SMD Wire-wound Chip Inductors
ctparts.com
CT1008LS Series
From 1.2 µH to 47 µH
Not shown at actual size.
SPECIFICATIONS
Please specify tolerance code when ordering.
CT1008LS-122_
J = ±5%, K = ±10%, M = ±20%
Add Letter 'G' at the end of part number after the tolerance for gold terminations.
Part
Number
CT1008LS-122_
CT1008LS-152_
CT1008LS-182_
CT1008LS-222_
CT1008LS-272_
CT1008LS-332_
CT1008LS-392_
CT1008LS-472_
CT1008LS-562_
CT1008LS-682_
CT1008LS-822_
CT1008LS-103_
CT1008LS-123_
CT1008LS-153_
CT1008LS-183_
CT1008LS-223_
CT1008LS-273_
CT1008LS-333_
CT1008LS-393_
CT1008LS-473_
Inductance
(µH)
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
L Test
Freq.
(MHz)
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
Q
Fact.
Min.
44
40
35
35
34
28
28
28
28
28
28
28
28
28
25
24
24
23
23
23
Q Test
Freq.
(MHz)
50
50
50
50
50
50
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
SRF
Min.
(MHz)
220
210
170
150
135
120
95
80
75
65
60
60
50
45
25
25
20
20
20
20
DCR
Max.
Ω
(Ω)
0.7
0.7
0.8
1.2
1.5
1.7
1.8
1.9
2.2
2.4
2.6
3.4
4.4
5.2
5.5
6.2
6.8
8.0
8.7
12.5
Rated
DC
(mA)
650
630
600
520
490
450
420
400
380
360
330
300
270
270
270
250
250
250
250
250
PHYSICAL DIMENSIONS
CHARACTERISTICS
Description:
SMD ferrite core wire-wound chip inductor
Applications:
LC resonant circuits such as oscillator and signal
generators, impedance matching, circuit isolation, RF filters, disk
drives and computer peripherals, audio and video equipment, TV,
radio and telecommunication equipment
Operating Temperature:
-55°C to +85°C
Inductance Tolerance:
±5%, ±10% & ±20%
Testing:
Inductance and Q are tested on an HP4286A at
specified frequency
Packaging:
Tape & Reel, 2,000 parts per reel
Marking:
Reels are marked with inductance code and tolerance
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
Size
mm
inches
Max.
2.55
0.1
A
Max.
2.38
0.09
B
Max.
2.1
0.08
C
D
2
0.08
E
0.5
0.02
F
1.43
0.06
PAD LAYOUT
Volume Manufacturer of Inductive Components
800-684-5322
Inside US
949-453-1811
Outside US
7.12.14.01
Copyright © 2002 by CT Magnetics. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice.
