8
7
LATCH
ACTUATOR
6
LATCH RELEASE
5
4
3
2
REV
38.28
1.51
DOCUMENT
1
DRAWING REVISIONS
APP
DATE
1
08 - 1093
VS
1/12/09
D
D
10.60
.42
LABEL INCLUDES CINCH: PART NUMBER,
REVISION LEVEL DESCRIPTION,DATE CODE,
RoHS COMPLIANT AND COUNTRY OF ORIGIN
7.26
.29
32.15
1.27
"L" SEE TABLE
18.85
.74
P1
"D" DOWN
C
P2
"D" UP
S15
S1
C
8.80
.35
18.03
.71
S2
S16
S1
S1
PLUG DETAIL
SCALE 2:1
S15
S16
S2
STANDARD PART NUMBERS
CONSULT FACTORY FOR CUSTOM
CONFIGURATIONS AND LENGTH
24 AWG CABLE
"L" Meters
1
2
3
5
7
10
Part Number
717 01 00 101
717 01 00 102
717 01 00 103
717 01 00 104
717 01 00 105
717 01 00 106
MODELED BY:
V.SKUZA
B
NOTES:
CABLE SPECIFICATIONS:
PLUG MATERIALS:
TWINAX; FULLY SHIELDED DIFFERENTIAL PAIRS, 24 AWG; UL STYLE CL2 OR CM.
CHARACTERISTIC IMPEDANCE: 100 +/- 8 OHMS.
CONTACTS - COPPER ALLOY; GOLD PLATED OVER NICKEL.
SHELL - ZINC DIE CAST; NICKEL PLATED OVER COPPER.
LATCH MECHANISM - THERMOPLASTIC AND NICKEL ALLOY.
CONNECTOR HOUSING - HIGH TEMPERATURE THERMOPLASTIC UL94V-0.
TOLERANCE TABLE
"L" LENGHT
UP TO 1M
1M TO 10M
GREATER THAN 10M
TOLERANCE
40.0mm
70.0mm OF "L"
100mm OF "L"
B
MECHANICAL PERFORMANCE:
LATCH RETENTION FORCE - 75 N (16.9 LBS) MIN.
DURABILITY - 250 CYCLES
RoHS COMPLIANT
UNITS
METRIC
Solidworks
DATE
TITLE
1700 FINLEY RD
LOMBARD, IL. 60148
A
OPERATING TEMPERATURE RANGE: -20°C to 75°C.
ENVIRONMENT:
DO NOT SCALE DRAWING
UNLESS OTHERWISE SPECIFIED:
ALL DIMENSIONS ARE IN MILLIMETERS
FILLET/RADII
0.50 MAX
TOLERANCES AND
LIMITS APPLY OVER
ADDITIVE FINISH
TOLERANCES
.X ± .3
.XX ± .13
.XXX ± .025
ANGULAR ± .5°
DRAWN BY
V.SKUZA
DESIGN ENGINEER
1/12/09
XX/XX/XX
XX/XX/XX
XX/XX/XX
XX/XX/XX
MATERIAL
4X ANGLED W/LATCH OPPOSITE D ORIENTATION
24 AWG CABLE ASSEMBLY
*
*
FINISH
DRAWING NUMBER
SIZE
CONTROL SPEC NUMBER
*
*
*
*
*
A
PERFORMANCE:
DESIGN ENGINEERING MGR.
MFG. ENGINEERING
MATERIAL SPEC NUMBER
CAD FILE NUMBER
DIRECT ATTACH CABLE ASSEMBLY MEETS InfiniBand™ REQUIREMENTS FOR HIGH
SPEED DATA TRANSFERS AND SFF 8470
*
PROJECT NUMBER
C 14939
DIMENSIONS IN [ ] ARE IN INCHES.
8
7
6
5
4
THIS DOCUMENT IS THE PROPERTY
OF CINCH. NEITHER THIS DOCUMENT
NOR ANY OF THE INFORMATION
CONTAINED IN IT MAY BE DUPLICATED
OR DISCLOSED WITHOUT PRIOR
WRITTEN CONSENT OF CINCH.
717 01 00 100S
CAGE IDENT NO.
QUALITY ASSURANCE
71785
B
SCALE
717 01 00 100S
SHEET 1 OF 1
1:1
3
2
1
