D72 & DP72 Series
Specification
(25°C and Vs ± 15 Vdc)
Analog Input Characteristics
Impedance
10 kΩ min.
Voltage Range
± 10 Vpeak
Max. Safe Voltage
± Vs
Analog Output Characteristics
Impedance
1
Ω
Linear Operating Range± 10 V
2
Maximum Current
D72 ± 10 mA
DP72 ± 5 mA
Offset Voltage
10 mV max.
1
3 mV typ.
Offset Temp. Coeff.
20
µV
/ °C
Power Supply (±V)
Rated Voltage
± 15 Vdc
Operating Range
± 5 to ± 18 Vdc
Maximum Safe Voltage ± 18 Vdc
Quiescent Current
D72
5 mA max.
3 mA typ.
Quiescent Current
DP72
1 mA max.
600
µA
typ.
Temperature
Operating
-
0 to + 70 °C
Storage
- 25 to + 85 °C
Notes:
1. Input and output signal voltage referenced to
supply common.
2. Output is short circuit protected to common.
DO NOT CONNECT TO ±Vs.
1
Pin-Out and Package Data
Ordering Information
All dimensions are in inches
All case dimensions ± 0.01"
Grid Dimensions 0.1" x 0.1"
IN
1
-Vs
8
15
GND
12 11
+Vs OUT
BOTTOM VIEW
0.46
➝
(max.)
➝
0.375
(max.)
➝
➝
0.15
(min.)
0.88
(max.)
➝
➝
➝
➝
0.30
(typ.)
➝
0.09
(typ.)
➝ ➝
➝ ➝
0.025
(dia.)
➝ ➝
0.10
(typ.)
FRONT VIEW
SIDE VIEW
Filter Mounting Assembly-See FMA-01A
Ordering Information
Filter Type
L
- Low Pass
H
- High Pass
Transfer Function
B
- Butterworth
L
- Bessel
D72L2B-849 Hz
Power Level
- 3 dB Corner Frequency
3
D
– Standard Power
DP
– Low Power
e.g., 849 Hz
2.50 kHz
33.3 kHz
3. How to Specify Corner Frequency:
Corner frequencies are specified by attaching a three digit frequency designator to the
basic model number. Corner frequencies can range from 1 Hz to 100 kHz.
