NCP1201D100R2G datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Power/power management> The power supply circuit> NCP1201D100R2G

NCP1201D100R2G: DescriptionSWITCHING CONTROLLER, 117kHz SWITCHING FREQ-MAX, PDSO8, HALOGEN FREE, BFR FREE AND ROHS COMPLIANT, SOIC-8; CategoryPower/power management The power supply circuit; File Size1MB，20 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

NCP1201D100R2G Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	NCP1201D100R2G	-	-	View	Buy Now

NCP1201D100R2G Overview

SWITCHING CONTROLLER, 117kHz SWITCHING FREQ-MAX, PDSO8, HALOGEN FREE, BFR FREE AND ROHS COMPLIANT, SOIC-8

NCP1201D100R2G Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	conform to
Parts packaging code	SOIC
package instruction	HALOGEN FREE, BFR FREE AND ROHS COMPLIANT, SOIC-8
Contacts	8
Reach Compliance Code	unknown
Is Samacsys	N
Analog Integrated Circuits - Other Types	SWITCHING CONTROLLER
control mode	CURRENT-MODE
Control Technology	PULSE WIDTH MODULATION
Nominal input voltage	11 V
JESD-30 code	R-PDSO-G8
JESD-609 code	e3
length	4.9 mm
Humidity sensitivity level	NOT SPECIFIED
Number of functions	1
Number of terminals	8
Maximum operating temperature	125 °C
Minimum operating temperature	-25 °C
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260
Maximum seat height	1.75 mm
surface mount	YES
Switch configuration	SINGLE
Maximum switching frequency	117 kHz
technology	CMOS
Temperature level	OTHER
Terminal surface	MATTE TIN
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	40
width	3.9 mm
Base Number Matches	1

Preview
