SAFEB1G90FA0F05R14 datasheet, PDF

Datasheet> All Categories > Analog mixed-signal IC> filter> SAFEB1G90FA0F05R14

SAFEB1G90FA0F05R14: DescriptionSAW Filter, 1 Function(s), 1900MHz; CategoryAnalog mixed-signal IC filter; File Size166KB，4 Pages; ManufacturerMurata; Websitehttps://www.murata.com

Download Datasheet Parametric Compare View All

SAFEB1G90FA0F05R14 Overview

SAW Filter, 1 Function(s), 1900MHz

SAFEB1G90FA0F05R14 Parametric

Parameter Name	Attribute value
Reach Compliance Code	unknown
Is Samacsys	N
Other features	TAPE AND REEL
Center frequency or cutoff frequency (fo/fc)	1900 MHz
filter type	SAW FILTER
high	0.6 mm
input resistance	200 OHM//27 nH
Maximum insertion loss	2 dB
length	1.35 mm
Manufacturer's serial number	SAFEB1G90FA0F05
Installation type	SURFACE MOUNT
Number of functions	1
Maximum operating temperature	85 °C
Minimum operating temperature	-30 °C
Output impedance	200 OHM//27 nH Ω
physical size	L1.35XB1.05XH0.6 (mm)/L0.053XB0.041XH0.024 (inch)
width	1.05 mm
Base Number Matches	1

Preview

Download Datasheet

View All

SAW FILTER FOR TD-SCDMA

Murata part number : SAFEB1G90FA0F05

Package Dimensions

1.35±0.05

(5)

(1)

Dot Marking(φ0.3)

(4)

1.05±0.05

Specification

Item

Nominal Center Frequency(fc)

Insertion Loss

(1880 to 1920 MHz)

(0.20)

0.6max.

Specification

-30 to +85°C

1900 MHz

2.0 dB max.

1.5 dB

typ.

a N

(2)

(3)

Absolute Attenuation

0 to 1000 MHz

45 dB min.

35 dB min.

18 dB min.

15 dB min.

10 dB min.

15 dB min.

20 dB min.

25 dB min.

40 dB min.

25 dB min.

50 dB

39 dB

42 dB

34 dB

25 dB

24 dB

36 dB

54 dB

44 dB

2) 1000 to 1500 MHz

3) 1500 to 1800 MHz

4) 1800 to 1820 MHz

5) 1820 to 1840 MHz

5-0.325±0.050

6) 1970 to 2000 MHz

2-0.25±0.05

(0.075)

7) 2000 to 2500 MHz

8) 2500 to 3000 MHz

9) 3000 to 4500 MHz

10) 4500 to 6000 MHz

(2)

(1)

(5)

(3)

(0.05)

2-0.25±0.05

(4)

5-0.25±0.05

2-0.25±0.05

Ripple Deviation

(1880 to 1920 MHz)

VSWR

(1880 to 1920 MHz)

Amplitude Balance

(1880 to 1920 MHz)

1.2 dB max.

0.4 dB

2.2 max.

1.6

±5.0 dB max.

+0.2 dB

Marking

: Laser Printing

(1) : Unbalance Port

(3)(4) : Balance Port

Others : Ground

Unit : mm

Phase Balance

(1880 to 1920 MHz)

Unbalance Port Matching Impedance

(nominal)

Balance Port Matching Impedance

(nominal)

Input Signal Level

180±15 deg.

Ω

180+3 deg.

200

Ω

//27nH

20mW (+13dBm), 2000 hours

Dec. 8, 2009

1/4
