D76L6L-33.3KHZ datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> filter> D76L6L-33.3KHZ

D76L6L-33.3KHZ: DescriptionActive Filter, 1 Func, PDIP32, DIP-32/5; CategoryAnalog mixed-signal IC filter; File Size646KB，6 Pages; ManufacturerFrequency Devices

Download Datasheet Parametric View All

D76L6L-33.3KHZ Overview

Active Filter, 1 Func, PDIP32, DIP-32/5

D76L6L-33.3KHZ Parametric

Parameter Name	Attribute value
package instruction	DIP, DIP5/32,.6
Reach Compliance Code	unknown
JESD-30 code	R-PDIP-T32
length	45.72 mm
Maximum negative supply voltage (Vsup)	-18 V
Negative supply voltage minimum (Vsup)	-5 V
Nominal Negative Supply Voltage (Vsup)	-15 V
Number of functions	1
Number of terminals	32
Maximum operating temperature	70 °C
Minimum operating temperature
Package body material	PLASTIC/EPOXY
encapsulated code	DIP
Encapsulate equivalent code	DIP5/32,.6
Package shape	RECTANGULAR
Package form	IN-LINE
Maximum seat height	12.7 mm
Maximum supply current (Isup)	9 mA
Maximum supply voltage (Vsup)	18 V
Minimum supply voltage (Vsup)	5 V
Nominal supply voltage (Vsup)	15 V
surface mount	NO
Temperature level	COMMERCIAL
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
width	20.32 mm
Base Number Matches	1

Preview

Download Datasheet

View All

D76 & DP76 Series

1.0 Hz to 100 kHz

Fixed Frequency

Description

The D76 and DP76 Series of low-power, fixed-

frequency, linear active filters are high performance,

6-pole filters in a compact package. These

Butterworth and Bessel low-pass and Butterworth

high-pass filters (D76 only) combine linear active

filter design with the space savings of a 32-pin dual

in-line package (DIP). Each model comes factory

tuned to a user-specified corner frequency between

1 Hz and 100 kHz (DP76, 1 Hz to 5kHz). These fully

self-contained units require no external components

or adjustments and operate with dynamic input

voltage range from non-critical ±5V to ±18V power

supplies.

Features/Benefits:

• Low cost solution for low frequency signal

conditioning

• Compact DIP design minimizes board space

requirements

• Plug-in ready-to-use, reducing engineering design

and manufacturing time

• Factory tuned, no external clocks or adjustments

needed saving time and labor of other discrete

assembly solutions

• Low harmonic distortion and wide signal-to-noise

ratio to 12 bit resolution

Applications

• Anti-alias filtering

• Vibration & shock analysis

• Automatic test equipment

• Aerospace, navigation and sonar

• Communication systems

• Medical electronics

• Sound and vibration testing

• Noise elimination

• Process control

32 Pin DIP

6-Pole Filters

Available

D76L6B

DP76L6B

D76L6L

DP76L6L

Low-Pass Models:

. . . . . . . . . . . . . . . .

6-pole Butterworth . . . . . . . . . . . . . . .2

6-pole Butterworth (Low Power) . . . . .2

6-pole Bessel . . . . . . . . . . . . . . . . . . .2

6-pole Bessel (Low Power) . . . . . . . .2

Available High-Pass Models:

D76H6B

6-pole Butterworth . . . . . . . . . . . . . . .2

General Specifications:

Pin-out/package data & ordering information . . . .3

25 Locust St, Haverhill, Massachusetts 01830 • Tel: 800/252-7074, 978/374-0761 • FAX: 978/521-1839

e-mail: sales@freqdev.com • Web Address: http://www.freqdev.com
