IDT54FCT810CTLB datasheet, PDF

Datasheet> All Categories > logic> logic> IDT54FCT810CTLB

IDT54FCT810CTLB: DescriptionLow Skew Clock Driver, FCT Series, 5 True Output(s), 5 Inverted Output(s), CMOS, CQCC20, LCC-20; Categorylogic logic; File Size107KB，6 Pages; ManufacturerIDT (Integrated Device Technology)

Download Datasheet Parametric View All

IDT54FCT810CTLB Overview

Low Skew Clock Driver, FCT Series, 5 True Output(s), 5 Inverted Output(s), CMOS, CQCC20, LCC-20

IDT54FCT810CTLB Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Parts packaging code	QLCC
package instruction	LCC-20
Contacts	20
Reach Compliance Code	not_compliant
Is Samacsys	N
Other features	ONE BANK WITH ALL TRUE OUTPUTS & OTHER WITH ALL INVERTED OUTPUTS; MAX PART TO PART SKEW = 1.2NS
series	FCT
Input adjustment	SCHMITT TRIGGER
JESD-30 code	S-CQCC-N20
JESD-609 code	e0
length	8.89 mm
Load capacitance (CL)	50 pF
Logic integrated circuit type	LOW SKEW CLOCK DRIVER
MaximumI(ol)	0.032 A
Number of functions	1
Number of inverted outputs	5
Number of terminals	20
Actual output times	5
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Output characteristics	3-STATE
Package body material	CERAMIC, METAL-SEALED COFIRED
encapsulated code	QCCN
Encapsulate equivalent code	LCC20,.35SQ
Package shape	SQUARE
Package form	CHIP CARRIER
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
power supply	5 V
Prop。Delay @ Nom-Sup	4.6 ns
propagation delay (tpd)	4.6 ns
Certification status	Not Qualified
Same Edge Skew-Max（tskwd）	1 ns
Filter level	38535Q/M;38534H;883B
Maximum seat height	2.54 mm
Maximum supply voltage (Vsup)	5.5 V
Minimum supply voltage (Vsup)	4.5 V
Nominal supply voltage (Vsup)	5 V
surface mount	YES
technology	CMOS
Temperature level	MILITARY
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	NO LEAD
Terminal pitch	1.27 mm
Terminal location	QUAD
Maximum time at peak reflow temperature	NOT SPECIFIED
width	8.89 mm
Base Number Matches	1

Preview

Download Datasheet

View All

FAST CMOS

BUFFER/CLOCK DRIVER

Integrated Device Technology, Inc.

IDT54/74FCT810BT/CT

FEATURES:

•

0.5 MICRON CMOS technology

Guaranteed low skew < 600ps (max.)

Very low duty cycle distortion < 700ps (max.)

Low CMOS power levels

TTL compatible inputs and outputs

TTL level output voltage swings

High drive: –32mA I

, 48mA I

Two independent output banks with 3-state control

– One 1:5 Inverting bank

– One 1:5 Non-Inverting bank

• ESD > 2000V per MIL-STD-883, Method 3015;

> 200V using machine model (C = 200pF, R = 0)

• Available in DIP, SOIC, SSOP, QSOP, CERPACK and

LCC packages

• Military product compliant to MIL-STD-883, Class B

DESCRIPTION:

The IDT54/74FCT810BT/CT is a dual bank inverting/ non-

inverting clock driver built using advanced dual metal CMOS

technology. It consists of two banks of drivers, one inverting

and one non-inverting. Each bank drives five output buffers

from a standard TTL-compatible input. The IDT54/

74FCT810BT/CT have low output skew, pulse skew and

package skew. Inputs are designed with hysteresis circuitry

for improved noise immunity. The outputs are designed with

TTL output levels and controlled edge rates to reduce signal

noise. The part has multiple grounds, minimizing the effects of

ground inductance.

FUNCTIONAL BLOCK DIAGRAMS

PIN CONFIGURATIONS

P20-1

D20-1

SO20-2

SO20-7

SO20-8

E20-1

GND

3103 drw 02

-OA

GND

-OB

3103 drw 01

GND

DIP/SOIC/SSOP/QSOP/CERPACK

TOP VIEW

INDEX

GND

20 19

GND

L20-2

9 10 11 12 13

The IDT logo is a registered trademark of Integrated Device Technology, Inc.

LCC

TOP VIEW

GND

3103 drw 03

MILITARY AND COMMERCIAL TEMPERATURE RANGES

Integrated Device Technology, Inc.

OCTOBER 1995

DSC-4646/3

9.4
