ICL7621BMTV datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> Amplifier circuit> ICL7621BMTV

ICL7621BMTV: DescriptionICL7621BMTV amplifier basic information: ICL7621BMTV is an OPERATIONAL AMPLIFIER. Commonly used packaging methods are, ICL7621BMTV amplifier core information: The minimum operating temperature of ICL7621BMTV is -55 °C and the maximum operating temperature is 125 °C. Its peak reflow temperature is NOT SPECIFIED Its maximum average bias current is 0.004 µA How to simply check the efficiency of an amplifier? Looking at its slew rate, the nominal slew rate of ICL7621BMTV is 0.16 V/us. When the op amp is used in closed loop, at a certain closed-loop gain (usually 1 or 2, 10, etc.), the frequency when the ICL7621BMTV gain becomes 0.707 times the low-frequency gain is 480 kHz. The nominal supply voltage of ICL7621BMTV is 5 V, and its corresponding nominal negative supply voltage is -5 V. The input offset voltage of ICL7621BMTV is 7000 µV (input offset voltage: the compensation voltage added between the two input terminals to make the output terminal of the operational amplifier 0V (or close to 0V).) Related dimensions of ICL7621BMTV: ICL7621BMTV has 8 terminals. Its terminal position type is: BOTTOM. Total pins: 8 ICL7621BMTV amplifier additional information: Its temperature grade is: MILITARY. ICL7621BMTV is not Rohs certified. It contains lead. The corresponding JESD-30 code is: O-MBCY-W8. The corresponding JESD-609 code is: e0. The materials used in the ICL7621BMTV package are mostly METAL. And its package shape is ROUND. The ICL7621BMTV package pin format is: CYLINDRICAL. Its terminal form is: WIRE.; CategoryAnalog mixed-signal IC Amplifier circuit; File Size956KB，12 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/; Alternative parts：ICL7621BMTV

Download Datasheet Parametric Compare View All

ICL7621BMTV Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	ICL7621BMTV	-	-	View	Buy Now

ICL7621BMTV Overview

ICL7621BMTV amplifier basic information:

ICL7621BMTV is an OPERATIONAL AMPLIFIER. Commonly used packaging methods are,

ICL7621BMTV amplifier core information:

The minimum operating temperature of ICL7621BMTV is -55 °C and the maximum operating temperature is 125 °C. Its peak reflow temperature is NOT SPECIFIED Its maximum average bias current is 0.004 µA

How to simply check the efficiency of an amplifier? Looking at its slew rate, the nominal slew rate of ICL7621BMTV is 0.16 V/us. When the op amp is used in closed loop, at a certain closed-loop gain (usually 1 or 2, 10, etc.), the frequency when the ICL7621BMTV gain becomes 0.707 times the low-frequency gain is 480 kHz.

The nominal supply voltage of ICL7621BMTV is 5 V, and its corresponding nominal negative supply voltage is -5 V. The input offset voltage of ICL7621BMTV is 7000 µV (input offset voltage: the compensation voltage added between the two input terminals to make the output terminal of the operational amplifier 0V (or close to 0V).)

Related dimensions of ICL7621BMTV:

ICL7621BMTV has 8 terminals. Its terminal position type is: BOTTOM. Total pins: 8

ICL7621BMTV amplifier additional information:

Its temperature grade is: MILITARY. ICL7621BMTV is not Rohs certified. It contains lead. The corresponding JESD-30 code is: O-MBCY-W8. The corresponding JESD-609 code is: e0.

The materials used in the ICL7621BMTV package are mostly METAL. And its package shape is ROUND. The ICL7621BMTV package pin format is: CYLINDRICAL. Its terminal form is: WIRE.

ICL7621BMTV Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Parts packaging code	BCY
package instruction	,
Contacts	8
Reach Compliance Code	unknown
ECCN code	EAR99
Is Samacsys	N
Amplifier type	OPERATIONAL AMPLIFIER
Maximum average bias current (IIB)	0.004 µA
Nominal Common Mode Rejection Ratio	91 dB
Maximum input offset voltage	7000 µV
JESD-30 code	O-MBCY-W8
JESD-609 code	e0
Negative supply voltage upper limit	-9 V
Nominal Negative Supply Voltage (Vsup)	-5 V
Number of functions	2
Number of terminals	8
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package body material	METAL
Package shape	ROUND
Package form	CYLINDRICAL
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	Not Qualified
Nominal slew rate	0.16 V/us
Supply voltage upper limit	9 V
Nominal supply voltage (Vsup)	5 V
surface mount	NO
technology	CMOS
Temperature level	MILITARY
Terminal surface	TIN LEAD
Terminal form	WIRE
Terminal location	BOTTOM
Maximum time at peak reflow temperature	NOT SPECIFIED
Nominal Uniform Gain Bandwidth	480 kHz
Base Number Matches	1
