M50747-PGYS datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The embedded processor and controller> Microcontrollers and processors> M50747-PGYS

M50747-PGYS: DescriptionMicrocontroller, 8-Bit, EPROM, MELPS740 CPU, 2MHz, CMOS, PDIP64; CategoryThe embedded processor and controller Microcontrollers and processors; File Size2MB，30 Pages; ManufacturerMitsubishi; Websitehttp://www.mitsubishielectric.com/semiconductors/

Download Datasheet Parametric Compare View All

M50747-PGYS Overview

Microcontroller, 8-Bit, EPROM, MELPS740 CPU, 2MHz, CMOS, PDIP64

M50747-PGYS Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
package instruction	SDIP, SDIP64,.75
Reach Compliance Code	unknown
Is Samacsys	N
bit size	8
CPU series	MELPS740
JESD-30 code	R-PDIP-T64
JESD-609 code	e0
Number of terminals	64
Maximum operating temperature	70 °C
Minimum operating temperature	-10 °C
Package body material	PLASTIC/EPOXY
encapsulated code	SDIP
Encapsulate equivalent code	SDIP64,.75
Package shape	RECTANGULAR
Package form	IN-LINE, SHRINK PITCH
power supply	5 V
Certification status	Not Qualified
RAM (bytes)	256
rom(word)	16384
ROM programmability	EPROM
speed	2 MHz
Maximum slew rate	12 mA
Nominal supply voltage	5 V
surface mount	NO
technology	CMOS
Temperature level	COMMERCIAL
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	THROUGH-HOLE
Terminal pitch	1.78 mm
Terminal location	DUAL
Base Number Matches	1

Preview

Download Datasheet

View All

M50747-PGYS Related Products

	M50747-PGYS	M50747-146SP	M50747ES	M50747T-XXXSP	M50747EFS	M50747H-XXXSP	M50747H-XXXFP	M50747E-XXXSP	M50747E-XXXFP
Description	Microcontroller, 8-Bit, EPROM, MELPS740 CPU, 2MHz, CMOS, PDIP64	single-chip 8-bit cmos microcomputer	Microcontroller, 8-Bit, UVPROM, MELPS740 CPU, 8MHz, CMOS, CDIP64	Microcontroller, 8-Bit, MROM, MELPS740 CPU, 2MHz, CMOS, PDIP64	Microcontroller, 8-Bit, UVPROM, MELPS740 CPU, 8MHz, CMOS, CQFP72	Microcontroller, 8-Bit, MROM, MELPS740 CPU, 3MHz, CMOS, PDIP64	Microcontroller, 8-Bit, MROM, MELPS740 CPU, 3MHz, CMOS, PQFP72	Microcontroller, 8-Bit, UVPROM, MELPS740 CPU, 8MHz, CMOS, PDIP64	Microcontroller, 8-Bit, UVPROM, MELPS740 CPU, 8MHz, CMOS, PQFP72
Is it Rohs certified?	incompatible	-	incompatible	incompatible	incompatible	incompatible	incompatible	incompatible	incompatible
package instruction	SDIP, SDIP64,.75	-	SDIP, SDIP64,.75	SDIP, SDIP64,.75	QFP, QFP72,.7X.9,32	SDIP, SDIP64,.75	QFP, QFP72,.7X.9,32	SDIP, SDIP64,.75	QFP, QFP72,.7X.9,32
Reach Compliance Code	unknown	-	unknown	unknown	unknown	unknown	unknown	unknown	unknown
Is Samacsys	N	-	N	N	N	N	N	N	N
bit size	8	-	8	8	8	8	8	8	8
CPU series	MELPS740	-	MELPS740	MELPS740	MELPS740	MELPS740	MELPS740	MELPS740	MELPS740
JESD-30 code	R-PDIP-T64	-	R-XDIP-T64	R-PDIP-T64	R-XQFP-G72	R-PDIP-T64	R-PQFP-G72	R-PDIP-T64	R-PQFP-G72
JESD-609 code	e0	-	e0	e0	e0	e0	e0	e0	e0
Number of terminals	64	-	64	64	72	64	72	64	72
Maximum operating temperature	70 °C	-	70 °C	85 °C	70 °C	70 °C	70 °C	70 °C	70 °C
Minimum operating temperature	-10 °C	-	-10 °C	-40 °C	-10 °C	-10 °C	-10 °C	-10 °C	-10 °C
Package body material	PLASTIC/EPOXY	-	CERAMIC	PLASTIC/EPOXY	CERAMIC	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	SDIP	-	SDIP	SDIP	QFP	SDIP	QFP	SDIP	QFP
Encapsulate equivalent code	SDIP64,.75	-	SDIP64,.75	SDIP64,.75	QFP72,.7X.9,32	SDIP64,.75	QFP72,.7X.9,32	SDIP64,.75	QFP72,.7X.9,32
Package shape	RECTANGULAR	-	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	IN-LINE, SHRINK PITCH	-	IN-LINE, SHRINK PITCH	IN-LINE, SHRINK PITCH	FLATPACK	IN-LINE, SHRINK PITCH	FLATPACK	IN-LINE, SHRINK PITCH	FLATPACK
power supply	5 V	-	5 V	5 V	5 V	5 V	5 V	5 V	5 V
Certification status	Not Qualified	-	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
RAM (bytes)	256	-	256	256	256	256	256	256	256
rom(word)	16384	-	8192	8192	8192	8192	8192	8192	8192
ROM programmability	EPROM	-	UVPROM	MROM	UVPROM	MROM	MROM	UVPROM	UVPROM
speed	2 MHz	-	8 MHz	2 MHz	8 MHz	3 MHz	3 MHz	8 MHz	8 MHz
Maximum slew rate	12 mA	-	12 mA	12 mA	12 mA	18 mA	18 mA	12 mA	12 mA
Nominal supply voltage	5 V	-	5 V	5 V	5 V	5 V	5 V	5 V	5 V
surface mount	NO	-	NO	NO	YES	NO	YES	NO	YES
technology	CMOS	-	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS
Temperature level	COMMERCIAL	-	COMMERCIAL	INDUSTRIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL
Terminal surface	Tin/Lead (Sn/Pb)	-	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)
Terminal form	THROUGH-HOLE	-	THROUGH-HOLE	THROUGH-HOLE	GULL WING	THROUGH-HOLE	GULL WING	THROUGH-HOLE	GULL WING
Terminal pitch	1.78 mm	-	1.78 mm	1.78 mm	0.8 mm	1.78 mm	0.8 mm	1.78 mm	0.8 mm
Terminal location	DUAL	-	DUAL	DUAL	QUAD	DUAL	QUAD	DUAL	QUAD
Base Number Matches	1	-	1	1	1	1	1	1	1
