LT1509IS datasheet, PDF - EEWORLD Datasheet

LT1509IS: DescriptionIC 2 A POWER FACTOR CONTROLLER WITH POST REGULATOR, PDSO20, 0.300 INCH, PLASTIC, SO-20, Switching Regulator or Controller; CategoryPower/power management The power supply circuit; File Size44KB，1 Pages; ManufacturerLinear ( ADI ); Websitehttp://www.analog.com/cn/index.html

Download Datasheet Parametric Compare View All

LT1509IS Overview

IC 2 A POWER FACTOR CONTROLLER WITH POST REGULATOR, PDSO20, 0.300 INCH, PLASTIC, SO-20, Switching Regulator or Controller

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Parts packaging code	SOIC
package instruction	0.300 INCH, PLASTIC, SO-20
Contacts	20
Reach Compliance Code	compliant
ECCN code	EAR99
Is Samacsys	N
Analog Integrated Circuits - Other Types	POWER FACTOR CONTROLLER WITH POST REGULATOR
control mode	CURRENT-MODE
Control Technology	PULSE WIDTH MODULATION
JESD-30 code	R-PDSO-G20
JESD-609 code	e0
length	12.8 mm
Number of functions	1
Number of terminals	20
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Maximum output current	2 A
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Certification status	Not Qualified
Maximum seat height	2.65 mm
surface mount	YES
Switch configuration	PUSH-PULL
technology	BIPOLAR
Temperature level	INDUSTRIAL
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
width	7.5 mm
Base Number Matches	1

	LT1509IS	LT1509CS
Description	IC 2 A POWER FACTOR CONTROLLER WITH POST REGULATOR, PDSO20, 0.300 INCH, PLASTIC, SO-20, Switching Regulator or Controller	IC 2 A POWER FACTOR CONTROLLER WITH POST REGULATOR, PDSO20, 0.300 INCH, PLASTIC, SO-20, Switching Regulator or Controller
Is it Rohs certified?	incompatible	incompatible
Parts packaging code	SOIC	SOIC
package instruction	0.300 INCH, PLASTIC, SO-20	0.300 INCH, PLASTIC, SO-20
Contacts	20	20
Reach Compliance Code	compliant	compliant
ECCN code	EAR99	EAR99
Analog Integrated Circuits - Other Types	POWER FACTOR CONTROLLER WITH POST REGULATOR	POWER FACTOR CONTROLLER WITH POST REGULATOR
control mode	CURRENT-MODE	CURRENT-MODE
Control Technology	PULSE WIDTH MODULATION	PULSE WIDTH MODULATION
JESD-30 code	R-PDSO-G20	R-PDSO-G20
JESD-609 code	e0	e0
length	12.8 mm	12.8 mm
Number of functions	1	1
Number of terminals	20	20
Maximum operating temperature	85 °C	70 °C
Maximum output current	2 A	2 A
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	SOP	SOP
Package shape	RECTANGULAR	RECTANGULAR
Package form	SMALL OUTLINE	SMALL OUTLINE
Certification status	Not Qualified	Not Qualified
Maximum seat height	2.65 mm	2.65 mm
surface mount	YES	YES
Switch configuration	PUSH-PULL	PUSH-PULL
technology	BIPOLAR	BIPOLAR
Temperature level	INDUSTRIAL	COMMERCIAL
Terminal surface	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)
Terminal form	GULL WING	GULL WING
Terminal pitch	1.27 mm	1.27 mm
Terminal location	DUAL	DUAL
width	7.5 mm	7.5 mm
