XG-3XX
Connector Type:
13
- Cable End
14
- Panel Mount
15
- Cable to Cable
Back
Shell
Style 3
Grommet Code –
Cable O.D. Range:
21
- .21 - .25 (5.3-6.3)
26
- .26 - .30 (6.6-7.6)
31
- .31 - .38 (7.8-9.6)
Contact Size:
1
- #12 (7 Contacts)
2
- #20 (18 & 20 Contacts)
3
- #16 (10 Contacts)
Back Shell Style:
3
Mechanical screw-down
cable clamp with grommet
seal and (1) interfacial “O”
ring for cable end.
Contact Style:
80
-
81
-
82
-
91
-
92
-
Crimp (Supplied loose)
P/C Tail .187” (4.7) (Supplied assembled)
Solder Cup (Supplied assembled)
P/C Tail .280” (7.1) (Supplied assembled)*
P/C Tail .335” (8.5) (Supplied assembled)*
300
- Panel mount with hex nut &
gasket.
3ES
- 300 with Epoxy
Number of Contacts:
7, 10, 18
&
20
Type of Contact:
P
- Pin
S
- Socket
Contact Plating:
G
- Gold over Nickel (Standard)
EMI/RFI shielded assemblies available - consult factory.
*Available in #20 size contact only.
Consult factory for optional threaded coupling.
Consult factory for your custom design cable assemblies and connectors. (See pages 3 & 26)
Contact Arrangements
1
1
2
1
3
3
6
7
10
5
4
8
9
7
7
12
16
18
15
2
3
2
4
6
8
11
13
17
19
20
6
10
11
15
7
12
16
18
14
1
3
5
9
2
7-#12
10-#16
18-#20
20-#20*
Contact arrangements shown are wiring view of cable end pins/sockets.
Key/keyway shown for orientation only.
*Available in connector types: cable end socket, panel mount pin styles only.
®
601 East Wildwood, Villa Park, Illinois 60181 • Telephone (630) 834-7504 • Fax (630) 834-8540
®
20
M
AXI
-C
ON
-X
®
F
IELD
I
NSTALLABLE
C
ONNECTORS
Specifications
Typical Specifications
Manufacturers Identifications
Description
Rating
Conductor Size
Configuration
Maxi-Con-X
®
Field Installable Connector & Custom Cable Assemblies
1.35 thru 13.0A, 600V
#12 Contacts, 12 thru 14 AWG
#16 Contacts, 16 thru 18 AWG
#20 Contacts, 20 thru 24 AWG
7 - #12 Contacts
10 - #16 Contacts
18 - #20 Contacts
20 - #20 Contacts
UL Recognized File #E150822 - 250V
CSA Certified File #LR89277 - 600V
Certification
Material Specifications
Cable Pin/Socket
Mechanical Backshell (Threaded)
Strap
Screws
Grommet
Coupling Ring
Contacts
Connector Body
O-Ring
Nylon, UL Recognized, Black
Nylon, UL Recognized, Black
Cadmium Plated
Santoprene Rubber, Black
Nylon, UL Recognized, Black
Brass, Gold over Nickel
Nylon, UL Recognized, Black
Nitrile Rubber, Black
Nylon, UL Recognized, Black (W/14482)
Nylon, UL Recognized, Black
Santoprene Rubber, Black
Nylon, UL Recognized, Black
Cadmium Plated
Brass, Gold over Nickel
Nylon, UL Recognized, Black
Brass, Gold over Nickel
Nylon, UL Recognized, Black
Nitrile Rubber, Black
Nylon, UL Recognized, Black
Santoprene Rubber, Black (Part No. 14295)
Minimum 300 mate/unmate cycles without mechanical or electrical
failure
Coupling rings have overriding locking feature to prevent loosening or
separation of connector
All series hex nut to withstand 10-12 inch/lb tightening torque
600 V
See Electrical Current Rating Chart (Page 27)
-55°C to +125°C (-67°F to +257°F)
300 Hr salt spray contacts
Consult factory with specific application
Optional
Winged Coupling Ring
Cable to Cable
Mechanical Backshell (Threaded)
Grommet
Strap
Screws
Contacts
Connector Body
Panel Mount
Contacts
Panel Body
Gasket
Hex Nut
Optional
Dust Cap
Mechanical Specifications
Durability
Vibration
Hex Nut Torque
Electrical Specifications
Voltage
Current
Environmental Specifications
Temperature Rating
Corrosion
Weathertight
Molded Cable Assemblies
Watertight
(See Pages 3 & 26)
NEMA 6P, 13: IEC IP67
®
601 East Wildwood, Villa Park, Illinois 60181 • Telephone (630) 834-7504 • Fax (630) 834-8540
®
21
