UTO1023: DescriptionNarrow Band Medium Power Amplifier, 10MHz Min, 1000MHz Max, HERMETIC SEALED, TO-8T, 4 PIN; CategoryWireless rf/communication Radio frequency and microwave; File Size205KB，6 Pages; ManufacturerTeledyne Technologies Incorporated; Websitehttp://www.teledyne.com/

Download Datasheet Parametric Compare View All

UTO1023 Overview

Narrow Band Medium Power Amplifier, 10MHz Min, 1000MHz Max, HERMETIC SEALED, TO-8T, 4 PIN

UTO1023 Parametric

Parameter Name	Attribute value
Reach Compliance Code	compliant
Other features	LOW NOISE
Characteristic impedance	50 Ω
structure	COMPONENT
Gain	12 dB
Maximum input power (CW)	17 dBm
Maximum operating frequency	1000 MHz
Minimum operating frequency	10 MHz
Maximum operating temperature	100 °C
Minimum operating temperature	-55 °C
RF/Microwave Device Types	NARROW BAND MEDIUM POWER
Maximum voltage standing wave ratio	2
Base Number Matches	1

Preview

Download Datasheet

View All

Thin-Film Cascadable Amplifier

10 to 1000 MHz

Technical Data

UTO/UTC 1023 Series

Features

• Frequency Range: 10 to

1000 MHz

• High Power: +26.5 dBm

(Typ)

• Medium Gain: 13.0 dB (Typ)

• Temperature Compensated

• Low Phase Noise

Description

The 1023 Series is a thin-film

bipolar RF amplifier for higher

output power and medium-gain

applications up to 1000 MHz.

Resistive feedback and active bias

assure temperature compensation

and increased immunity to bias

voltage variations. Low VSWR is

maintained by inductive tuning

while the RF is coupled through

the amplifier by internal blocking

capacitors. The 1023 Series

amplifiers are available in either

the TO-8 hermetic case or

connectored TC-1A package.

Pin Configuration

UTO—TO-8T

RF IN

GROUND

RFOUT

V+

CASE GROUND

UTC—TC-1A

Applications

• IF/RF Amplification

• Output Stage

RF IN

RF OUT

V+

Schematic

V+

Maximum Ratings

Parameter

DC Voltage

Continuous RF Input Power

Operating Case Temperature

Storage Temperature

“R” Series Burn-In Temperature

Maximum

+17 Volts

+17 dBm

–55 to +100°C

–62 to +150°C

+100°C

OUT

Thermal Characteristics

Active Transistor Power Dissipation

Junction Temperature Above Case Temperature

MTBF (MIL-HDBK-217E, A

@ 90°C)

52°C/W

924/661/661 mW

48/34/34°C

410,200 Hrs.

Notes:

1. Values refer to first, second, and third stages, respectively.

Weight:

(typical) UTO —2.1 grams; UTC—21.5 grams
