JANKCA1N5297 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> JANKCA1N5297

JANKCA1N5297: DescriptionCurrent Regulator Diode, 1mA I(S), 1.35V V(L), Silicon, HERMETIC SEALED, DIE-2; CategoryDiscrete semiconductor diode; File Size31KB，2 Pages; ManufacturerMicrosemi; Websitehttps://www.microsemi.com

Download Datasheet Parametric View All

JANKCA1N5297 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	JANKCA1N5297	-	-	View	Buy Now

JANKCA1N5297 Overview

Current Regulator Diode, 1mA I(S), 1.35V V(L), Silicon, HERMETIC SEALED, DIE-2

JANKCA1N5297 Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Parts packaging code	DIE
package instruction	S-XXUC-N2
Contacts	2
Reach Compliance Code	compliant
ECCN code	EAR99
Shell connection	CATHODE
Configuration	SINGLE
Diode component materials	SILICON
Diode type	CURRENT REGULATOR DIODE
Minimum dynamic impedance	800000 Ω
JESD-30 code	S-XXUC-N2
JESD-609 code	e0
Maximum limit voltage	1.35 V
Number of components	1
Number of terminals	2
Package body material	UNSPECIFIED
Package shape	SQUARE
Package form	UNCASED CHIP
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Maximum power dissipation	0.6 W
Certification status	Qualified
Guideline	MIL-19500/463G
Nominal regulation current (Ireg)	1 mA
Maximum repetitive peak reverse voltage	100 V
surface mount	YES
technology	FIELD EFFECT
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	NO LEAD
Terminal location	UNSPECIFIED
Maximum time at peak reflow temperature	NOT SPECIFIED
Base Number Matches	1

Preview

Download Datasheet

View All

• 1N5283-1 THRU 1N5314-1 AVAILABLE IN

JAN, JANTX, JANTXV AND JANS

PER MIL-PRF-19500/463

• CURRENT REGULATOR DIODES

• HIGH SOURCE IMPEDANCE

• METALLURGICALLY BONDED

• DOUBLE PLUG CONSTRUCTION

1N5283 thru 1N5314

and

1N5283-1 thru 1N5314-1

MAXIMUM RATINGS

Operating Temperature: -65°C to +175°C

Storage Temperature: -65°C to +175°C

DC Power Dissipation: 500mW @ TL= +50°C, L = 3/8”

Power Derating: 4 mW / °C above +50°C

Peak Operating Voltage: 100 Volts

ELECTRICAL CHARACTERISTICS

@ 25°C, unless otherwise speci½ed

TYPE

NUMBER

NOM

1N5283

1N5284

1N5285

1N5286

1N5287

1N5288

1N5289

1N5290

1N5291

1N5292

1N5293

1N5294

1N5295

1N5296

1N5297

1N5298

1N5299

1N5300

1N5301

1N5302

1N5303

1N5304

1N5305

1N5306

1N5307

1N5308

1N5309

1N5310

1N5311

1N5312

1N5313

1N5314

0.22

0.24

0.27

0.30

0.33

0.39

0.43

0.47

0.56

0.62

0.68

0.75

0.82

0.91

1.00

1.10

1.20

1.30

1.40

1.50

1.60

1.80

2.00

2.20

2.40

2.70

3.00

3.30

3.60

3.90

4.30

4.70

REGULATOR CURRENT

l p (mA) @ VS = 25V

MIN

0.198

0.216

0.243

0.270

0.297

0.351

0.387

0.423

0.504

0.558

0.612

0.675

0.738

0.819

0.900

0.990

1.08

1.17

1.26

1.35

1.44

1.62

1.80

1.98

2.16

2.43

2.70

2.97

3.24

3.51

3.87

4.23

MAX

0.242

0.264

0.297

0.330

0.363

0.429

0.473

0.517

0.616

0.682

0.748

0.825

0.902

1.001

1.100

1.210

1.32

1.43

1.54

1.65

1.76

1.98

2.20

2.42

2.64

2.97

3.30

3.63

3.96

4.29

4.73

5.17

MINIMUM

DYNAMIC

IMPEDANCE

@VS = 25V

ZS (M )

(Note 1)

25.0

19.0

14.0

9.0

6.6

4.10

3.30

2.70

1.90

1.55

1.35

1.15

1.00

0.880

0.800

0.700

0.640

0.580

0.540

0.510

0.475

0.420

0.395

0.370

0.345

0.320

0.300

0.280

0.265

0.255

0.245

0.235

MINIMUM

KNEE

IMPEDANCE

@VK = 6.0 V

ZK (M )

(Note 2)

2.75

2.35

1.95

1.60

1.35

1.00

0.870

0.750

0.560

0.470

0.400

0.335

0.290

0.240

0.205

0.180

0.155

0.135

0.115

0.105

0.092

0.074

0.061

0.052

0.044

0.035

0.029

0.024

0.020

0.017

0.014

0.012

MAXIMUM

LIMITING

VOLTAGE

@ lL = 0.8 lp (min)

VL (VOLTS)

1.00

1.05

1.10

1.13

1.15

1.20

1.25

1.29

1.35

1.40

1.45

1.50

1.55

1.60

1.65

1.75

1.85

1.95

2.00

2.15

2.25

2.35

2.50

2.60

2.75

2.90

FIGURE 1

DESIGN DATA

CASE:

Hermetically sealed glass

case. DO – 7 outline.

LEAD MATERIAL:

Copper clad steel.

LEAD FINISH:

Tin / Lead

THERMAL RESISTANCE: (R

OJEC):

250

C/W maximum at L = .375 inch

THERMAL IMPEDANCE: (Z

OJX): 25

C/W maximum

POLARITY:

Diode to be operated with

the banded (Cathode) end negative.

WEIGHT:

0.2 grams.

MOUNTING POSITION:

Any.

NOTE 1

NOTE 2

ZS is derived by superimposing A 90Hz RMS signal equal to 10% of VS on VS

ZK is derived by superimposing A 90Hz RMS signal equal to 10% of VK on VK

6 LAKE STREET, LAWRENCE, MASSACHUSETTS 01841

PHONE (978) 620-2600

FAX (978) 689-0803

WEBSITE: http://www.microsemi.com
