3-827753-2: DescriptionHEADER CONNECTOR,PCB MNT,RECEPT,32 CONTACTS,PIN,0.1 PITCH,R ANGLE PC TAIL TERMINAL,BLACK; CategoryThe connector The connector; File Size115KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance

Download Datasheet Parametric View All

3-827753-2 Overview

HEADER CONNECTOR,PCB MNT,RECEPT,32 CONTACTS,PIN,0.1 PITCH,R ANGLE PC TAIL TERMINAL,BLACK

3-827753-2 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Reach Compliance Code	compliant
body width	0.114 inch
subject depth	0.255 inch
body length	3.2 inch
Body/casing type	RECEPTACLE
Connector type	BOARD CONNECTOR
Contact to complete cooperation	AU ON NI
Contact point gender	MALE
Contact material	PHOSPHOR BRONZE
contact mode	RECTANGULAR
Contact style	SQ PIN-SKT
Dielectric withstand voltage	750VAC V
Insulation resistance	5000000000 Ω
Insulator color	BLACK
insulator material	GLASS FILLED POLYBUTYLENE TEREPHTHALATE
Manufacturer's serial number	827753
Plug contact pitch	0.1 inch
Installation method	RIGHT ANGLE
Installation type	BOARD
Number of connectors	ONE
PCB row number	1
Number of rows loaded	1
Maximum operating temperature	105 °C
Minimum operating temperature	-65 °C
PCB contact pattern	RECTANGULAR
Plating thickness	31u inch
Rated current (signal)	3 A
Guideline	UL, CSA
reliability	COMMERCIAL
Terminal length	0.202 inch
Terminal pitch	2.54 mm
Termination type	SOLDER
Total number of contacts	32
Base Number Matches	1

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

PC B C onnectors

Product Feature Selector

> Product Details

3-827753-2 Product Details

Live Product Chat

Product Photo

.100 inch AMPMODU Headers

Always EU R oHS/ELV C om plia nt

(

Sta te m e nt of C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

3-827753-2

T E I nternal N umber: 3 - 8 2 7 7 5 3 - 2

Product Highlights:

Header

Header Type = Standard

Number of Rows = Single

Number of Positions = 32

Mating Post Length = 5.90 mm

View all Features

Pending Obsolescence

C ontact Product Information C enter

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Buy P roduc t

Documentation & Additional Information

Product Drawings:

AMPMODU II STIFTLEISTE 90 EINREIHIG

(PDF, English)

Catalog Pages/Data Sheets:

None Available

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Type

= Header

Number of Positions

= 32

Mount Angle

= Right Angle

PC B Retention Feature

= No

Surface Mount C ompatible

= No

Board Standoff

= Without

Mounting Ears

= Without

Mating C onnector Lock

= Without

Profile = Standard

C omment = Headers are side-to-side stackable.

Mechanical Attachment:

Mating Post Length (mm [in]) = 5.90 [0.232]

Panel Attachment

= Without

Termination Related Features:

Termination Post Length (mm [in])

= 5.12 [0.202]

Solder Tail C ontact Plating = Tin

Body Related Features:

Header Type = Standard

Number of Rows

= Single

C enterline, Matrix (mm [in])

= 2.54 [.100]

Selectively Loaded

= No

Mount Type

= Printed C ircuit Board

Contact Related Features:

C ontact Mating Area Plating Material

= Gold (30)

C ontact Base Material = Phosphor Bronze

Housing Related Features:

Housing Material = Thermoplastic Polyester

Housing Flammability Rating = UL 94V-0

Industry Standards:

RoHS/ELV C ompliance

= RoHS compliant, ELV compliant

Lead Free Solder Processes

= Wave solder capable to 240?C

RoHS/ELV C ompliance History = Always was RoHS compliant

Conditions for Usage:

High Temperature Housing

= No

Operation/Application:

High Speed Serial Data C onnector

= No

Other:

Brand = AMP

Additional Information:

Product Line Information
