5102162-9 Product Details
Live Product Chat
Product Photo
Pin and Pinless Headers (AMP-LATCH)
Always EU R oHS/ELV C om plia nt
(
Sta te m e nt of C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
5102162-9
T E I nternal N umber: 5 1 0 2 1 6 2 - 9
Product Highlights:
l
C onnector Type = Universal Ejection Pin Headers
l
Standard Profile
l
Number of Positions = 40
l
2.54 x 2.54 mm C enterline, Matrix
l
PC B Mount Angle = Right Angle
View all Features
Obsolete
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
HEADER ASSY, UNIVERSAL, AMP-LATC H
(PDF, English)
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
AMP-LATC H* and IDC Header C onnectors, .100 x .100 In...
(PDF, English)
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
C onnector Type
= Universal Ejection Pin Headers
l
Profile
= Standard
l
Number of Positions
= 40
l
PC B Mount Angle
= Right Angle
l
PC B Retention Feature
= No
l
Mating Polarization Type
= C enter, Dual Polarizing Bar, Military
l
Mating C onnector Lock
= Without
l
Housing Style
= 4-Sided
l
Ejection Latches
= Without
l
Post Size (mm [in]) = 0.64 [.025]
l
Shrouded = Yes
l
PC B Thickness (mm [in]) = 3.18 [0.125]
l
Mating Polarization = With
Termination Related Features:
l
Termination Post Length (mm [in])
= 3.94 [0.155]
l
Solder Tail C ontact Plating = Tin over Nickel
Body Related Features:
l
C enterline, Matrix (mm [in])
= 2.54 x 2.54 [.100 x .100]
Contact Related Features:
l
C ontact Mating Area Plating Material
= Gold (30), Gold Flash over
Palladium Nickel
l
C ontact Shape = Square
l
C ontact Base Material = Phosphor Bronze
Housing Related Features:
l
Housing Material = Thermoplastic
l
Housing Flammability Rating = UL 94V-0
l
Housing C olor = Black
Industry Standards:
l
RoHS/ELV C ompliance
= RoHS compliant, ELV compliant
l
Lead Free Solder Processes
= Wave solder capable to 240?C , Wave
solder capable to 260?C , Wave solder capable to 265?C
l
RoHS/ELV C ompliance History = Always was RoHS compliant
Conditions for Usage:
l
Temperature Rating
= Standard
Other:
l
Brand = AMP
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
