3-828205-5 Product Details
Live Product Chat
Product Photo
.100 AMPMODU Headers, Housings & Contacts
Always EU R oHS/ELV C om plia nt
(
Sta te m e nt of C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
3-828205-5
T E I nternal N umber: 3 - 8 2 8 2 0 5 - 5
Product Highlights:
l
Housing
l
Preloaded
l
Number of Positions = 70
l
Housing Type = Receptacle
l
C ontact Type = Receptacle
View all Features
Pending Obsolescence
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
C onnector, AMPMODU, Mass Terminated Standard Pressure
(PDF, English)
l
Interconnection System, AMPMODU MT, Shielding Access...
(PDF, English)
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type = Housing
l
Number of Positions
= 70
l
Mating C onnector Lock
= Without
l
Mating Polarization = Without
l
Wire Insulation Diameter (mm [in]) = 1.27 [0.050]
l
Keyed
= No
l
C onnector Series
= MT
l
Wire Termination Type = Insulation Displacement C rimp (IDC )
l
Applied Pressure = Standard
Mechanical Attachment:
l
Preloaded = Yes
Termination Related Features:
l
Solder Tail C ontact Plating = Tin
Body Related Features:
l
Housing Type
= Receptacle
l
Number of Rows
= Dual
l
C enterline, Matrix (mm [in])
= 2.54 x 2.54 [.100 x .100]
l
Wire Range (mm [AWG])
= 0.05-0.15 [30-26]
Contact Related Features:
l
C ontact Type = Receptacle
l
C ontact Mating Area Plating Material
= Gold (30)
l
C ontact Base Material = C opper Alloy
Housing Related Features:
l
Housing C olor
= Black
l
Housing Flammability Rating = UL 94V-0
l
Housing Material = Thermoplastic Polyester
Industry Standards:
l
RoHS/ELV C ompliance
= RoHS compliant, ELV compliant
l
Lead Free Solder Processes
= Not relevant for lead free process
l
RoHS/ELV C ompliance History = Always was RoHS compliant
Conditions for Usage:
l
Terminate To
= Wire
Other:
l
Brand = AMP
Additional Information:
l
Product Line Information
