ST7PMC2R6T6/XXX: Description8-BIT, FLASH, 8MHz, MICROCONTROLLER, PQFP64, 14 X 14 MM, LQFP-64; CategoryThe embedded processor and controller Microcontrollers and processors; File Size6MB，311 Pages; ManufacturerSTMicroelectronics; Websitehttp://www.st.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

ST7PMC2R6T6/XXX Overview

8-BIT, FLASH, 8MHz, MICROCONTROLLER, PQFP64, 14 X 14 MM, LQFP-64

ST7PMC2R6T6/XXX Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Parts packaging code	QFP
package instruction	14 X 14 MM, LQFP-64
Contacts	64
Reach Compliance Code	compliant
Has ADC	YES
Address bus width
bit size	8
CPU series	ST72
maximum clock frequency	16 MHz
DAC channel	NO
DMA channel	NO
External data bus width
JESD-30 code	S-PQFP-G64
JESD-609 code	e3
length	14 mm
Number of I/O lines	44
Number of terminals	64
On-chip program ROM width	8
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
PWM channel	YES
Package body material	PLASTIC/EPOXY
encapsulated code	LQFP
Encapsulate equivalent code	QFP64,.6SQ,32
Package shape	SQUARE
Package form	FLATPACK, LOW PROFILE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
power supply	5 V
Certification status	Not Qualified
RAM (bytes)	1024
rom(word)	32768
ROM programmability	FAST
Maximum seat height	1.6 mm
speed	8 MHz
Maximum slew rate	18 mA
Maximum supply voltage	5.5 V
Minimum supply voltage	3.8 V
Nominal supply voltage	5 V
surface mount	YES
technology	CMOS
Temperature level	INDUSTRIAL
Terminal surface	Tin (Sn)
Terminal form	GULL WING
Terminal pitch	0.8 mm
Terminal location	QUAD
Maximum time at peak reflow temperature	NOT SPECIFIED
width	14 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER
Base Number Matches	1

Preview

Download Datasheet

ST7MC1/ST7MC2

8-bit MCU with nested interrupts, flash, 10-bit ADC,

brushless motor control, five timers, SPI, LINSCI™

Features

Memories

– 8K to 60K dual voltage FLASH Program mem-

ory or ROM with read-out protection capabili-

ty, In-Application Programming and In-Circuit

Programming.

– 384 to 1.5K RAM

– HDFlash endurance: 100 cycles, data reten-

tion: 40 years at 85°C

■

Clock, reset and supply management

– Enhanced reset system

– Enhanced low voltage supervisor (LVD) for

main supply and auxiliary voltage detector

(AVD) with interrupt capability

– Clock sources: crystal/ceramic resonator os-

cillators and by-pass for external clock, clock

security system.

– Four power saving modes: Halt, Active-Halt,

Wait and Slow

■

Interrupt management

– Nested interrupt controller

– 14 interrupt vectors plus TRAP and RESET

– MCES top level interrupt pin

– 16 external interrupt lines (on 3 vectors)

■

Up to 60 I/O ports

– up to 60 multifunctional bidirectional I/O lines

– up to 41 alternate function lines

– up to 12 high sink outputs

■

5 Timers

– Main Clock Controller with: Real time base,

Beep and Clock-out capabilities

– Configurable window watchdog timer

– Two 16-bit timers with: 2 input captures, 2 out-

put compares, external clock input, PWM and

pulse generator modes

– 8-bit PWM Auto-Reload timer with: 2 input

captures, 4 PWM outputs, output compare

and time base interrupt, external clock with

event detector

Table 1. Device Summary

■

LQFP80

14 x 14

LQFP64

14 x 14

LQFP44

10 x 10

LQFP32 7x 7

SDIP32

■

■

■

■

■

■

2 Communication interfaces

– SPI synchronous serial interface

– LINSCI™ asynchronous serial interface

Brushless motor control peripheral

– 6 high sink PWM output channels for sine-

wave or trapezoidal inverter control

– Motor safety including asynchronous emer-

gency stop and write-once registers

– 4 analog inputs for rotor position detection

(sensorless/hall/tacho/encoder)

– Permanent magnet motor coprocessor includ-

ing multiplier, programmable filters, blanking

windows and event counters

– Operational amplifier and comparator for cur-

rent/voltage mode regulation and limitation

Analog peripheral

– 10-bit ADC with 16 input pins

In-circuit Debug

Instruction set

– 8-bit Data Manipulation

– 63 Basic Instructions with illegal opcode de-

tection

– 17 main Addressing Modes

– 8 x 8 Unsigned Multiply Instruction

– True Bit Manipulation

Development tools

– Full hardware/software development package

ST7MC2

Features

Program memory - bytes

RAM (stack) - bytes

Peripherals

Operating

Supply vs. Frequency

Temperature Range

ST7MC1

8K

16K

32K

16K

32K

48K

60K

384 (256)

768 (256) 1024 (256) 768 (256)

1024 (256)

1536 (256)

Watchdog, 16-bit Timer A, LINSCI

™

, 10-bit ADC, MTC, 8-bit PWM ART, ICD

SPI, 16-bit Timer B

-

4.5 to 5.5V with f

CPU

≤8MHz

-40°C to +85°C

-40°C to +85 °C

-40°C to +125°C

LQFP44

SDIP56

1)

/LQFP64 LQFP64/44 LQFP80

-40°C to +85°C

-40°C to

-40°C to +85°C

/-40°C to +125°C

+125°C

Package

LQFP32

SDIP32

LQFP32

Note 1:

For development only. No production

Rev 11

December 2006

1/308

1

Table of Contents

1 INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

2 PIN DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

3 REGISTER & MEMORY MAP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

4 FLASH PROGRAM MEMORY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

4.1 INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

4.2

4.3

4.4

4.5

4.6

4.7

4.8

MAIN FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

STRUCTURE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

ICC INTERFACE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

ICP (IN-CIRCUIT PROGRAMMING) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

IAP (IN-APPLICATION PROGRAMMING) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

RELATED DOCUMENTATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

REGISTER DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

5 CENTRAL PROCESSING UNIT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

5.1 INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

5.2

5.3

MAIN FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

CPU REGISTERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

6 SUPPLY, RESET AND CLOCK MANAGEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

6.1 OSCILLATOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

6.2

6.3

6.4

RESET SEQUENCE MANAGER (RSM) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

SYSTEM INTEGRITY MANAGEMENT (SI) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

MAIN CLOCK CONTROLLER WITH REAL TIME CLOCK AND BEEPER (MCC/RTC) . 36

7 INTERRUPTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

7.1 INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

7.2

7.3

7.4

7.5

7.6

7.7

MASKING AND PROCESSING FLOW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

INTERRUPTS AND LOW POWER MODES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

CONCURRENT & NESTED MANAGEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

INTERRUPT REGISTER DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

EXTERNAL INTERRUPTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

EXTERNAL INTERRUPT CONTROL REGISTER (EICR) . . . . . . . . . . . . . . . . . . . . . . . 46

8 POWER SAVING MODES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

8.1 INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

8.2

8.3

8.4

SLOW MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

WAIT MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

ACTIVE-HALT AND HALT MODES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

9 I/O PORTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

9.1 INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

9.2

9.3

9.4

9.5

FUNCTIONAL DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

I/O PORT IMPLEMENTATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

LOW POWER MODES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

INTERRUPTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

308

10 ON-CHIP PERIPHERALS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

10.1 WINDOW WATCHDOG (WWDG) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

2/308

Table of Contents

10.2 PWM AUTO-RELOAD TIMER (ART) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

10.3 16-BIT TIMER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

10.4 SERIAL PERIPHERAL INTERFACE (SPI) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94

10.5 LINSCI SERIAL COMMUNICATION INTERFACE (LIN MASTER/SLAVE) . . . . . . . . . 106

10.6 MOTOR CONTROLLER (MTC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137

10.7 OPERATIONAL AMPLIFIER (OA) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 232

10.8 10-BIT A/D CONVERTER (ADC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 235

11 INSTRUCTION SET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 240

11.1 CPU ADDRESSING MODES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 240

11.2 INSTRUCTION GROUPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 243

12 ELECTRICAL CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 246

12.1 PARAMETER CONDITIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 246

12.2 ABSOLUTE MAXIMUM RATINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 247

12.3 OPERATING CONDITIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 249

12.4 SUPPLY CURRENT CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 251

12.5 CLOCK AND TIMING CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 255

12.6 MEMORY CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 259

12.7 EMC CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 260

12.8 I/O PORT PIN CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 263

12.9 CONTROL PIN CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 266

12.10 TIMER PERIPHERAL CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 269

12.11 COMMUNICATION INTERFACE CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . . . 270

12.12 MOTOR CONTROL CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 272

12.13 OPERATIONAL AMPLIFIER CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . . . . . . 279

12.14 10-BIT ADC CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 280

13 PACKAGE CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 284

13.1 PACKAGE MECHANICAL DATA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 284

13.2 THERMAL CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 288

13.3 SOLDERING INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 289

14 ST7MC DEVICE CONFIGURATION AND ORDERING INFORMATION . . . . . . . . . . . . . . . . 290

14.1 FLASH OPTION BYTES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 290

14.2 DEVICE ORDERING INFORMATION AND TRANSFER OF CUSTOMER CODE . . . . 292

14.3 DEVELOPMENT TOOLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 294

14.4 ST7 APPLICATION NOTES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 296

15 IMPORTANT NOTES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 299

15.1 FLASH/FASTROM DEVICES ONLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 299

15.2 CLEARING ACTIVE INTERRUPTS OUTSIDE INTERRUPT ROUTINE . . . . . . . . . . . . 300

15.3 LINSCI LIMITATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 300

15.4 MISSING DETECTION OF BLDC “Z EVENT” . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 302

15.5 INJECTED CURRENT ON PD7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 302

15.6 RESET VALUE OF UNAVAILABLE PINS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 302

3/308

ST7PMC2R6T6/XXX Related Products

	ST7PMC2R6T6/XXX	ST7MC2S4T6/XXX	ST7PMC2M9T6/XXX	ST7MC1K2T6/XXX	ST7PMC2R7T6/XXX	ST7PMC2S6T6/XXX	ST7PMC2S4T6/XXX
Description	8-BIT, FLASH, 8MHz, MICROCONTROLLER, PQFP64, 14 X 14 MM, LQFP-64	8-BIT, FLASH, 8MHz, MICROCONTROLLER, PQFP44, 10 X 10 MM, LQFP-44	8-BIT, FLASH, 8MHz, MICROCONTROLLER, PQFP80, 14 X 14 MM, LQFP-80	8-BIT, FLASH, 8MHz, MICROCONTROLLER, PQFP32, 7 X 7 MM, LQFP-32	8-BIT, FLASH, 8MHz, MICROCONTROLLER, PQFP64, 14 X 14 MM, LQFP-64	8-BIT, FLASH, 8MHz, MICROCONTROLLER, PQFP44, 10 X 10 MM, LQFP-44	8-BIT, FLASH, 8MHz, MICROCONTROLLER, PQFP44, 10 X 10 MM, LQFP-44
Is it lead-free?	Lead free	Lead free	Lead free	Lead free	Lead free	Lead free	Lead free
Is it Rohs certified?	conform to	conform to	conform to	conform to	conform to	conform to	conform to
Parts packaging code	QFP	QFP	QFP	QFP	QFP	QFP	QFP
package instruction	14 X 14 MM, LQFP-64	10 X 10 MM, LQFP-44	LQFP, QFP80,.64SQ	LQFP, QFP32,.35SQ,32	14 X 14 MM, LQFP-64	10 X 10 MM, LQFP-44	10 X 10 MM, LQFP-44
Contacts	64	44	80	32	64	44	44
Reach Compliance Code	compliant	compliant	compliant	compliant	compliant	compliant	compliant
Has ADC	YES	YES	-	YES	YES	YES	YES
bit size	8	8	-	8	8	8	8
CPU series	ST72	ST72	-	ST72	ST72	ST72	ST72
maximum clock frequency	16 MHz	16 MHz	-	16 MHz	16 MHz	16 MHz	16 MHz
DAC channel	NO	NO	-	NO	NO	NO	NO
DMA channel	NO	NO	-	NO	NO	NO	NO
JESD-30 code	S-PQFP-G64	S-PQFP-G44	-	S-PQFP-G32	S-PQFP-G64	S-PQFP-G44	S-PQFP-G44
JESD-609 code	e3	e3	-	e3	e3	e3	e3
length	14 mm	10 mm	-	7 mm	14 mm	10 mm	10 mm
Number of I/O lines	44	17	-	17	44	26	26
Number of terminals	64	44	-	32	64	44	44
On-chip program ROM width	8	8	-	8	8	8	8
Maximum operating temperature	85 °C	85 °C	-	85 °C	85 °C	85 °C	85 °C
Minimum operating temperature	-40 °C	-40 °C	-	-40 °C	-40 °C	-40 °C	-40 °C
PWM channel	YES	YES	-	YES	YES	YES	YES
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	-	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	LQFP	LQFP	-	LQFP	LQFP	LQFP	LQFP
Encapsulate equivalent code	QFP64,.6SQ,32	QFP44,.47SQ,32	-	QFP32,.35SQ,32	QFP64,.6SQ,32	QFP44,.47SQ,32	QFP44,.47SQ,32
Package shape	SQUARE	SQUARE	-	SQUARE	SQUARE	SQUARE	SQUARE
Package form	FLATPACK, LOW PROFILE	FLATPACK, LOW PROFILE	-	FLATPACK, LOW PROFILE	FLATPACK, LOW PROFILE	FLATPACK, LOW PROFILE	FLATPACK, LOW PROFILE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED	260	-	260	260	260	260
power supply	5 V	5 V	-	5 V	5 V	5 V	5 V
Certification status	Not Qualified	Not Qualified	-	Not Qualified	Not Qualified	Not Qualified	Not Qualified
RAM (bytes)	1024	768	-	384	1536	1024	768
rom(word)	32768	16384	-	8192	49152	32768	16384
ROM programmability	FAST	FLASH	-	FLASH	FASTROM	FASTROM	FASTROM
Maximum seat height	1.6 mm	1.6 mm	-	1.6 mm	1.6 mm	1.6 mm	1.6 mm
speed	8 MHz	8 MHz	-	8 MHz	8 MHz	8 MHz	8 MHz
Maximum slew rate	18 mA	18 mA	-	18 mA	18 mA	18 mA	18 mA
Maximum supply voltage	5.5 V	5.5 V	-	5.5 V	5.5 V	5.5 V	5.5 V
Minimum supply voltage	3.8 V	3.8 V	-	3.8 V	3.8 V	3.8 V	3.8 V
Nominal supply voltage	5 V	5 V	-	5 V	5 V	5 V	5 V
surface mount	YES	YES	-	YES	YES	YES	YES
technology	CMOS	CMOS	-	CMOS	CMOS	CMOS	CMOS
Temperature level	INDUSTRIAL	INDUSTRIAL	-	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL
Terminal surface	Tin (Sn)	Tin (Sn)	-	Matte Tin (Sn)	Tin (Sn)	Tin (Sn)	Tin (Sn)
Terminal form	GULL WING	GULL WING	-	GULL WING	GULL WING	GULL WING	GULL WING
Terminal pitch	0.8 mm	0.8 mm	-	0.8 mm	0.8 mm	0.8 mm	0.8 mm
Terminal location	QUAD	QUAD	-	QUAD	QUAD	QUAD	QUAD
Maximum time at peak reflow temperature	NOT SPECIFIED	NOT SPECIFIED	-	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
width	14 mm	10 mm	-	7 mm	14 mm	10 mm	10 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER	MICROCONTROLLER	-	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER

Recommended Resources

INA103 offset voltage adjustable circuit diagram

TDA1552Q power amplifier circuit diagram

Single-phase electric water pump water level control point card

PI correction compensation circuit

Electronic fuse circuit diagram

H2BIP applied to 40W fluorescent lamp electronic ballast circuit diagram

[Powerful] Jungle Walking Robot - Super Strong Ability to Adapt to Obstacles (Appeared on CCTV) - EEWORLD University Hall: Jungle Walking Robot - Super Ability to Adapt to Obstacles : https://training.eeworld.com.cn/course/2066[size=4][b]Atlas, the latest humanoid robot developed by Boston Dynamics, can already walk in th...; chenyy Robotics Development

CCS6.0 cannot be opened: When I open the software, CCSstudio displays "failed to create the java virtual machine" and then cannot be opened. What should I do?...; 下雨天不洗澡 Microcontroller MCU

Looking for a program for segment calibration of att7022: Has anyone done segmented calibration of att7022? I have been working on it for several days but have no idea. Please help, thank you!...; 小子sxx stm32/stm8

TI Cup 2009 D topic: Single-phase sine wave variable frequency power supply: Does anyone have relevant information about the TI Cup 2009 D question "Single-phase sine wave variable frequency power supply"? And can this be achieved with L298? Thank you......; leijiayou MCU

Display of single chip microcomputer to common cathode LED seven-segment digital tube: [p=24, null, left][color=#333333][font=arial, 宋体, sans-serif,]My friend is going to write a graduation thesis. Since I help him to look up information, please help us to see what we need to start, wha...; yanglu_lulu 51mcu

I found that the board I bought in group purchase has been shipped.: I am a little happy that the msp430 development board I bought in group purchase at eeworld has been shipped. I am very grateful to the organizer of the event, and I hope that everyone who got the boa...; liangpingyy Microcontroller MCU

Shortcut: 00 01 02 03 04 05 06 07 08 09 0A 0C 0F 0J 0L 0M 0R 0S 0T 0Z 10 11 12 13 14 15 16 17 18 19 1A 1B 1C 1D 1E 1F 1H 1K 1M 1N 1P 1S 1T 1V 1X 1Z 20 21 22 23 24 25 26 27 28 29 2A 2B 2C 2D 2E 2F 2G 2K 2M 2N 2P 2Q 2R 2S 2T 2W 2Z 30 31 32 33 34 35 36 37 38 39 3A 3B 3C 3D 3E 3F 3G 3H 3J 3K 3L 3M 3N 3P 3R 3S 3T 3V 40 41 42 43 44 45 46 47 48 49 4A 4B 4C 4D 4M 4N 4P 4S 4T 50 51 52 53 54 55 56 57 58 59 5A 5B 5C 5E 5G 5H 5K 5M 5N 5P 5S 5T 5V 60 61 62 63 64 65 66 67 68 69 6A 6C 6E 6F 6M 6N 6P 6R 6S 6T 70 71 72 73 74 75 76 77 78 79 7A 7B 7C 7M 7N 7P 7Q 7V 7W 7X 80 81 82 83 84 85 86 87 88 89 8A 8D 8E 8L 8N 8P 8S 8T 8W 8Y 8Z 90 91 92 93 94 95 96 97 98 99 9A 9B 9C 9D 9F 9G 9H 9L 9S 9T 9W

Popular Components

Popular Articles

Technical ResourceMore

EEWorld
subscription
account

EEWorld
service
account

Automotive
development
circle

Robot
development
community

About Us Customer Service Contact Information Datasheet Sitemap LatestNews

Index Files: 542 2725 2032 2887 220 11 55 41 59 5

Datasheet 0 1 2 3 4 5 6 7 8 9 A B C D E F G H I J K L M N O P Q R S T U V W X Y Z

Room 1530, 15th Floor, Building B, No. 18 Zhongguancun Street, Haidian District, Beijing Telephone: (010) 82350740 Postal Code: 100190

Copyright © 2005-2026 EEWORLD.com.cn, Inc. All rights reserved 京ICP证060456号京ICP备10001474号-1 电信业务审批[2006]字第258号函

京公网安备 11010802033920号
