REVISIONS
DESCRIPTION
RELEASED FOR PRODUCTION
PRODUCT VALIDATION UPDATE (ECN)
REWORDED SPECIFICATIONS FOR LABELING
.
1
DATE
09/28/00
01/20/03
10/15/04
.
APPROVED
R.CARRICK
MCCORMICK
M.LAHEY
.
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF
L-COM, INC. ANY REPRODUCTIONS IN PART OR WHOLE WITHOUT THE WRITTEN
PERMISSION OF L-COM, INC. IS PROHIBITED.
D
.72
D
DB9
DB25
1.852
4X R.132
1.684
2.10
1.85
.449
1
2
3
4
5
6
7
8
9
8
3
2
20
7
6
4
5
22
C
C
2X R.06
.51
RECOMMENDED
PANEL OPENING
MAX PANEL THICKNESS: 0.06"
FEMALE, 9 PIN
D-SUB CONNECTOR
2X 4-40 PHILLIPS HD
B
B
.23
SPECIFICATIONS;
MATERIALS;
SHELL: COLD ROLLED STEEL
CONTACTS: BRASS
INSULATOR: PBT UL94-V0 RATED
FINISH;
SHELL: TIN PLATED
CONTACT: GOLD FLASH
C
LABELING:
PANTONE 2945 BLUE. "L-COM" FONT MyriaMM ITALIC.
"ADAPTOR" FONT ARIAL BOLD, TEXT HEIGHTS; .085"
TEXT COLOR; WHITE.
APPROVALS
DRAWN BY
R.CARRICK
CHECKED BY
DATE
12/03/2001
PRODUCT DESCRIPTION
MALE, 25 PIN
D-SUB CONNECTOR
A
45 BEECHWOOD DRIVE
NORTH ANDOVER, MA
01845
A
ADAPTOR, DB25 MALE/DB9 FEMALE
DRAWING TITLE
UNLESS OTHERWISE SPECIFIED
12/03/2001
MCCORMICK
DIMENSIONS ARE IN INCHES
APPROVED BY
TOLERANCES ARE:
D.PARHAM
12/03/2001
.X .1
.XX .05
CONFIGURATION DETAILS OF
.XXX .005
UNDIMENSIONED FEATURES
CABLE LENGTH TOLERANCE
MAY VARY
<300" ±5% >300" ±2%
OUTLINE DRAWING
SIZE
FSCM NO.
DWG. NO.
REV.
B
43321
DMA010FM-OD1
1
C
SCALE: 2:1
CAD FILE: DMA010FM-OD1.SLDDRW
SHEET 1 OF 1
8
7
6
5
4
3
2
