Preview

BR-HE133-05V: DescriptionSingle Color LED, High Efficiency Red, Water Clear, 2mm, SURFACE MOUNT PACKAGE-2; CategoryLED optoelectronic/LED photoelectric; File Size200KB，1 Pages; ManufacturerBRIGHT; Websitehttp://www.brightled.co.kr/

Download Datasheet Parametric Compare View All

BR-HE133-05V Overview

Single Color LED, High Efficiency Red, Water Clear, 2mm, SURFACE MOUNT PACKAGE-2

BR-HE133-05V Parametric

Parameter Name	Attribute value
package instruction	SURFACE MOUNT PACKAGE-2
Reach Compliance Code	unknown
Is Samacsys	N
color	HIGH EFFICIENCY RED
Configuration	SINGLE WITH BUILT-IN RESISTOR
Maximum forward current	0.012 A
Lens type	WATER CLEAR
Nominal luminous intensity	15.0 mcd
Installation features	SURFACE MOUNT
Number of functions	1
Number of terminals	2
Maximum operating temperature	85 °C
Minimum operating temperature	-45 °C
Optoelectronic device types	SINGLE COLOR LED
total height	1.1 mm
method of packing	BULK
peak wavelength	640 nm
shape	RECTANGULAR
size	2 mm
surface mount	YES
Terminal pitch	3.5 mm
perspective	140 deg
Base Number Matches	1

Preview

Download Datasheet

View All

Surface Mount Resistor Chip LED Lamps

1206 Resistor Built-in BR-Hxxx3-xx Series

Absolute Maximum Ratings(Ta=25 )

UNIT

IF

IFp

Topr

Tstg

mA

SPEC.

12

100

-45~+85

-45~+100

Chip

Part No.

Material

GaP/GaP

GaAsP/GaP

A1GaInP

GaP/GaP

GaAsP/GaP

GaP/GaP

GaAsP/GaP

Emitted Color

Yellow Green

Yellow

Hi-Eff Red

Super Red

Yellow Green

Yellow

Hi-Eff Red

Super Red

Yellow Green

Yellow

Hi-Eff Red

p

(nm)

568

583

640

660

645

568

583

640

660

568

583

640

Water Clear

Lens

Appearance

Operating

Voltage

Typ.

Max.

5

9

12

15

Electro-optical Data

Forward

Current

Typ.

7

Max.

12

Iv(mcd)

Min.

5.5

3.7

5.5

12.3

5.5

3.7

5.5

12.3

5.5

3.7

5.5

Typ.

15.0

12.0

15.0

30.0

25.0

15.0

12.0

15.0

30.0

15.0

12.0

15.0

Viewing

Angle

2 1/2

(deg)

BR-HG033-05V

BR-HY033-05V

BR-HE133-05V

BR-HUB33-05V

BR-HUB33-09V

BR-HG033-12V

BR-HY033-12V

BR-HE033-12V

BR-HG033-15V

BR-HY033-15V

BR-HE133-15V

BR-HD033-05V GaA1As/GaAs

140

BR-HD033-12V GaA1As/GaAs

AMERICAN BRIGHT

(909) 628-5050 FAX (909) 628-5006

.

w w w . a m e r ica n b r ig h tle d . co m

SMT-18
