SMGA-12 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Mechanical and electronic products> relay> SMGA-12

SMGA-12: DescriptionPOWER/SIGNAL RELAY, DPDT, MOMENTARY, 0.031A (COIL), 12VDC (COIL), 369mW (COIL), 1A (CONTACT), 28VDC (CONTACT), SURFACE MOUNT-STRAIGHT; CategoryMechanical and electronic products relay; File Size109KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric Compare View All

SMGA-12 Overview

POWER/SIGNAL RELAY, DPDT, MOMENTARY, 0.031A (COIL), 12VDC (COIL), 369mW (COIL), 1A (CONTACT), 28VDC (CONTACT), SURFACE MOUNT-STRAIGHT

SMGA-12 Parametric

Parameter Name	Attribute value
Brand Name	CII
Is it Rohs certified?	incompatible
Reach Compliance Code	unknown
ECCN code	EAR99
body width	8.51 mm
body height	7.11 mm
Body length or diameter	8.51 mm
Maximum coil current (DC)	0.031 A
Coil operating voltage (DC)	9 V
Coil power	369 mW
Coil release voltage (DC)	0.41 V
Coil resistance	390 Ω
Maximum coil voltage (DC)	12 V
Coil/Input Power Type	DC
Contact (AC) maximum rated R load	.25A@115VAC
Maximum contact current (AC)	0.25 A
Maximum contact current (DC)	1 A
Contact (DC) maximum rated R load	1A@28VDC
Maximum contact voltage (AC)	115 V
Maximum contact voltage (DC)	28 V
Contact/Output Power Type	AC/DC
Electrical life	100000 Cycle(s)
Manufacturer's serial number	SMGA
Installation features	SURFACE MOUNT-STRAIGHT
operating hours	3.5 ms
Maximum operating temperature	125 °C
Minimum operating temperature	-65 °C
physical size	8.51mm X 8.51mm X 7.11mm
Guideline	MIL-R-39016/17
Relay action	MOMENTARY
Relay function	DPDT
Relay type	POWER/SIGNAL RELAY
release time	3 ms
seal	HERMETICALLY SEALED
surface mount	NO
Termination type	SOLDER
Base Number Matches	1

Preview

Download Datasheet

View All

My Account

Tyco Electronics

(C hange)

Se a rch by Ke yword or Pa rt #

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Relays

Product Feature Selector

> Product Details

SMGA-12 Product Details

Military/Aerospace High Performance Relays

Not EU R oHS or ELV C om plia nt

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

SMGA-12

(1617159-1)

T E I nternal N umber: 1 6 1 7 1 5 9 - 1

Product Highlights:

SMGA .100 Grid Relay Series

Input Voltage = 12 VDC

C ontact Arrangement = 2 Form C , DPDT, 2 C /O

C ontact C urrent Rating = 1 Amps.

Non Polarized, Monostable C oil Magnetic System

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Active

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

RELAY

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Termination Type = Surface Mount

Electrical Characteristics:

Input Voltage (VDC ) = 12

C ontact C urrent Rating (Amps.) = 1

C oil Polarity Protection Diode = Without

Transistor Driver = Without

C oil Resistance (?) = 390

MOSFET Driver = Without

C oil Power Measurement = Milliwatts

C oil Power, Nominal (mW) = 369

Actuating System = DC

Shock = 75 G's, 6ms

Vibration = 30G's, 10 to 3000Hz

Body Related Features:

Series

= SMGA .100 Grid Relay

Contact Related Features:

Mounting Options = PC Board

Enclosure = Hermetically Sealed

Configuration Related Features:

C ontact Arrangement

= 2 Form C , DPDT, 2 C /O

C oil Magnetic System = Non Polarized, Monostable

C oil Suppression Diode = Without

Industry Standards:

Government/Industry Qualification = No

RoHS/ELV C ompliance

= Not ELV/RoHS compliant

Lead Free Solder Processes

= Not suitable for lead free processing

Conditions for Usage:

Temperature Range (?C ) = -65 – +125

Other:

Brand = C II

Additional Information:

Product Line Information

SMGA-12 Related Products

	SMGA-12	1617159-1
Description	POWER/SIGNAL RELAY, DPDT, MOMENTARY, 0.031A (COIL), 12VDC (COIL), 369mW (COIL), 1A (CONTACT), 28VDC (CONTACT), SURFACE MOUNT-STRAIGHT	POWER/SIGNAL RELAY, DPDT, MOMENTARY, 0.031A (COIL), 12VDC (COIL), 369mW (COIL), 1A (CONTACT), SURFACE MOUNT-STRAIGHT
Is it Rohs certified?	incompatible	incompatible
Reach Compliance Code	unknown	unknown
ECCN code	EAR99	EAR99
Maximum coil current (DC)	0.031 A	0.031 A
Coil power	369 mW	369 mW
Coil resistance	390 Ω	390 Ω
Maximum coil voltage (DC)	12 V	12 V
Coil/Input Power Type	DC	DC
Maximum contact current (AC)	0.25 A	1 A
Maximum contact current (DC)	1 A	1 A
Contact/Output Power Type	AC/DC	AC/DC
Manufacturer's serial number	SMGA	1617159
Installation features	SURFACE MOUNT-STRAIGHT	SURFACE MOUNT-STRAIGHT
Maximum operating temperature	125 °C	125 °C
Minimum operating temperature	-65 °C	-65 °C
Relay action	MOMENTARY	MOMENTARY
Relay function	DPDT	DPDT
Relay type	POWER/SIGNAL RELAY	POWER/SIGNAL RELAY
seal	HERMETICALLY SEALED	HERMETICALLY SEALED
surface mount	NO	NO
Termination type	SOLDER	SOLDER
Base Number Matches	1	1
