INTERCONNECTS
SERIES 712 • 2,54 GRID CARRIER WITH SOLDER TAIL •
SINGLE AND DOUBLE ROW STRIPS
•
Standard solder tail receptacles can be
Number of Pins X 2,54
2,54
2,54
mounted as a low profile receptacle or by the
solder tail for use in smaller diameter holes
•
Series 712 use MM #0255 pins. See page 165
for details
•
Hi-Rel, 4-finger BeCu #30 contact is rated at
3 amps. See page 253 for details
0,38-0,64
0,25 * 0,46
1,83 DIA.
1,35 DIA.
0,79
•
Insulators are high temperature thermoplastic,
suitable for all soldering operations
2,62
3,81 4,39
ORDERING INFORMATION
Single Row (0,71 or 1,4 min. mounting holes)
0,51 DIA.
3,15
FIG. 1
FIG. 1
FIG. 2
Number of Pins X 2,54 / 2
712-XX-1_ _-41-001000
Specify number of pins
01-64
Double Row (0,71 or 1,4 min. mounting holes)
712-XX-2_ _-41-001000
Specify number of pins
5,08
04-64
2,54
2,54
0,38-0,64
0,25 * 0,46
1,83 DIA.
1,35 DIA.
0,79
2,62
0,51 DIA.
3,15
2011/65/EU
RoHS - 2
XX=Plating Code
See Below
11
13
91
93
For
Electrical, Mechanical
& Enviromental Data,
See page 264
2,54
SPECIFY PLATING CODE XX=
41
43
FIG. 2
Sleeve
(Pin)
Contact
(Clip)
0,25μm
Au
0,25μm
Au
5,08μm
Sn/Pb
5,08μm
Sn/Pb
5,08μm
Sn
5,08μm
Sn
0,25μm
Au
0,76μm
Au
0,25μm
Au
0,76μm
Au
0,25μm
Au
0,76μm
Au
Mill-Max Mfg. Corp. • 190 Pine Hollow Road, P.O. Box 300, Oyster Bay, NY 11771 • 516-922-6000 • Fax: 516-922-9253 • www.mill-max.com
PAGE 75 | INTERCONNECTS
