Power
Inductors
7.0
+/- 0.3
5.0
+/- 0.35
7.8
Typ.
7.0
Typ.
LC75
2.1
Typ.
7.8
+/- 0.3
CHARACTERISTICS
INDUCTANCE RANGE 10 µH to 470 µH.
TOLERANCE 10% over entire range.
CURRENT RATING Current to cause maximum 10% of
inductance drop, or 40°C temperature rise.
OPERATING TEMPERA
TURE -30°C to +100°C.
PART
NUMBER
LC75-100K
LC75-120K
LC75-150K
LC75-180K
LC75-220K
LC75-270K
LC75-330K
LC75-390K
LC75-470K
LC75-560K
LC75-680K
LC75-820K
LC75-101K
LC75-121K
LC75-151MK
LC75-181MK
LC75-221K
LC75-271K
LC75-331K
LC75-391K
LC75-471K
L ±10%
µH
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
TEST
FREQUENCY
(MHz)
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
FEATURES
High current rating
Low core loss for high frequency power application
APPLIC
ATIONS
DC/DC Converters
Computers
Telecommunications equipment
Filters
LCD display
SELF RESONANT
FREQUENCY
TYPIC AL (MHz)
28
23
22
20
17
15
15
14
13
11
11
10
9.2
7.7
6.1
5.8
5.2
4.8
4.3
4.3
3.8
DC RESIST ANCE
MAXIMUM
(OHMS)
0.07
0.08
0.09
0.10
0.11
0.12
0.13
0.16
0.18
0.24
0.28
0.37
0.43
0.47
0.64
0.71
0.96
1.11
1.26
1.77
1.96
RATED DC
CURRENT
MAXIMUM (AMPS)
2.30
2.00
1.80
1.60
1.50
1.30
1.20
1.10
1.10
0.94
0.85
1.78
0.72
0.66
0.58
0.51
0.49
0.42
0.40
0.36
0.34
